Creative Notebook Travel Speaker User Manual
Notebook Travel Speaker
User Manual
0
Table of Content
1. Introduction USB 2 / 2.1 Channel Speakers 3
2. System Requirement and Installation 4
3. User Interface and Function Control 10
4. Feature Overview of Xear 3D Sound Technology 15
5. Product Application 17
6. FAQ & Technical Support 18
1
1.Introduction USB 2/2.1 Channel Speakers
This USB 2/2.1 channel Speakers is design for all kind of PC base products. It is USB
2.0 full speed compatible and utilizes USB bus power. No driver is needed for audio
playback on all mainstream OSs; therefore this device provides a truly plug-and-play
feature for external digital audio play back. Better yet, simply install Xear 3D Sound
USB audio driver, users can avail themselves of a much better virtual 5.1 CH
environment capable. Via 3 dimensional audio conversions of this technology,
Personalized and optimum 5.1 CH listening environment and experience is achieved.
Advantage of USB 2Ch Speakers:
¾Easy to replace “entry level” sound card solutions.
¾No more limitations on analog signal cable line.
¾Utilize USB bus power, no external adapter required.
¾All in one design, saving weight and easy to carry on.
¾Plug and play for any PC System reach maximum compatibility.
¾Digital audio sound solution fit next generation multi-media trend.
¾Greater than +100db SNR (Idle status) ensure “hiss-free” and high audio fidelity.
¾No problem on FCC test.
¾Getting world’s first USB 2 /2.1CH speaker, capable of providing virtual yet immersive
5.1 CH 3D surround sound.
¾More price competitive than other USB audio solutions of its kind.
¾User friendly and adjustable GUI for a tailor made listening environment.
¾Adjustable EQ(equalizer), compensating the inefficiency of the conventional
speakers.
¾Support +22db audio gain control to loudness output sound.
2
2.System Requirement and Installation
This device must be applied on USB specification products. And user should to confirm
that PC operation supports USB function, USB 1.1 or 2.0.
No external driver installed：
¾OS Support ：Win98SE, WinME, Win2000, WinXP, Mac OS 9.0 and 10.1
¾System recommended：use Intel
¾At least 64 MB RAM (Win98SE) or 128MB RAM (WinME, Win2000 and WinXP)
¾For good sound quality, please adjust your system’s H/W acceleration and Sample
rate conversion quality to Full and Best.
PII 350 MHz or AMD K6 450 above
Note: Some USB Host Controller may have problem with data stream package loss,
this will influence output audio data and make some discontinuous sound. But
this is very rare.
Sometime, when user plug USB speaker on PC system and OS cannot auto
change audio device to USB audio, please switch the audio device to USB
audio sound and audio devices properties in control panel.
3
Install Xear 3D sound audio driver：
¾OS Support ：Win98SE, WinME, Win2000, WinXP
¾System recommended：use Intel
PII 350 MHz or AMD K6 450 above
¾At least 64 MB RAM (Win98SE) or 128MB RAM (WinME, Win2000 and WinXP)
¾Support Direct sound 3D
Note: Windows OS has default USB driver support, but no support for HRTF 3D, EAX
or Virtual 5.1 CH sound effect. Thus, if user wants to enjoy these fancy
experiences must install C-Media Xear 3D sound audio driver.
Before users install C-Media Xear 3D sound audio driver, they must make sure
that USB Speakers have connected to PC system already.
If your PC system has more than one USB connect port, please remember
which one is connected for install, and next time when you plug USB speaker
to PC, you have to plug the same port for initialize the Xear 3D driver.
4
Xear 3D Sound Audio Driver Installation Step：
nTurn on PC system and connect USB speaker to PC system.
oPlease follow up the set up procedure and click “Next ” button to continue
installation.
5
pYou can Select install driver only or both driver and demo program then click “Next”
to continue installation.
qIf your System is WinXP, you may see a dialog box asking you about windows logo
issue, please click “Continue Anyway” to complete installation. And set up program
will continue install.
6
