Crate & Barrel Notch Storage Cart Assembly Instruction
NOTCH STORAGE CART
ASSEMBLY HARDWARE
Thank you for purchasing the Notch Storage Cart. This
page lists all the contents included in the box. Please
take time to identify the hardware as well as the individual
components of this product. As you unpack and prepare
for assembly, place the contents on a carpeted or
padded area to protect them from damage.
Note: 2 people are required to safely assemble this product.
COMPONENTS
6 - small
screws
5 - cams 4 - shelf
2 - casters 2 - lock
16 - medium
screws
5 - cam
screws
casters
8 - large
screws
4 - spring
washers
5 - cam
covers
4 - small
bolts
4 - flat
washers
Missing hardware?
Please call 800.606.6387
for replacements.
4 - large
bolts
pins
TOOLS REQUIRED
phillips head screwdriver
(We reccomend the use of hand tools instead of power tools)
ASSEMBLY
1 - top panel
1- exterior
panel
1 - back
panel
Made in Vietnam - r06 Page 1 of 3
Customer Service 800.967.6696 | Latest instructions available at www.crateandbarrel.com
1 - bottom
panel
1- interior
panel
1 - small
shelf
1 - front
panel
1 - door
front
1 - large
shelf
side
NOTE: Make sure arrows
on each cam points toward
nearest edge with holes
1 A) Insert 3 cams into side panel as shown.
B) Insert 2 cams into interior panel as shown. Make sure
arrows on each cam points toward the nearest edge with
holes.
panel
interior
panel
NOTCH STORAGE CART
NOTE: Do not over
tighten cam screws
A
top panel
B
front panel
C
back panel
2 A) Insert 2 cam screws into top panel as shown.
B) Insert 1 cam screw into front panel as shown.
C) Insert 2 cam screws into back panel as shown.
Secure, but do not over tighten, cam screws using a
phillips head screwdriver.
front panel
interior
panel
3 Fit cam screw of front panel into corresponding
hole of interior panel. With a screwdriver, turn the cam
clockwise until it securely engages the cam screw.
back panel
interior
panel
exterior panel
4 Fit cam screws of back panel into corresponding
holes of interior panel and exterior panel. Secure all
cams.
top panel
5 Place top panel face down onto a clean, padded
surface. With the assistance of another adult, fit preassembled dowels of assembled unit into corresponding
holes of top panel as shown. Secure top panel with 4
flat washers, 4 spring washers and 4 large bolts.
Made in Vietnam- r06 Page 2 of 3
Customer Service 800.967.6696 | Latest instructions available at www.crateandbarrel.com
