JOB:
ITEM NO:
AQUATEMP™/ROAST-N-HOLD
GENTLE CONVECTION OVEN
MODEL CO-151-HW-UA-6D (HALF SIZE)
FEATURES AND BENEFITS:
• Roast, cook, bake, reheat and hold with precise temperature and
humidity control. Slow convected air system promotes natural
browning for flavor and seals in natural juices.
• Moist heat, dry heat or a combination of both allows for a variety of
food preparation and holding.
• Full 4700 Watts of power allows for reheating of prepared meals or
bulk items. Maximum temperature 350˚F. (176.5˚C.).
• Standard 1850 Watt water heater with automatic water fill system and
low water indicator. LED and water heater shut off when water is at
critically low level.
• Standard solid state electronic control with large, clean, easy-to-read
and operate LED digital display to ensure holding at precise food
temperatures.
• AquaTemp system maintains optimum food texture through
continuous monitoring of both temperature and humidity.
Temperature and humidity values are measured, displayed and
controlled through intuitive solde state controller. Air temperature is
prioritized over humidity to ensure food safety.
• Roast and hold over 120 lbs. (54 kg.) of meat in just 7 sq. ft. of floor
space.
• Non-venting oven, permitted by most local codes, provides easy,
inexpensive installation.
• Stainless steel construction throughout for ease of cleaning. Smooth
interior coved corners prevent food particle/grease buildup.
• Field reversible insulated door prevents temperature loss. Silicone
door gasket for proper seal. High temperature ceramic magnetic latch
for “easy open” and security during transport.
• Safety conscious anti-microbial latch protects against spreading
germs. Standard with right hand hinging; left hand hinging available
upon request.
• Non-corrosive stainless steel wire universal angles accommodate a
large variety of pan sizes on adjustable 1-1/2" spacing. Supplied with
six sets of angles and three raised wire grids.
• Heavy duty 5" swivel casters, two with brakes. Provides mobility
when fully loaded.
Deluxe Models (-DX) have 18 factory or eld programmed cook
& hold cycles. Each programmed menu can be customized for
exact time and temperature needs. Probe cooking includes one
6" meat temperature probe and port.
POWER UNIT OPTIONS:
4700 Watts, 208 Volts, 1 Phase, 60 Hz.
4700 Watts, 240 Volts, 1 Phase, 60 Hz.
4700 Watts, 208 Volts, 3 Phase, 60 Hz.
4700 Watts, 240 Volts, 3 Phase, 60 Hz.
™
®
C US
CO-151-HW-UA-6DE
Standard (-DE) Deluxe (-DX)
All Ovens come standard with
easy-to-read and operate
LED digital controls.
ACCESSORIES and OPTIONS
(Available at extra cost):
q Deluxe version with 18 programmable menus
and 6" meat probe (or optional 3" food probe).
q Security Panel for Controls
q Key Lock Latch
q Extra Universal Angles
q Extra Wire Grids
q Side and Rear Bumpers
q HACCP Documentation (built-in USB port)
See page E-10 for accessory details.
Deluxe Controls are available
with 18 programmable menus
and 6" meat probe.
5925 Heisley Road • Mentor, OH 44060-1833
Phone: 877/CRESCOR • Fax: 440/350-7267
www.crescor.com
Page E-4.1A
Jan., 2015
CO-151-HW-UA-6D
5-1/8
4"
4-1/2
"B"
DETAIL OF
PAN SLIDE
CRES COR
MODEL NO.
CO-151-HW-UA-6DE
CO-151-HW-UA-6DX
Note: Refer to pan size chart at end of section.
CAP/ANGLES
SETS
CABINET:
• Body: 22 ga. stainless steel.
• Reinforcement: Internal framework of 16 ga. stainless steel.
• Insulation: Fiberglass, thermal conductivity (K factor) is .23 at
75˚F. 1-1/2" in back wall, doors, base; 2" in side walls.
• Water pan: 4 Gallons; 16 ga. stainless steel with 1850 Watt
heater and with petcock drain; mounted to base.
• Air tunnels: 20 ga. stainless steel, lift-out type, mounted on side walls.
• Interior coved corners
• Automatic water ll hook-up under base.
• Work top: 18 ga., stainless steel.
BASE:
• One piece construction, .125 aluminum.
• Drip trough: Formed 18 ga. stainless steel; mounted to lower
front of cabinet.
• Casters: 5" dia., swivel, modulus tires, 1-1/4 wide, load cap.
250 lbs. each, temp. range -45˚/+180˚F. Delrin bearings. Front
casters equipped with brakes.
DOOR:
• Field reversible.
• Formed 22 ga. stainless steel.
• Latch: Chrome plated zinc with composite handle, ceramic
magnetic type.
• Hinges: Heavy duty chrome plated zinc.
• Pan stop: Embossed.
PAN SLIDES:
• Stainless steel wire universal angles (.306 dia.) mounted on
lift-out posts.
• (6) sets of angles adjustable on 1-1/2" centers.
• Grids (3): Nickel chrome plated steel, raised wire 17" x 25".
POWER REQUIREMENTS AVAILABLE:
• 4700 Watts, 208 Volts, 60 Hz., 1 phase, 24 Amps., 30 Amp. service.
• 4700 Watts, 240 Volts, 60 Hz., 1 phase, 21 Amps., 30 Amp. service.
• 4700 Watts, 208 Volts, 60 Hz., 3 phase, 15 Amps., 20 Amp. service.
• 4700 Watts, 240 Volts, 60 Hz., 3 phase, 13 Amps., 20 Amp. service.
PAN DIM "A" DIM "B" DIM "C" INSIDE DIMENSIONS
SIZE WIDTH DEPTH HEIGHT WIDTH DEPTH HEIGHT
6
SEE NOTE
BELOW
IN 28-1/4 34 43-1/4 21-1/4 26-1/2 28 LBS 260
MM 718 864 2832 540 675 715 KG 118
"A"
G
"C"
40"
ELECTRICAL COMPONENTS:
• Thermostat (roast/hold): Solid state digital control, 140°F to 350˚F
(176.5˚C).
• Thermostat (humidity): Solid state digital control, room ambient
to 95%.
• Switch: ON-OFF push button type.
• Thermometer: Digital.
• Power cord: Permanent, 6 ft.;
- Right Angle Plug for 30 Amp.
- Straight Blade Twistlock Plug for 20 Amp.
• Air heaters (6): 735 Watts each.
• Water heater: 1850 Watts.
• Blower motors (4).
• Vent fans (3).
• Fuses (2): 6 amp.
INSTALLATION REQUIREMENTS:
• This model complies with section 59 of UL710B for emissions
of grease laden air, and according to UL is not required to be
placed under a ventilation hood. Check local requirements
before installation.
SHORT FORM SPECIFICATIONS
Cres Cor AquaTemp Roast-N-Hold Convection Oven Model
CO-151-HW-UA-6D_. 18 ga. stainless steel, recessed
control panel with digital thermostats. Cabinet 22 ga.
stainless steel. Stainless steel internal frame; coved corner
interior. 16 ga. stainless steel water reservoir, 4 gallon
capacity. Fiberglass insulation in sides 2”; back, door and
base 1-1/2”. 22 ga. stainless steel door, high temperature
anti-microbial magnetic latch, heavy duty hinges. (6) sets
universal angles for multiple pan sizes and spacing. One
piece base .125 aluminum. 5" swivel modulus casters,
Delrin bearings. Load capacity 250 lbs. each.
4700 Watts,
_____ Volts, 60 Hz., ____ Phase. 2-Year Parts / 1-Year
Labor warranty. Provide the following accessories: ______
______ ______. CSA-US, CSA-C, CSA to NSF4 listed.
6-30P
YXG
Z
L15-20P
WEIGHT
ACT.
In line with its policy to continually improve its products,
5925 Heisley Road • Mentor, OH 44060-1833
Phone: 877/CRESCOR • Fax: 440/350-7267
www.crescor.com
© Crescent Metal Products, Inc. 2015 All rights reserved. Litho in U.S.A.
CRES COR reserves the right to change materials and
specications without notice.
