QUEEN MARY RACKS
271 SERIES
FEATURES AND BENEFITS:
• Durable Queen Mary rack ideal for transporting
plated banquet meals and returning soiled
dishware to ware washing area.
• All riveted framework of structural aluminum
extrusions for rigidity and durability.
• Constructed of non-corrosive, Hi-Tensile
aluminum for strength.
JOB:
ITEM NO:
• Shelves have raised "marine" edges; prevents
tray slide and retains spillage.
• Two models available:
5 shelves with 11" clearance - Model 271-51-5927
6 shelves with 8" clearance - Model 271-61-5927
• Side mounted push handles for ease of
transporting.
• Standard perimeter bumper protects surfaces.
• Heavy duty 8" polyurethane casters, two swivel
with brakes make maneuvering easy.
271-61-5927
¨ N
ACCESSORIES and OPTIONS
(Available at extra cost):
q Stainless Steel Shelves
5925 Heisley Road • Mentor, OH 44060-1833
Phone: 877/CRESCOR • Fax: 440/350-7267
www.crescor.com
Page G-26
Jan., 2011
271 Series
A
A
B
C
CRES COR
MODEL NO.
271-51-5927
271-61-5927
NOTES: 1. For oval tray sizes: 20-3/4" x 25-1/2", 22-3/4" x 27-5/8" and 23-1/2" x 29". Two trays per shelf.
2. *Inside height dimension is between shelves.
NO. OF
SHELVES
5
6
DIM "A" DIM "B" DIM "C" INSIDE DIMENSIONS
WIDTH DEPTH HEIGHT WIDTH DEPTH *HEIGHT
IN 62-1/4 29 62-11/16 55-1/4 25 11 LBS 156
MM 1585 740 1595 1405 635 280 KG 71
IN 62-1/4 29 62-11/16 55-1/4 25 8 LBS 156
MM 1585 740 1595 1405 635 205 KG 71
B
WEIGHT
ACT.
ALL ALUMINUM CONSTRUCTION IS RIVETED, WELDED AND FINISHED.
RACK:
• Posts: Extruded channels, 1 x 2 x .125.
• Shelves: Formed one piece .063 aluminum with 1/4" marine
edges on the two 62" sides; reinforced with .063 aluminum
channels.
• Optional stainless steel shelves are 16 ga. type 304.
271-52-5927: Five shelves spaced with 11" clearance.
271-62-5927: Six shelves spaced with 8" clearance.
• Shelf corners and bottom gussets: .100 aluminum
riveted to posts and shelves.
• Push handles (2): 1" dia. aluminum tubing, gray
plastic coated.
• Bolsters: Formed .190 aluminum; welded to posts,
casters attached.
• Casters: 8" dia., polyurethane tires, 2" wide, load cap.
900 lbs. each, temp. range -30˚/+180˚F. Bearings are
sealed and permanently lubricated. Two swivel casters
equipped with brakes and two rigid casters.
• Bumper: 1" wide gray rubber, perimeter type.
Cres Cor Queen Mary Rack Model 271-____-5927.
Extruded aluminum construction reinforced with riveted
gussets. (___) aluminum (or) stainless steel shelves with
1/4" marine edges with (___) clearance. Push handle
on each end. 8" polyurethane casters, 2 swivel, 2 rigid,
permanently lubricated, sealed ball bearings. Load
capacity 900 lbs. each, temperature -30° to +180°F. 2 Year
Parts / 1 Year Labor Warranty. NSF Listed. NSF Listed.
SHORT FORM SPECIFICATIONS
In line with its policy to continually improve its products,
5925 Heisley Road • Mentor, OH 44060-1833
Phone: 877/CRESCOR • Fax: 440/350-7267
www.crescor.com
© Crescent Metal Products, Inc. 2011 All rights reserved. Litho in U.S.A.
CRES COR reserves the right to change materials and
specications without notice.
