1: INPUT: Connect your guitar to this 1/4” jack by means of a shielded instrument cable.
2: OVERDRIVE BOOST: Use this control to increase the volume and add “crunch” to your
sound. This control is only active when the Overdrive Gain control (#3) is turned up. (For more
information please see the “Getting Your Sound” section to the right.)
3: OVERDRIVE GAIN: Use this control in conjunction with the Overdrive Boost control (#2) to
add distortion to your sound. (For more information please see the “Getting Your Sound” section to the right.)
4: CLEAN VOLUME: Use this control to set the overall output level of the amp. (For more
information please see the “Getting Your Sound” section to the right.)
5: BASS: Use this control to adjust the low frequency output level of the amplifier. Rotating this
control counter clockwise reduces the low frequency output; rotating it to the right increases it.
6: MID: Use this control to adjust the midrange frequency output level of the amplifier . Rotating
this control counter clockwise reduces the midrange frequency output; rotating it to the right
increases it.
7: TREBLE: Use this control to adjust the high frequency output level of the amplifier. Rotating this
control counter clockwise reduces the high frequency output; rotating it to the right increases it.
8: INSERT: Use this 1/4” jack to connect an external effects to the amplifier . Use a stereo 1/4”
male Y-cord: ring = send, tip = return, sleeve = ground. Send goes to the effect’s input; return
comes from its output. (See the illustration on the panel to the right for more information.)
9: HEADPHONES: Use this 1/4” jack to connect a pair of stereo headphones for private listening. The external speaker is disconnected when headphones are in use.
10: POWER LED: This LED will illuminate when power is applied to the amplifier.
11: POWER SWITCH: Use this switch to turn the amplifier on and off.
12: AC LINE IN: (Rear panel, not shown) The grounded power cord should only be plugged
into a grounded power outlet that meets all applicable electrical codes and is compatible with
the voltage, power, and frequency requirements stated on the rear panel. Do not attempt to
defeat the safety ground connection.
Getting Your Sound: The Boost, Gain and
Volume controls (#2, 3 & 4) can be used together
to create a wide variety of sounds. The following
guidelines will help you achieve your desired
sound.
Clean Sounds: Rotate the Gain control fully
counter clockwise (the Boost control will be inactive). Use the Volume control to set the output
level.
“Crunch” Sounds: Set the Boost control to 11
o’clock and the Gain to 9 o’clock. Use the Volume
control to set the output level. (The volume control
should be adjusted to a lower setting as the Boost
and Gain controls are increased.)
Rhythm Sounds: Set the Boost control around 1 1
o’clock and the Gain at or near “10”. Use the
Volume control to set the output level.
Lead Sounds: Set the Boost and Gain controls at
or near “10”. Use the Volume control to set the output level.
N
Connecting to the Insert jack: The Insert
jack (#8) lets you patch external effects into
the amplifier just prior to its power amp stage.
Use Crate’s STP201, STP202 or STP203
stereo-to-mono Y-cord or an adapter such as
Crate’s YPP117 and 2 1/4” mono signal
cables to connect to the effect as shown:
Block Diagram:
Stereo-to-mono Y-cord:
to Insert
(STP201, 3'
STP202, 6'
STP203, 9')
TIP
TIP
RING
jack
SLEEVE
to
effect
"OUT"
jack
effect
"IN"
jack
External Effect
Y-adapter and 2 cables:
RETURN
RING
to
SEND
GROUND
RING
SLEEVE
(YPP117)
TIP
MONO CABLES)
to
effect
"OUT"
jack
External Effect
TIP
to Insert
jack
(1/4"-TO-1/4"
effect
"IN"
jack
RING
to
OVERDRIVE
INPUT
AC POWER
POWER SW
Overdrive
Gain
POWER SUPPLY
BUFFER PRE AMP
B+
B–
POWER LED
EQUALIZATION
Volume
Treble Mid Bass
POWER AMP
INSERT
HEADPHONE
TIP: RETUR
RING: SEND
SPEAKER
MX10 TECHNICAL SPECIFICATIONS:
Output Power Rating 10 watts RMS @ 1% THD
14 watts @ 10% THD
Speaker Size 6”
Input Impedance 500k ohms
Minimum Noise 1mV
Maximum Noise 10mV
Distortion 0.9%
Power Requirements 120 VAC, 60Hz, 20VA
100/115VAC, 50/60Hz, 20VA
100/115VAC, 50/60Hz, 20VA
Size and Weight 14” H x 12.5” W x 6” D, 12 lbs.
The MX10 is covered with a durable black Tolex material: wipe it clean with a lint-free cloth.
Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.
Crate continually develops new products, as well as improves existing ones. For this reason, the specifications
and information in this manual are subject to change without notice.
www.crateamps.com
@2001 SLM Electronics, a division of St. Louis Music, Inc • 1400 Ferguson Avenue • St. Louis, MO 63301
05/01
IMPORTANT SAFETY INSTRUCTIONS
• READ, FOLLOW, HEED, AND KEEPALLINSTRUCTIONS AND WARNINGS.
• DO NOT OPERATE NEAR ANY HEAT SOURCE AND DO NOTBLOCK ANY VENTILATION OPENINGS ON THIS APPARATUS.
• DO NOT USE THIS APPARATUS NEAR SPLASHING, FALLING, SPRAYING, OR STANDING LIQUIDS.
• CLEAN ONLY WITH LINT-FREE DAMP CLOTH AND DO NOTUSE CLEANING AGENTS.
• ONLY CONNECT POWER CORD TO APOLARIZED, SAFETY GROUNDED OUTLET WIRED TO CURRENT ELECTRICAL CODES AND
COMPATIBLE WITH VOLTAGE, POWER, AND FREQUENCY REQUIREMENTS STATED ON THE REAR PANELOF THE APPARATUS.
• PROTECT THE POWER CORD FROM DAMAGE DUE TO BEING WALKED ON, PINCHED, OR STRAINED.
• UNPLUG THE APPARATUS DURING LIGHTNING STORMS OR WHEN UNUSED FOR LONG PERIODS OF TIME.
• ONLY USE ATTACHMENTS, ACCESSORIES, STANDS, OR BRACKETS SPECIFIED BY THE MANUFACTURER FOR SAFE OPERA-
TION AND TO AVOID INJURY.
• THIS APPARATUS DOES NOT OPERATE NORMALLYAND REQUIRES SERVICE WITH ANY PHYSICAL DAMAGE FROM IMPACT OR
ANY EXPOSURE TO MOISTURE.
• SERVICE MUST BE PERFORMED BY QUALIFIED PERSONNEL.
• OUR AMPLIFIERS ARE CAPABLE OF PRODUCING HIGH SOUND PRESSURE LEVELS. CONTINUED EXPOSURE TO HIGH SOUND
PRESSURE LEVELS CAN CAUSE PERMANENT HEARING IMPAIRMENT OR LOSS. USER CAUTION IS ADVISED AND EAR PROTECTION IS RECOMMENDED IF UNIT IS OPERATED AT HIGH VOLUME.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
"IT IS NECESSARY FOR THE USER TO REFER TO THE INSTRUCTION MANUAL"
“ES NECESARIO QUE EL USUARIO SE REFIERA AL MANUAL DE INSTRUCCIONES.”
"REFERREZ-VOUS AU MANUAL D'UTILISATION"
EXPLANATION OF GRAPHICAL SYMBOLS:
EXPLICACION DE SIMBOLOS GRAFICOS:
EXPLICATION DES SYMBÔLES GRAPHIQUES:
"DANGEROUS VOLTAGE"
“VOLTAJE PELIGROSO”
"DANGER HAUTE TENSION"
=
=
PRECAUCION
RIESGO DE CORRIENTAZO
NO ABRA
PRECAUCION: PARA REDUCIR EL RIESGO DE INCENDIOS O DESCARGAS
ELECTRICAS, NO PERMITA QUE ESTE APARATO QUEDE EXPUESTO A LA
LLUVIA O LA HUMEDAD. PARA DISMINUOIR EL RIESGO DE CORRIENTAZO.
NO ABRA LA CUBIERTA. NO HAY PIEZAS ADENTRO QUE EL USARIO PUEDO
REPARAR DEJE TODO MANTENIMIENTO A LOS TECHNICOS CALIFICADOS.
ATTENTION
RISQUE D'ELECTROCUTION
NE PAS OUVRIR
ATTENTION: PROTÉGEZ CET APPAREIL DE LA PLUIE ET DE L'HUMIDITÉ
AFIN D'ÉVITER TOUT RISQUE D'INCENDIE OU D'ÉLECTROCUTION. POUR
REDUIRE D'ELECTROCUTION NE PAS ENLEVER LE COUVERCLE. AUCUNE
PIECE INTERNE N'EST REPRABLE PAR L'UTILISATEUR. POUR TOUTE
REPARATION, S'ADRESSER A UN TECHNICIEN QUALIFIE.
