Congratulations on purchasing the ZiiSound DSx Wireless

Subwoofer, a perfect complement to the ZiiSound series of

wireless speaker systems featuring SLAM (Symmetrically
Loaded Acoustic Module) Technology. Experience a whole

new definition of freedom in placement for that perfect

acoustic projection with our wireless systems.

Additional ZiiSound D5x, D3x or DSx shown here and throughout the user manual are
for illustration purposes only. Sold separately. Not included.

EN

For detailed product information, instructions or

to find out more about our speakers, visit

www.creative.com/speakers

Safety Instruction

Please read the following before using the Creative Products:

• Use a mains plug that is appropriate for your country or region.

• To be completely disconnected from the power input, the mains plug has to be disconnected
/detached from the mains.

• Disconnect the mains plug when the device is expected to be unused for several days.

Additional guidelines for wireless devices

• The short wave radio frequency signals of a wireless device may impair the operation of other
electronic and medical devices

• Switch off the device where it is prohibited. Do not use the device in medical facilities, aircraft,
refueling points, close to automatic doors, automatic fire alarms or other automatically controlled
devices

• Keep this device at least 20 cm from pacemakers and other medical devices. Radio waves may
impair the operation of pacemakers and other medical devices

4

5

Technical Specifications

• Input Rating: 100-240V~ 50/60Hz 300mA

• Operating Frequency : 5725 – 5850 Mhz

• Supported Speaker models : ZiiSound D5x , ZiiSound D3x

• Operating Range: Up to 30 meters (Measured in open space. Walls and structures may affect
range of device.)

Note: Compliance markings are located at the back of this product.

Compatibility Disclaimer

• Every electronic device is subjected to radio frequency (RF) interference from external sources.
These include the connection between linked ZiiSound D5x, D3x and wireless subwoofer.

• Creative will not be liable for any loss of data or leakage resulting from the use of these devices.

1

Product Overview / Connectivity Diagram

1

2

3

1

ZiiSound DSx LED Status Indicator LED lights up to indicate active wireless link status

2

SLAMTM Master driver Do not poke objects into these areas

SLAMTM Pressure drivers Do not poke objects into these areas

3
