Crate & Barrel Alden Four-Drawer Chest Assembly Instruction
ALDEN FOUR-DRAWER CHEST
HARDWARE
48 - screws 27 - bolts
8 - pull screws 8 - drawer pulls
Thank you for purchasing the Alden Four-Drawer
Chest. This page lists all the contents included in the
box. Please take time to identify the hardware as
well as the individual components of this product. As
you unpack and prepare for assembly, place the
contents on a carpeted or padded area to protect
them from damage.
NOTE: 2 people are required to safely assembly this
product.
COMPONENTS
1 - back frame
1 - front frame
Missing hardware? Please call 800.606.6387 for replacements.
TOOLS REQUIRED
Allen wrench (included)
Phillips head screwdriver
2 - side frames
(1 left, 1 right)
8 - drawer sides
(4 left, 4 right)
Made in Thailand - r04
4 - drawer
backs
1- top panel
4 - drawer
fronts
4 - drawer
bottoms
1 With the assistance of another adult, fit dowels of left
and right side panels into corresponding holes in back
frame as shown. Loosely attach each side panel with 4
bolts. Do not fully tighten the bolts.
Page 1 of 3
ALDEN FOUR-DRAWER CHEST
2 Fit front frame into position, aligning dowels in side
frames with corresponding holes in front frame. Secure
from the inside with 4 bolts per side frame. Do not fully
tighten the bolts.
A
B
4 A. Fit left drawer side onto drawer back dowels as
shown. Attach with 3 screws and fasten with a phillips
head screwdriver. Do not over tighten the screws.
B. Attach drawer front to drawer side with 3 screws.
C. Slide drawer bottom into slot at bottom of drawer
back, side and front.
D. Repeat Steps A-C for remaining 3 drawers.
C
NOTE:
Do not over tighten
the screws.
3 Fit top panel into position, aligning dowels in side
frames with holes in top. Attach top with 11 bolts. At
this point, fully tighten all bolts installed in Steps 1 & 2
with the allen wrench.
A
B
5 A. Attach right drawer side to drawer back and front
with 6 screws.
B. Attach each drawer pull with 1 pull screw. Secure
with a phillips head screwdriver.
C. Repeat Steps A & B for remaining 3 drawers.
Made in Thailand - r04
Page 2 of 3
