WORK WINE RACK 36 BOTTLE
HARDWARE
Thank you for purchasing the Work Wine Rack 36
Bottle. This page lists all the contents included in the
box. Please take time to identify the hardware as well as
the individual components of this product. As you
unpack and prepare for assembly, place the contents on
a carpeted or padded area to protect them from damage.
ASSEMBLY
top leg
4 - threaded
connectors
24 - plug
brackets
Missing hardware? Please call
800.606.6387 for replacements.
24 - socket
brackets
COMPONENTS
4 - top legs 4 - bottom legs 6 - wine rack
shelves
NOTE: Make sure
feet are facing down
as shown
NOTE: Make sure
wine rack shelf
faces up as shown
plug
bracket
4 - feet
socket
bracket
groove
A
threaded
connector
bottom leg
wine rack
shelf
B
foot
1 A) Attach top leg to bottom leg with 1 threaded
connector. Turn top leg counterclockwise to
secure.
B) Attach 1 foot to bottom leg by turning each
counterclockwise to secure. Repeat for remaining
top and bottom legs.
Made in Taiwan - r03 Page 1 of 2
Customer Service 800.967.6696 | Latest instructions available at www.crateandbarrel.com
2 A) Fit 1 plug bracket and 1 socket bracket onto groove of
each assembled leg as shown. Make sure brackets snap-fit
together.
B) Fit assembled legs into corresponding holes of 1 wine rack
shelf. Slide wine rack shelf over brackets and press down
firmly to secure. Repeat steps for 4 wine rack shelves.
B
A
WORK WINE RACK 36 BOTTLE
plug
bracket
socket
bracket
groove
wine rack
shelf
3 A) Positioned assembled unit upright. Attach 1 plug
bracket and 1 socket bracket to groove of each
assembled leg as shown.
B) Fit assembled legs into corresponding holes of
remaining wine rack shelf. Slide wine rack shelf over
brackets.
Assembly is now complete.
CLEANING AND CARE
Clean surfaces with a dry soft cloth. Do not
use abrasive cleaners.
Made in Taiwan - r03
Customer Service 800.967.6696 | Latest instructions available at www.crateandbarrel.com
Page 2 of 2
