Creative Labs WMU95S0103E User Manual

Note:

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

t may cause

The manufacturer is not responsible for any radio or TV interference caused by unauthorized

modifications to this equipment. Such modifications could void the user authority to operate the

conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference tha

undesired operation.

Caution:

equipment.

Revision History

RevisionDescriptions Preparedby Date

1.1 Low battery blue LED at receiver MLK 10/05/04

1.2

Text format put up modify

MLK 10/27/04

Part 1.0: General features and description

- Prevent Repetitive Strain Injury on your wrists and arms.

- Radio frequency : 27.045 MHz、27.195MHz, two channels with 256 IDs per channel, no more

problems with radio frequency interference .

- Battery type: 2 AA alkaline batteries for mouse

- Mouse resolution : 800cpi

- Sensor detects movement on all kinds of surface,a* including wood, plastics, pants, etc… ( Highly

reflective surfaces like mirror or deep dark color may not work properly).

- The ergonomically designed shaped provides easy control for both right hand and left hand

- Works under Windows 98/98SE/Me/2000/XP

- The left, right and scroll wheel buttonscan be programmed to perform a variety of functions to

speed up daily tasks.

Part 2.0: System Requirements

. IBM PC or compatible system

Part 3.0: Preface

The functionality and performance requirements related to the mouse are defined in this specification.

Part 4.0: Version

- USB (1.1version) and PS/2 interface

Part 5.0: Physical characteristics and configuration

Item 5.1: Dimension

Mouse: 125mm(L) x 77mm(W) x 40.87mm(H)

Receiver: 80mm(L) x 59.5mm(W) x 25.85mm(H)

DR： Sam CHECK： APPD：

Mouse:

Receiver:

Item 5.2: Material

Mouse Body ABS

Beside face(3) Rubber paint

Wheel Rubber

Item 5.3: Finish: Texture

DR： Sam CHECK： APPD：
