GALERIE COFFEE TABLE
Thank you for purchasing the Galerie Coffee Table. This
page lists all the contents included in the box. Please
take time to identify the hardware as well as the individual
components of this product. As you unpack and prepare
for assembly, place the contents on a carpeted or padded
area to protect them from damage.
Note: 2 people are required to safely assemble this
product.
COMPONENTS
1 - top
1 - shelf
4 - legs
Made in China - r02
HARDWARE
8 - long bolts 8 - washers8 - short bolts
Missing hardware? Please call
4 - brackets
800.606.6387 for replacements.
TOOLS REQUIRED
Allen wrench (included)
x 2
1 Place top face down on a padded surface. Loosely attach
2 legs with 2 short bolts per leg as shown. Make sure holes
and notches on each leg faces inward. Do not fully tighten the
bolts.
Page 1 of 2
Customer Service 800-967-6696 | http://www.crateandbarrel.com
GALERIE COFFEE TABLE
2 With the assistance of another adult, turn top
assembly on its side. Fit slots of middle shelf and
bottom shelf into corresponding slots on legs as shown.
x 4
4 With the assistance of another adult, turn table
assembly upside down. Attach 1 bracket at each leg
and bottom shelf intersection. Secure each with 2 long
bolts and 2 washers. Fully tighten with the allen
wrench.
Made in China - r02
3 Attach remaining 2 legs as shown, fitting leg slots into
corresponding slots in shelves. Loosely attach each leg
to top with 2 short bolts. Do not fully tighten the bolts.
x 8
5 Fully tighten all 8 short bolts installed in Steps 1 & 3
with the allen wrench. With the assistance of another
adult, lift assembled unit into an upright position.
Assembly is now complete.
CARE & CLEANING
Clean surfaces with a dry or damp soft cloth. Do not use
abrasive cleaners. Do not use furniture wax or polish as the
wood is finished with a protective clear lacquer.
