MODEL NUMBER 917.256510 owner’s manual

® Assembly
® Operation
® Cystomer Responsibilities

® Service and Adjustments

• Repair Parts

CAUTION: Read and follow ail safety rules and instructions before operating this equipment.

FOR CONSUMER ASSISTANCE HOT LINE. CALL THIS TOLL FREE NUMBER: 1 -800-659-5917

Sears, Roebuck and Co., Hoffman Estates, IL 60^79 HJ.S.A.

SAFETY RULES

Safe Operation Practices for Ride-On Mowers

A

= ™'® CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS.

FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH,

A

I. GENERAL OPERATION

Read, understand, and follow all instructions in the manual
and on the machine before starting.

Only allow responsible adults, who are familiar with the
instructions, to operate the machine.

Clear the area of objects such as rocks, toys, wire, etc.,

which could be picked up and thrown by the blade.
Be sure the area is clear of otherpeople before mowing. Stop

machine if anyone enters the area.
Never carry passengers
Do not mow in reverse unless absolutely necessary Always

look down and behind before and while backing.
Be aware of the mower discharge direction and do not point

it at anyone. Do not operate the mower without either the
entire grass catcher or the guard in place.

Slow down before turning
Never leave a running machine unattended. Always turn off

blades, set parking brake, stop engine, and remove keys

before dismounting.
Turn off blades when not mowing
Stop engine before removing grass catcher or unclogging

chute.

Mow only in daylight or good artificial light.

Do not operate the machine while under the influence of
alcohol or drugs

Watch for traffic when operating near or crossing roadways.

Use extra care when loading or unloading the machine into
a trailer or truck

II. SLOPE OPERATION

Slopes are a major factor related to ioss-of-control and
tipover accidents, which can result in severe injury or death,.

All slopes require extra caution. If you cannot back up the
slope or if you feel uneasy on it, do not mow it.

DO:

Mow up and down slopes, not across.
Remove obstacles such as rocks, tree limbs, etc
Watch for holes, ruts, or bumps. Uneven terrain could

overturn the machine. Tall grass can hide obstacles.
Use slow speed. Choose a low gear so that you will not have

to stop or shift while on the slope.
Follow the manufacturer’s recommendations for wheel

weights or counterweights to improve stability.
Use extra care with grass catchers or other attachments,

These can change the stability of the machine.
Keep all movement on the slopes slow and gradual. Do not

make sudden changes in speed or direction.
Avoid starting or stopping on a slope, if tires lose traction,

disengage the blades and proceed slowly straight down the
slope,

DO NOT:

• Do not turn on slopes unless necessary, and then, turn slowly
and gradually downhill, if possible,

• Do not mow near drop-offs, ditches, or embankments. The
mower could suddenly turn over if a wheel is over the edge
of a cliff or ditch, or if an edge caves in

• Do not mow on wet grass Reduced traction could cause
sliding.

• Do not try to stabilize the machine by putting your foot on the
ground,

• Do not use grass catcher on steep slopes

III. CHILDREN

Tragic accidents can occur if the operator is not alert to the

presence of children. Children are often attracted to the
machine and the mowing activity. Never assume that

children will remain where you last saw them.

• Keep children out of the mowing area and under the watchful
care of another responsible adult,

• Be alert and turn machine off if children enter the area.

• Before and when backing, look behind and down for small
children

• Never carry children. They may fall off and be seriously
injured or Interfere with safe machine operation.

• Never allow children to operate the machine,

• Use extra care when approaching blind corners, shrubs,
trees, or other objects that may obscure vision.

IV. SERVICE

• Useextracare in handling gasoline and otherfuels. Theyare
flammable and vapors are explosive.

- Use only an approved container.

- Never remove gas cap or add fuel with the engine

running. Allow engine to coo! before refueling. Do not
smoke.

- Never refuel the machine indoors,

- Never store the machine or fuel container inside where

there is an open flame, such as a wafer healer

• Never run a machine Inside a closed area.

• Keep nuts and bolts, especially blade attachment bolts, tight
and keep equipment in good condition.

• Never tamper with safety devices. Check their proper
operation regularly.

• Keep machine free of grass, leaves, or other debris build-up
Clean oil or fuel spillage. Allow machine to cool before
storing,

• Stop and inspect the equipment if you strike an object.
Repair, if necessary, before restarting.

• Never make adjustments or repairs with the engine running,

• Grass catcher components are subject to wear, damage,and
deterioration, which could expose moving parts or allow
objects to be thrown. Frequently check components and
replace with manufacturer's recommended parts, when nec
essary.

• Mower blades are sharp and can cut. Wrap the bladefs) or
wear gloves, and use extra caution when servicing them

• Check brake operation frequently, Adjust and service as
required.

CONGRATULATIONS on your purchase of a Sears

Tractor. It has been designed, engineered and manufac
tured to give you the best possible dependability and
performance.

Should you experience any problem you cannot easily

remedy, please contact your nearest Sears Authorized
Service Center/Department. We have competent, well­trained technicians and the propertoolsto service or repair
this tractor.

Please read and retain this manual. The instructions will

enable you to assemble and maintain your tractor properly.

Always observe the “SAFETY RULES".

MODEL
NUMBER

917.256510

SERIAL
NUMBER

DATE OF PURCHASE.
THE MODEL AND SERIAL NUMBERS WILL BE FOUND

ON A PLATE UNDER THE SEAT.

PRODUCT SPECIFÎCATIOMS

HORSEPOWER: 15,5
GASOLINE CAPACITY

AND TYPE:
OIL TYPE (API-SF/SG):

OIL CAPACITY:
SPARK PLUG:

(GAP; .030")
VALVE CLEARANCE:

GROUND SPEED (MPH):

5 QUARTS
UNLEADED REGULAR

SAE 30 (above 32“F)
SAE 5W-30 (below 32“F)

3,0 PINTS
CHAMPION RJ19LM

STD 361458

INTAKE: 005" - „007"
EXHAUST: .009"-,,011"

FORWARD;

1st 1,0
2nd 1.3
3rd 2.1
4th 3,1
5th 4,0
6th 5.1

REVERSE: 1,6

YOU SHOULD RECORD BOTH SERIAL NUMBER AND
DATE OF PURCHASE AND KEEP IN A SAFE PLACE
FOR FUTURE REFERENCE.

TIRE PRESSURE: FRONT; 14PS1

CHARGING SYSTEM:

REAR; 12PSI

3 AMPS BATTERY

5 AMPS HEADLIGHTS

MAINTENANCE AGREEMENT

A Sears Maintenance Agreement is available on this prod
uct. Contact your nearest Sears store for details.

CUSTOMER RESPONSIBILITIES

• Read and observe the safety rules,

• Followa regularschedule in maintaining, caringforand
using your tractor.

» Follow the instructions under “Customer Responsibili

ties" and “Storage” sections of this owner’s manual.

WARNING: This tractor is equipped with an internal

combustion engine and should not be used on or near any

unimproved forest-covered, brush-covered or grass-cov
ered land unless the engine’s exhaust system is equipped
with a spark arrester meeting applicable local or state laws

BATTERY: AMP/HR: 25

MIN-CCA: 190
CASE SIZE: U1R

BLADE BOLT TORQUE:

30-35 FT. LBS,

(if any). If a spark arrester is used, it should be maintained
in effective working order by the operator.
In the state of California the above is required by law
(Section 4442 of the California Public Resources Code).
Other states may have similar laws. Federal laws apply on
federal lands. A spark arrester for the muffler is available
through your nearest Sears Authorized Service Center/

Department (See REPAIR PARTS section of this manual).

LIMITED TWO YEAR WARRANTY ON CRAFTSMAN RIDING EQUIPMENT

For two (2) years from the date of purchase, If this Craftsman Riding Equipment is maintained, lubricated and tuned up according
to the instructions in the owner's manual, Sears will repair or replace, free of charge, any parts found to be defective in material
or workmanship.

This Warranty does not cover;

• Expendable items which become worn during normal use, such as blades, spark plugs, air cleaners, belts, etc

» Tire replacement or repair caused by punctures from outside objects, such as nails, thorns, stumps, or glass

• Repairs necessary because of operator abuse, negligence, improper storage or accident or the failure to maintain the
equipment according to the instructions contained in the owner’s manual

» Riding equipment used lor commercial or rental purposes,

LIMITED 90 DAY WARRANTY ON BATTERY

For ninety (90) days from date of purchase, if any battery included with this riding equipment proves defective in material or
workmanship and our testing determines the battery will not hold a charge. Sears will replace the battery at no charge.

IN-HOME WARRANTY SERVICE ON YOUR CRAFTSMAN RIDING EQUIPMENT IS AVAILABLE AT NO-CHARGE FOR 30
DAYS FROM THE DATE OF PURCHASE, PLEASE CONTACT YOUR NEAREST SERVICE CENTER, AFTER 30 DAYS
FROM THE DATE OF PURCHASE. WARRANTY SERVICE IS AVAILABLE BY TAKING YOUR CRAFTSMAN RIDING EQUIP
MENT TO YOUR NEAREST SEARS SERVICE CENTER. (IN-HOME WARRANTY SERVICE WILL STILL BE AVAILABLE

AFTER 30 DAYS FROM THE DATE OF PURCHASE BUT A STANDARD TRIP CHARGE WILL APPLY) THIS WARRANTY

APPLIES ONLY WHILE THIS PRODUCT IS IN THE UNITED STATES.

This Warranty gives you specific legal rights, and you may also have other rights which may vary from state to state

SEARS, ROEBUCK AND CO., D/817 WA, HOFFMAN ESTATES, IL 60179
