Creative NOMAD JUKEBOX Getting Started

Getting Started

Getting Started

NOMAD Jukebox

NOMAD Jukebox

NOMAD Jukebox NOMAD Jukebox

Information in this document is subject to change without notice and does not represent a commitment on the part of Creative Technology Ltd. No part
of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any
purpose without the written permission of Creative Technology Ltd. The software described in this document is furnished under a license agreement
and may be used or copied only in accordance with the terms of the license agreement. It is against the law to copy the software on any other medium
except as specifically allowed in the license agreement. The licensee may make one copy of the software for backup purposes.

Copyright © 2001 by Creative Technology Ltd. All rights reserved.

Version 1.0
April 2001

Sound Blaster, the Sound Blaster logo, and the Creative logo are registered trademarks, and Sound Blaster Live! and Environmental Audio are
trademarks of Creative Technology Ltd. in the United States and/or other countries.
NOMAD is a registered trademark of Aonix and is used by Creative Technology Ltd. and/or its affiliates under license.
CDDB-Enabled, CDDB, CDDB
Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
MPEG Layer-3 audio compression technology licensed from Fraunhofer IIS and Thomson Multimedia.
Pentium is a registered trademark of Intel Corporation.
Macintosh is registered trademark and Mac and Power are trademarks of Apple Computer, Inc.
All other brand and product names listed are trademarks or registered trademarks of their respective holders.
All specifications subject to change without prior notice. Use of this product is subject to the limited warranty. Actual contents may differ slightly from
those pictured.
This product is designed to assist you in reproducing material for which you own the copyright or are authorized to copy by the copyright owner or by
exemption in applicable law. Unless you own the copyright or have such authorization, you may be violating copyright law and may be subject to
payment of damages and other remedies. If you are uncertain about your rights, you should contact your legal advisor.

2

and the CDDB Logo are trademarks of CDDB, Inc.

Creative End-User Software License Agreement

PLEASE READ THIS DOCUMENT CAREFULLY BEFORE INSTALLING THE SOFTWARE. BY INSTALLING AND USING THE SOFTWARE, YOU AGREE TO BE BOUND BY THE TERMS OF
THIS AGREEMENT. IF YOU DO NOT AGREE TO THE TERMS OF THE AGREEMENT, DO NOT INSTALL OR USE THE SOFTWARE. PROMPTLY RETURN, WITHIN 15 DAYS, THE
SOFTWARE, ALL RELATED DOCUMENTATION AND ACCOMPANYING ITEMS TO THE PLACE OF ACQUISITION FOR A FULL REFUND.

This is a legalagreement between you andCreative Technology Ltd.
and its subsidiaries(“Creative”). This Agreement states the terms and
conditions upon which Creative offers to license the software sealed
in the disk package together with all related documentation and
accompanying items including, but not limited to, the executable
programs, drivers, libraries and data files associated with such
programs (collectively, the “Software”).

LICENSE

1. Grant of License

The Software is licensed, not sold, to you for use only under the
terms of this Agreement. You own the disk or other media on
which the Software isoriginally or subsequently recordedor fixed;
but, as between you and Creative (and, to the extent applicable, its
licensors), Creative retains all title to and ownership of the
Software and reserves all rights not expressly granted to you.

2. For Use on a Single Computer

The Software may be used only on a single computer by a single
user at any time.You may transfer the machine-readable portion of
the Software from one computer to another computer, provided
that (a) the Software (including any portion or copy thereof) is
erased from the first computer and (b) there is no possibility that
the Software will be used on more than one computer at a time.

3. Stand-Alone Basis

You may use the Software only on a stand-alone basis, such that
the Software and the functions it provides are accessible only to
persons who are physically present at the location of the computer
on which the Software is loaded. You may not allow the Software
or its functions to be accessed remotely, or transmit all or any
portion of the Software through any network or communication
line.

4. Copyright

The Software is owned by Creative and/or its licensees and is
protected by United States copyright laws and international treaty
provisions. You may not remove the copyright notice from any
copy of the Software or any copy of the written materials, if any,
accompanying the Software.

5. One Archival Copy

You may make one (1) archival copy of the machine-readable
portion of the Software for backup purposes only in support of
your use of the Software on a single computer, provided that you
reproduce on the copy all copyright and other proprietary rights
notices included on the originals of the Software.

Version 2.4, June 2000

6. No Merger or Integration

You may not merge any portion of the Software into, or integrate
any portion of the Software with, any other program, except to the
extent expressly permitted by the laws of the jurisdiction where
you are located. Any portion of the Software merged into or
integrated with another program, ifany, will continue to be subject
to the terms and conditions of this Agreement, and you must
reproduce on the merged or integrated portion all copyright and
other proprietary rights notices included in the originals of the
Software.

7. Network Version

If you have purchased a “network” version of the Software, this
Agreement applies to the installation of the Software on a single
“file server”. It may not be copied onto multiple systems. Each
“node” connected to the “file server” must also have its own
license of a “node copy” ofthe Software, which becomes a license
only for that specific “node”.

8. Transfer of License

You may transfer your license of the Software, provided that (a)
you transfer all portions of the Software or copies thereof, (b) you
do not retain any portion of the Software or any copy thereof, and
(c) the transferee reads and agrees to be bound by the terms and
conditions of this Agreement.

9. Limitations on Using, Copying, and Modifying the Software

Except to the extent expressly permitted by this Agreement or by
the laws of the jurisdiction where you acquired the Software, you
may not use, copy or modify the Software. Nor may you sub­license any of your rights under this Agreement. You may use the
Software for your personal use only, and not for public
performance or for the creation of publicly displayed videotapes.

10.Decompiling, Disassembling, or Reverse Engineering

You acknowledge that the Software contains trade secrets and
other proprietary information of Creative and its licensors. Except
to the extent expressly permitted by this Agreement or by the laws
of the jurisdiction where you are located, you may not decompile,
disassemble or otherwisereverse engineer the Software,or engage
in any other activities to obtain underlying information that is not
visible to the user in connection with normal use of the Software.

11.For Software with CDDB features

This package contains software from CDDB, Inc.of Berkeley
California ("CDDB"). The software from CDDB (the "CDDB
Client") enables this application to do online disc identification
and obtain music-relatedinformation, including name, artist, track
and title information ("CDDB Data")from online servers ("CDDB

Servers") and to perform other functions.
You agree that you will use CDDB Data, the CDDB Client and
CDDB Servers for your own personal non-commercial use only.
You agree not to assign, copy, transfer or transmit the CDDB
ClientoranyCDDBDatatoanythirdparty.YOUAGREENOT
TO USE OR EXPLOITCDDB DATA, THE CDDB CLIENT, OR
CDDB SERVERS, EXCEPT AS EXPRESSLY PERMITTED
HEREIN.
You agree that your non-exclusive license to use the CDDB Data,
the CDDB Client and CDDB Servers will terminate if you violate
these restrictions.If your licenseterminates, youagree to ceaseany
and all use of the CDDB Data, the CDDB Client and CDDB
Servers. CDDB reserves all rights in CDDB Data, the CDDB
Client and the CDDB Servers, including all ownership rights. You
agree that CDDB, Inc. may enforceits rights under thisAgreement
against you directly in its own name.
The CDDBClient and each item ofCDDB Data arelicensed to you
"AS IS."CDDB makes norepresentations or warranties,express or
implied, regarding the accuracy of any CDDB Data from in the
CDDB Servers. CDDB reserves the right to delete data from the
CDDB Servers or to change data categories for any cause that
CDDB deems sufficient. No warranty is made that the CDDB
Client or CDDB Servers are error-free or that functioning of
CDDB Client or CDDB Servers will be uninterrupted. CDDB is
not obligated to provide you with any new enhanced or additional
data types or categories that CDDB may chose to provide in the
future.
CDDB DISCLAIMS ALL WARRANTIES EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, TITLE AND NON­INFRINGEMENT. CDDB does not warrantthe resultsthat willbe
obtained by your use of the CDDB Clientor any CDDB Server. IN
NO CASE WILL CDDB BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTIAL DAMAGES OR FOR
ANY LOST PROFITS, OR LOST REVENUES.

In particular, you agree not for any purpose to transmit the
Software or display the Software's object code on any computer
screen or to make any hardcopy memory dumps of the Software's
object code. If you believe you require information related to the
interoperability of theSoftware with other programs, you shall not
decompile or disassemble theSoftware to obtain suchinformation,
and you agree to request such information from Creative at the
address listed below. Uponreceiving such a request, Creative shall

determine whether you require such information for a legitimate
purpose and, if so, Creative will provide such information to you
within a reasonable time and on reasonable conditions.
In any event, you will notify Creative of any information derived
from reverse engineering or such other activities, and the results
thereof will constitute the confidential informationof Creative that
may be used only in connection with the Software.

TERMINATION

The license granted to you is effective until terminated. You may
terminate it at any time by returning the Software (including any
portions or copies thereof) to Creative.The license will alsoterminate
automatically without any notice from Creative if you fail to comply
with any term or condition of this Agreement. You agree upon such
termination to return the Software (including any portions or copies
thereof) to Creative. Upon termination, Creative may also enforce any
rights provided by law. The provisions of this Agreement that protect
the proprietary rights of Creative will continue in force after
termination.

LIMITED WARRANTY

Creative warrants, as the sole warranty, that the disks on which the
Software is furnished will be free of defects, as set forth in the
Warranty Card or printed manual included with the Software. No
distributor, dealer orany other entity or personis authorized to expand
or alter this warranty or any other provisions of this Agreement. Any
representation, other than the warranties set forth in this Agreement,
will not bind Creative.

Creative doesnot warrant that the functions contained in the Software
will meet your requirements or thatthe operation of the Software will
be uninterrupted, error-free or free from malicious code. For purposes
of this paragraph, “malicious code” means any program code
designed to contaminate other computer programs or computer data,
consume computer resources, modify, destroy, record, or transmit
data, or in some other fashion usurp the normal operation of the
computer, computer system, or computer network, including viruses,
Trojan horses, droppers, worms, logicbombs, and the like. EXCEPT

AS STATED ABOVE IN THIS AGREEMENT, THE
SOFTWARE IS PROVIDED AS-IS WITHOUT WARRANTY
OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. CREATIVE IS NOT
OBLIGATED TO PROVIDE ANY UPDATES, UPGRADES OR
TECHNICAL SUPPORT FOR THE SOFTWARE.

Further, Creative shall not be liable for the accuracy of any
information provided by Creative or third party technical support
personnel, orany damagescaused, either directly or indirectly, byacts
taken or omissions made by you as a result of such technical support.

You assume full responsibility for the selection of the Software to
achieve your intended results, and for the installation, use and results

obtained from the Software. You also assume the entire risk as it
applies to the quality and performance of the Software. Should the
Software prove defective, you (and not Creative, or its distributors or
dealers) assume the entire cost of all necessary servicing, repair or
correction.

This warranty gives you specific legal rights, and you may also have
other rights which vary from country/state to country/state. Some
countries/states do not allow the exclusion of implied warranties, so
the above exclusion may not apply to you. Creative disclaims all
warranties of any kind if the Softwarewas customized, repackaged or
alteredinanywaybyanythirdpartyotherthanCreative.

LIMITATION OF REMEDIES AND DAMAGES
THE ONLY REMEDYFOR BREACH OF WARRANTY WILL
BE THAT SET FORTH IN THE WARRANTY CARD OR
PRINTED MANUALINCLUDED WITH THE SOFTWARE. IN
NO EVENT WILL CREATIVE OR ITS LICENSORS BE
LIABLE FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OR FOR ANY LOST
PROFITS, LOST SAVINGS, LOST REVENUES OR LOST
DATA ARISINGFROM OR RELATINGTO THE SOFTWARE
OR THIS AGREEMENT, EVEN IF CREATIVE OR ITS
LICENSORS HAVE BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES. IN NO EVENT WILL CREATIVE’S
LIABILITY OR DAMAGES TO YOU OR ANY OTHER
PERSON EVER EXCEED THE AMOUNT PAID BY YOU TO
USE THE SOFTWARE, REGARDLESS OF THE FORM OF
THE CLAIM.

Some countries/states do not allow the limitation or exclusion of
liability for incidental or consequential damages, so the above
limitation or exclusion may not apply to you.

PRODUCT RETURNS

If you must ship the software to Creative or an authorized Creative
distributor or dealer, you must prepay shipping and either insure the
software or assume all risk of loss or damage in transit.

U.S. GOVERNMENT RESTRICTED RIGHTS

All Software and related documentation are provided with restricted
rights. Use, duplication or disclosure by the U.S. Government is
subject to restrictions as set forth in subdivision (b)(3)(ii) of the
Rights in Technical Data and Computer Software Clause at 252.227-

7013. If you are sub-licensing or using the Software outside of the
United States, you will comply with the applicable local laws of your
country, U.S. export control law, and the English version of this
Agreement.

CONTRACTOR/MANUFACTURER

The Contractor/Manufacturer for the Software is:

Creative Technology Ltd

31, International Business Park
Creative Resource
Singapore 609921

GENERAL

This Agreement is binding on you as well as your employees,
employers, contractors and agents, and on any successors and
assignees. Neither the Software nor any information derived
therefrom may be exported except in accordance with the laws of the
U.S. or other applicable provisions. This Agreement is governed by
the laws of the State of California (except to the extent federal law
governs copyrights and federally registered trademarks). This
Agreement is the entire agreement between us and supersedes any
other understandings or agreements, including, but not limited to,
advertising, with respect to the Software. If any provision of this
Agreement is deemed invalid or unenforceable by any country or
government agency having jurisdiction, that particular provision will
be deemed modified to the extent necessary to make the provision
valid and enforceable, and the remaining provisions will remain in
full force and effect.

For questions concerning this Agreement, please contact Creative at
the address stated above. For questions on product or technical
matters, contact the Creative technical support center nearest you.

ADDENDUM TO THE MICROSOFT SOFTWARE LICENSE
AGREEMENT (WINDOWS 95)

IMPORTANT: By usingthe Microsoft software files (the “Microsoft

Software”) provided with this Addendum, you are agreeing to be
bound bythe following terms.If you do not agreeto be bound by these
terms, you may not use the Microsoft Software.

The Microsoft Software is provided for the sole purpose of replacing
the corresponding files provided with a previously licensed copy of
the Microsoft software product identified above (“ORIGINAL
PRODUCT”). Uponinstallation, the MicrosoftSoftware files become
part of the ORIGINAL PRODUCT and are subject to the same
warranty and license terms and conditions as the ORIGINAL
PRODUCT. If you do not have a valid license to use the ORIGINAL
PRODUCT, you may not use the Microsoft Software. Any other use
of the Microsoft Software is prohibited.

SPECIAL PROVISIONS APPLICABLE TO THE EUROPEAN
UNION

IF YOU ACQUIRED THE SOFTWARE IN THE EUROPEAN
UNION (EU), THE FOLLOWING PROVISIONS ALSO APPLY
TO YOU. IF THERE IS ANY INCONSISTENCY BETWEEN THE
TERMS OF THE SOFTWARE LICENSE AGREEMENT SETOUT
EARLIER AND IN THE FOLLOWING PROVISIONS, THE
FOLLOWING PROVISIONS SHALL TAKE PRECEDENCE.

DECOMPILATION

You agree not for any purpose to transmit the Software or display the
Software’s object code on any computer screen or to make any hard
copy memorydumps ofthe Software’s objectcode. If you believe you
require informationrelated to theinteroperability of the Software with
other programs, you shall not decompile or disassemblethe Software

to obtain suchinformation, and you agree to request such information
from Creative at the address listed earlier. Upon receiving such a
request, Creative shall determine whether you require such
information for a legitimate purpose and, if so, Creative will provide
such information to you within a reasonable time and on reasonable
conditions.

LIMITED WARRANTY
EXCEPT AS STATED EARLIERIN THIS AGREEMENT, AND
AS PROVIDED UNDER THE HEADING “STATUTORY
RIGHTS”, THE SOFTWARE IS PROVIDED AS-IS WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY
IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY, QUALITY AND FITNESS FOR A
PARTICULAR PURPOSE.

LIMITATION OF REMEDY AND DAMAGES
THELIMITATIONSOFREMEDIESANDDAMAGESINTHE
SOFTWARE LICENSE AGREEMENT SHALL NOT APPLY
TO PERSONAL INJURY (INCLUDING DEATH) TO ANY
PERSON CAUSED BY CREATIVE’S NEGLIGENCE AND
ARE SUBJECT TO THE PROVISION SET OUT UNDER THE
HEADING “STATUTORY RIGHTS”.

STATUTORY RIGHTS

Irish law provides that certain conditions and warranties may be
implied in contracts for the sale of goods and in contracts for the
supply of services. Such conditions and warranties are hereby
excluded, to the extent such exclusion, in the context of this
transaction, is lawful under Irish law. Conversely, suchconditions and
warranties, insofar as they may not be lawfully excluded, shall apply.

Accordingly nothing in this Agreement shallprejudice any rights that
you may enjoy by virtue of Sections 12, 13, 14 or 15 of the Irish Sale
of Goods Act 1893 (as amended).

GENERAL

This Agreement is governed by the laws of the Republic of Ireland.
The local language version of this agreement shall apply to Software
acquired in the EU. This Agreement is the entire agreement between
us, and you agree that Creative will not have any liability for any
untrue statement or representation made by it, its agents or anyone
else (whether innocently or negligently) upon which you relied upon
entering this Agreement, unless such untrue statement or
representation was made fraudulently.

Safety & Regulatory Information

The following sections contain notices for various countries:

CAUTION: This device is intended to be connected by the user to a
CSA/TUV/UL certified/listed IBM AT or compatible personal
computers in the manufacturer’s defined operator access area. Check
the equipment operating/installation manual and/or with the
equipment manufacturer to verify/confirm if your equipment is
suitable for devices to be connected to it.

ATTENTION: Ce périphérique est destiné à être connecté par
l’utilisateur àun ordinateur IBM AT certifiéou listé CSA/TUV/UL ou
compatible, à l’intérieur de la zone d'accès définie par le fabricant.
Consulter le mode d’emploi/guide d'installation et/ou le fabricant de
l’appareil pour vérifier ou confirmer qu'il est possible de connecter
d'autres périphériques à votre sytème.

Notice for the USA

FCC Part 15: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, this notice is not a guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning theequipment off and
on, the user is encouraged to try one or more of the following
measures:

❑ Reorient or relocate the receiving antenna.
❑ Increase the distance between the equipment and receiver.
❑ Connect the equipment to an outlet on a circuit different from

that to which the receiver is connected.

❑ Consult the dealer or an experienced radio/TV technician.

Caution

To comply with the limits for the Class B digital device, pursuant to
Part 15 of the FCC Rules, this device must be installed in computer
equipment certified to comply with the Class B limits.

All cables used to connect the computer and peripherals must be
shielded and grounded. Operation with non-certified computers or
non-shielded cables may result in interference to radio or television
reception.

Any changes or modifications not expressly approved by the grantee
of this device could void the user’s authority to operate the device.

Modifications

Notice for Canada

This apparatus complies with the Class “B” limits for radio
interference as specified in the Canadian Department of
Communications Radio Interference Regulations.

Cet appareil est conformeaux normes de CLASSE“B” d’interférence
radio tel que spécifié par le Ministère Canadien des Communications
dans les règlements d’interférence radio.

Compliance

This product conforms to the following Council Directive:

❑ Directive 89/336/EEC, 92/31/EEC (EMC), 73/23/EEC (LVD)

Declaration of Conformity

According to the FCC96 208 and ET95-19,

Manufacturer/Importer’s Name:Creative Labs, Inc.

Manufacturer/Importer’s Address: 1901 McCarthy Boulevard

declares under its sole responsibility that the product

Trade Name: Creative Labs

Model Numbers: DAP-6G01/DAP-6G02

has been tested according to the FCC / CISPR22/85
requirement for Class B devices and found compliantwith
the following standards:

EMI/EMC: ANSI C63.4 1992, FCC Part 15 Subpart B

This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This devicemust accept any interferencereceived, including

Ce matériel est conforme à la section 15 des régles FCC.
Son Fonctionnement est soumis aux deux conditions suivantes:

1. Le matériel ne peut étre source D’interférences et

2. Doit accepter toutes les interférences reques, Y compris

Supplementary Information:
DAP-6G01 == Standard Model
DAP-6G02 == Europe Model

DS-6401 is the docking station model.

Complies with Canadian ICES-003 Class B.

interference that may cause undesirable operation.

celles pouvant provoquer un fonctionnement indésirable.

Milpitas, CA. 95035
United States
Tel: [phone]

Compliance Manager

Creative Labs, Inc.

March 30, 2000

Contents

Note to Users.................................................................................... ix

Introduction ......................................................................................x

Software .....................................................................................................................................................x

System Requirements...............................................................................................................................xi

Windows......................................................................................................................................xi

Macintosh ....................................................................................................................................xi

Handling Instructions ..............................................................................................................................xii

Proper Care and Usage .............................................................................................................xiii

Health Hazards..........................................................................................................................xiii

Your NOMAD Jukebox ..................................................................... 1

1

Location of Controls..................................................................................................................................2

2 Setting Up NOMAD Jukebox............................................................ 5

Step 1: Insert Batteries............................................................................................................................... 5

Step 2: Connect NOMAD Jukebox to Your PC or Mac..........................................................................6

Step 3: Run Jukebox Tutorial....................................................................................................................6

Step 4: Install Software..............................................................................................................................7

Windows.......................................................................................................................................7

Macintosh ..................................................................................................................................... 7

Step 5: Verify NOMAD Jukebox Driver Installation .............................................................................. 8

Windows.......................................................................................................................................8

Macintosh ..................................................................................................................................... 8

Step 6: Connect Headphones ....................................................................................................................9

Step 7: Select and Play a Track................................................................................................................. 9

3 Using Your NOMAD Jukebox.......................................................... 10

Screen Icons .............................................................................................................................................10

Starting NOMAD Jukebox .....................................................................................................................10

Navigating Music Library Screens ......................................................................................................... 11

Navigating to Lower Level Screens.......................................................................................... 11

Navigating to Upper Level Screens .......................................................................................... 12

Music Library...........................................................................................................................................13

Searching for an Album, Artist, Genre, or Play List................................................................13

Queueing an Album...................................................................................................................14

Queueing a Track.......................................................................................................................14

Viewing Details..........................................................................................................................15

Previewing a Track .................................................................................................................... 16

Removing Albums, Tracks or Play List....................................................................................16

Playing Tracks/Albums...........................................................................................................................17

Skipping Forward/Backward.....................................................................................................17

Seek Mode.................................................................................................................................. 17

Setting Play Mode...................................................................................................................... 17

Saving an Active Queue List.....................................................................................................18

EAX and System Menu...........................................................................................................................19

Adjusting Parametric EQ...........................................................................................................19

Adjusting Spatialization Settings ..............................................................................................19

Adjusting Environmental Audio ............................................................................................... 20

Using Playback Speed ...............................................................................................................20

Creating and Saving an Audio Recording ................................................................................ 21

Listening to an Audio Recording ..............................................................................................23

Saving an Active Queue List.....................................................................................................24

Deleting Library Items...............................................................................................................25

Viewing System Information.....................................................................................................26

Adjusting System Preferences...................................................................................................26

4 Using Your NOMAD Jukebox Software in Windows ....................... 27

PlayCenter 2............................................................................................................................................. 27

Changing Skins ..........................................................................................................................29

Managing Files ........................................................................................................................................29

Converting and Transferring Files ............................................................................................29

Deleting Files .............................................................................................................................31

Creating Play Lists.....................................................................................................................31

Connecting to the NOMAD Web Site....................................................................................................32

Upgrading NOMAD Jukebox’s Firmware............................................................................... 32

Environmental Audio ..............................................................................................................................32

5 Using SoundJam™ MP with Macintosh OS.................................... 33

SoundJam MP and NOMAD Jukebox...................................................................................................34

NOMAD Jukebox WINDOW ..................................................................................................34

Opening SoundJam..................................................................................................................................35

SoundJam Controls....................................................................................................................35

Converting CD Audio to MP3................................................................................................................36

A Technical Specifications ............................................................... 37

NOMAD Jukebox (DAP-6G01).............................................................................................................37

B Troubleshooting ............................................................................. 39

Note to Users

In this manual, all references to "NOMAD Jukebox" refer to the NOMAD Jukebox C.

Note to Users ix

Introduction

Your Creative NOMAD Jukebox is the latest USB-compatible, multi-format portable audio player/recorder.

This new, light-weight (14 oz.) digital audio player is the size of a portable CD player and features high-capacity
storage—6 GB of built-in storage—that holds an entire music collection (150 albums). Its features include a Line­In connection for analog recording from external sources and two Line-Out connections for connecting a four­speaker system such as Cambridge SoundWorks FourPointSurround FPS2000 Digital.

NOMAD Jukebox features an onboard, real-time digital signal processor (DSP) and real-time effects processor
for superior audio playback and customization. A Headphone-Out jack supports headphone spatialization and
equalizer effects. This SDMI-capable portable digital audio player supports multiple formats including MP3,
WAV and other future format standards. The NOMAD Jukebox supports downloadable features including new
effects algorithms, security features, and auto playlist generators.

Software

NOMAD Jukebox includes:

Creative PlayCenter 2 for managing your favorite digital audio files on your computer and NOMAD

❑

Jukebox. It is also an integrated encoder for ripping audio CD tracks into compressed digital audio files.
SoundJam MP the ultimate music center for your Mac, that manages your digital audio files as well as

❑

converts almost any kind of sound file into MP3 files.
More than 20 hours of preloaded music and audio book content from Naxos and Soundbuzz.com.

❑

You can also download more MP3 files through worldwide web sites or online services, and play them back on
your NOMAD Jukebox.

Introduction x

System Requirements

The NOMAD Jukebox is supported in both Windows and Macintosh environments.

Windows

Macintosh

The minimum system requirements for NOMAD Jukebox are:

Microsoft® Windows® 98 and Windows® 2000

❑

200 MHz or higher Pentium® or AMD K6 200

❑

(Pentium II or AMD K6-2 or better recommended for MP3 encoding)
SVGA graphics adapter (256 colors, 640 x 480)

❑

Internet connection for Internet content downloading or CDDB support

❑

(user is responsible for charges incurred)
32 MB RAM (64 MB recommended)

❑

USB port

❑

30 MB free hard disk space (more for audio file storage)

❑

Installed mouse

❑

CD-ROM drive with digital audio extraction support

❑

The minimum system requirements for NOMAD Jukebox are as follows:

Mac® OS version 8.6 or higher

❑

iMac™, G3 or higher

❑

Internet connection for Internet content downloading or CDDB support

❑

(any expenses incurred are the responsibility of the user)
32 MB RAM (64 MB recommended)

❑

USB port

❑

USB Manager, version 1.2 or higher

❑

12 MB free hard disk space (more for audio file storage)

❑

Installed mouse

❑

CD-ROM drive with digital audio extraction support

❑

Introduction xi

Handling Instructions

Avoid severe impact on the NOMAD Jukebox

Do not drop the Jukebox on a solid surface or drop a heavy object on the Jukebox.

❑

Prevent water from entering the NOMAD Jukebox

If the Jukebox comes into contact with water, dry it immediately with a dry cloth.

❑

If the Jukebox becomes wet, remove the batteries. Allow the Jukebox and components to dry completely

❑

before re-assembling.
If the Jukebox is not functioning, call Technical Support.

❑

Storing the NOMAD Jukebox

Avoid storing NOMAD Jukebox where there is high humidity, strong magnetic fields, or high heat.

❑

Turnin g Off Your NOMAD Jukebox

Cleaning NOMAD Jukebox

Using and Replacing Batteries

Be sure that NOMAD Jukebox is properly turned off before detaching its power cable.

Disconnect the power adapter from the wall outlet or power source before cleaning.

❑

Do not use liquid or aerosol cleaners.

❑

Use a damp cloth for cleaning.

❑

Do not dispose of the batteries in fire, recharge, put in backwards, and mix with used or other battery
types—improper use of batteries may lead to explosion or leakage and cause personal injury.

DO NOT:

Use the NOMAD Jukebox to recharge batteries other than the type specified. Attempting to recharge

❑

batteries such as normal, heavy duty, or alkaline batteries, or mixing different types of batteries, such as
rechargeable alkaline, may lead to explosion or leakage and cause personal injury.
Use external battery chargers to charge your batteries. Charging your batteries in this way may damage your

❑

batteries and your Jukebox.
Immerse the batteries in water.

❑

Repair or disassemble the batteries.

❑

Drop the batteries or subject them to extreme force.

❑

Short-circuit the batteries—this may result in skin burns.

❑

Introduction xii

DO:

Insert the batteries according to the polarity markings on the product; see the diagram on the bottom of the

❑

battery compartment for proper positioning.
Keep the batteries in a cool and dry place, away from heat, moisture, and metal objects when not in use.

❑

Handle leaking batteries with rubber gloves. Avoid direct contact with skin or eyes. If this happens, wash

❑

the skin and flush the eyes thoroughly with clean water—seek medical attention.
Dispose of used batteries as required by local ordinances or regulations.

❑

Keep the batteries out of reach of children.

❑

Servicing

Power Sources

Proper Care and Usage

Health Hazards

Inhalation

Skin Contact

Eye Contact

Do not attempt to service any part of the product yourself. Servicing should only be done by qualified
service personnel.

The product should be operated only with the power adapter included. If you are not certain of the power supply
type in your home, consult your product dealer.

If you are using batteries with your product, refer to the operating instructions included in your documentation and
markings, if any, on the product.

Do not use any object to probe the openings of the product—this may result in electric shock or fire, and can

❑

also damage the product.
Do not spill liquid of any kind on the product.

❑

Inhaling the fumes from the contents of an exposed, damaged, or leaking battery may cause respiratory irritation.
If this happens, breathe in fresh air and seek medical attention.

Direct skin contact with the contents of a damaged battery may cause skin irritation and/or chemical burns.
Remove contaminated clothing and wash the affected skin area with soap and water. If a chemical burn or the
irritation persists, seek medical attention.

If the contents of a damaged battery comes into contact with the eyes, severe irritation and chemical burns may
result. Flush the eyes thoroughly with clean water immediately for at least 15 minutes, lifting the upper and lower
eyelids while doing so, until no evidence of the chemical remains. Seek medical attention.

Introduction xiii

Your NOMAD Jukebox

Your NOMAD Jukebox includes the following:

Items that come with your
NOMAD Jukebox package
may differ depending on the
country in which you
purchased the package.

NOMAD Jukebox

USB cable

Software installation CD

4 rechargeable AA

NiMH batteries

Power adapter and cable

1

Quick Start guide

For a list of the latest accessories, visit NOMAD World at http://www.nomadworld.com.

Your NOMAD Jukebox 1

Location of Controls

Top

Top

TopTop

Screen Title

The diagrams may differ
slightly from the actual
NOMAD Jukebox.
Features and operations
remain the same.

Soft buttons

Press to execute the function
listed directly above each of
them.

Library button

Press to switch between
LIBRARY CATEGORIES
screen and ACTIVE QUEUE
LIST screen.

EAX and System button

Press to display the full list of
EAX & System Settings
which can be adjusted.

Skip Backward button

Press to restart audio at the start
of the previous track in the Play
List. The PlayPointer icon
indicates the playing track.
Hold down the button to enable
the Seek function and search
backward to any point in the
memory.

Power On/Play button

Press and hold for four seconds to turn on
the Jukebox. Also, press once to
immediately play a selected track. A track
selected from the Music Library is placed
at the top of the ACTIVE QUEUE LIST; a
track selected from the ACTIVE QUEUE
LIST advances the list to that track and
begins playback.

Main Info

Soft button
functions

Scroll Up/Down buttons

Screen navigation—press
to move up or down
through the items, press
and hold to move rapidly
through the list. Also, use
to increment character in

Skip Forward button

Restart audio at the beginning of the
next track in the Play List.
Hold down the button to enable the
Seek function and search forward to
any point in the memory.

Stop button

Press once to pause playback. Press
again to stop playback. The PlayPointer
returns to the beginning of the track. Press
the Play button to resume playback.

search/save operation.

Your NOMAD Jukebox 2

Line Out Jacks 1 and 2

Use for a four-speaker system
such as Creative Cambridge
SoundWorks FourPointSurround.

Line In Jack

Connects to an external
device for recording to
NOMAD Jukebox.

USB Port

Power Jack

Connects to the power adapter.
NOMAD Jukebox recharges the
NiMH batteries if the batteries
are installed and the adapter is
connected to an outlet.

Headphones
Jack

Lock switch

While in the ON position,
the control buttons and
Volume Adjuster cannot be
operated.

Volume Control

Adjusts audio volume through the
headphones.
Note: To control the playback volume of
speakers connected to NOMAD Jukebox
using Line Out Jacks 1 and 2, adjust the
volume control of the speakers instead.

Your NOMAD Jukebox 3
