TRANSPORT DOLLIES
500 SERIES
FEATURES AND BENEFITS:
• Sturdy dolly for storage and transport of
miscellaneous pans, cup and glass racks, or
baskets.
• Constructed of non-corrosive, Hi-Tensile
aluminum.
• Base and corner gussets formed of .100
aluminum for strength and durability.
JOB:
ITEM NO:
• Heavy duty 5" swivel casters, two with brakes.
Provides mobility when fully loaded. No rust
sealed bearings prevent “wheel lock” in wet
environments.
500-2020
(Shown with accessory handle)
¨ N
ACCESSORIES and OPTIONS
(Available at extra cost):
q Rigid or Spring-Back Push Handle
q Corner Bumpers
q Various Caster Options
See page H-9 for accessory details.
5925 Heisley Road • Mentor, OH 44060-1833
Phone: 877/CRESCOR • Fax: 440/350-7267
www.crescor.com
Page H-7
Jan., 2011
B
500 Series
A
A B
C
CRES COR
MODEL NO.
500-2020
500-1326-2
1
Carries two 13" x 26" baskets for side by side for Basket Retherm operations.
ALL ALUMINUM CONSTRUCTION.
PAN SIZE DIM "A" WIDTH DIM "B" DEPTH DIM "C" HEIGHT WEIGHT ACT.
INCHES MM INCHES MM INCHES MM INCHES MM LBS KG
20 x 20 510 x 510 20-5/8 525 20-5/8 525 8-7/8 225 19 9
13 x 26
1
330 x 660 27-5/8 705 26-5/8 680 8-7/8 225 24 11
BASE:
• Base and corner gussets: Formed .100 aluminum and
fastened together with machine screws.
• Casters: 5" dia., swivel, modulus tires, 1-1/4 wide, load
cap. 250 lbs. each, temp. range -45˚/+180˚F. Delrin
bearings. Two casters equipped with brakes.
SHORT FORM SPECIFICATIONS
Cres Cor Transport Dolly Model 500- formed of
.100 aluminum, corner gussets fastened with machine
screws. Five inch swivel modulus casters have Delrin
bearings. Load capacity 250 lbs. each. Provide the
following accessories: . NSF listed.
2-Year Parts / 1-Year Labor warranty.
In line with its policy to continually improve its products,
5925 Heisley Road • Mentor, OH 44060-1833
Phone: 877/CRESCOR • Fax: 440/350-7267
www.crescor.com
© Crescent Metal Products, Inc. 2011 All rights reserved. Litho in U.S.A.
CRES COR reserves the right to change materials and
specications without notice.
