OPERATOR’S MANUAL
ONE HOUR UNIVERSAL BATTERY CHARGER
Item No. 911041
(1425301)
For use with Craftsman EX and DieHard
7.2 Volt - 24 Volt battery packs
BATTERIES SOLD SEPARATELY
WARNING: To reduce the risk of injury,
the user must read and understand the
operator’s manuai before using this
product.
Customer Help Line: 1-800-932-3188
Sears, Roebuck and Co., 3333 Beverly Rd., Hoffman Estates, IL 60179 USA
Visit the Craftsman web page: www.sears.com/craftsman
983000-733
5-05
Save this manual for future reference
US
WARRANT
ONE YEAR FULL WARRANTY ON CRAFTSMAN TOOL
If this Craftsman tool fails to give complete satisfaction within one year from date of purchase, RETURN IT TO THE
NEAREST SEARS STORE IN THE UNITED STATES, and Sears will replace it, free of charge.
If this Craftsman tool is used for commercial or rental purposes, this warranty applies for only 90 days from the date of
purchase.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Sears, Roebuck and Co., Dept. 817 WA, Hoffman Estates, IL 60179
SAFETY RULES FOR CHARGE
k WARNING! READ AND UNDERSTAND ALL
INSTRUCTIONS. Failure to follow all instructions
listed below, may result in electric shock, fire
and/or serious personal injury.
Before using battery charger, read all instructions
and cautionary markings in this manual, on battery
charger, battery, and product using battery to prevent
misuse of the products and possible injury or damage.
k CAUTION: To reduce the risk of electric shock
or damage to the charger and battery, charge
only nickel-cadmium rechargeable batteries as
specifically designated on your charger. Other
types of batteries may burst, causing personal
injury or damage.
Do not use charger outdoors or expose to wet or
damp conditions. Water entering charger will increase
the risk of electric shock.
Use of an attachment not recommended or sold
by the battery charger manufacturer may result in
a risk of fire, electric shock, or injury to persons.
Following this rule will reduce the risk of electric shock,
fire, or serious personal injury.
Do not abuse cord or charger. Never use the cord to
carry the charger. Do not pull the charger cord rather
than the plug when disconnecting from receptacle.
Damage to the cord or charger could occur and create
an electric shock hazard. Replace damaged cords
immediately.
Make sure cord is located so that it will not
be stepped on, tripped over, come in contact
with sharp edges or moving parts or otherwise
subjected to damage or stress. This will reduce the
risk of accidental falls, which could cause injury, and
damage to the cord, which could result in electric
shock.
J
Keep cord and charger from heat to prevent
damage to housing or internal parts.
Do not let gasoline, oils, petroleum-based products,
etc. come in contact with plastic parts. They contain
chemicals that can damage, weaken, or destroy plastic.
Do not operate charger with a damaged cord or
plug, which could cause shorting and electric shock. If
damaged, have the charger replaced by an authorized
serviceman.
Do not operate charger if it has received a sharp
blow, been dropped, or otherwise damaged in any
way. Take it to an authorized serviceman for electrical
check to determine if the charger is in good working
order.
Do not disassemble charger. Take it to an authorized
serviceman when service or repair is required. Incorrect
reassembly may result in a risk of electric shock or fire.
Unplug charger from outlet before attempting any
maintenance or cleaning to reduce the risk of
electric shock.
Disconnect charger from the power supply when
not in use. This will reduce the risk of electric shock
or damage to the charger if metal items should fall into
the opening. It also will help prevent damage to the
charger during a power surge.
Risk of electric shock. Do not touch uninsulated
portion of output connector or uninsulated battery
terminal.
Save these instructions. Refer to them frequently
and use them to instruct others who may use this
tool. If you loan someone this tool, loan them these
instructions also to prevent misuse of the product and
possible injury.
SYMBOLS
Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper Interpretation
of these symbols will allow you to operate the tool better and safer,
SYMBOL NAME DESIGNATION/EXPLANATION
Do not expose to rain or use In damp locations.
To reduce the risk of Injury, user must read and understand
operator’s manual before using this product.
Always wear safety goggles or safety glasses with side shields,
or a full face shield when operating this product.
Precautions that Involve your safety.
©
o
A
Wet Conditions Alert
Read The Operator’s Manual
Eye Protection
Safety Alert
FEATURES
PRODUCT SPECIFICATIONS
Charger Voltage...............................................................................................................................................7,2 Volt - 24 Volt DC
Charger Input..................................................................................................................................................120 V, 60 Hz, AC only
Charge Rate..............................................................................................................................................................................1 hour
Cord Length...................................................................................................................................................................................6 ft.
4-1/2 in.
KNOW YOUR CHARGER
See Figure 1.
Before attempting to use this product, familiarize yourself
with all operating features and safety rules,
“KEY HOLE” HANGING
The charger has a “key hole” hanging feature for convenient,
space-saving storage. Screws should be Installed so the
center distance Is 4-1/2 In,
LED DISPLAY
The LED lights located next to each battery port Indicate
the charge status of each battery,
THERMAL PROTECTION
Your charger has a thermal protection system that
prevents charging batteries that are too hot, which could
CAUTION
Do not use any DC to AC power
inverters. Charger will be Damaged!
Fig, 1
OPERATION
APPLICATIONS
You may use this tool for the following purposes:
■ Portable charging of Craftsman EX and DieHard
7,2 Volt - 24 Volt batteries
CAUTION: If at any point during the charging
process none of the LEDs are lit, remove the battery
pack from the charger to avoid damaging the
product, DO NOT insert another battery. Return the
charger and battery to your nearest service center
for service or replacement,
LED FUNCTIONS OF CHARGER
LED WILL BE ON TO INDICATE STATUS OF
CHARGER AND BATTERY PACK:
■ Red LED on = Fast charging mode,
■ Green LED on = Fully charged and in maintenance
charge mode,
■ Green LED on = When battery pack is inserted into
charger, indicates hot battery pack or that battery pack
is out of normal temperature range,
■ Yellow and Green LEDs on = Deeply discharged or
defective battery pack,
■ No LED on = Defective charger or battery pack,
If both yellow and green LEDs come on, this indicates
a deeply discharged or defective battery pack. Allow
the battery pack to remain in the charger for 15 to 30
minutes. When the battery pack reaches normal
voltage range, the red LED should come on. If the red
LED does not come on after 30 minutes, this may
indicate a defective battery pack and should be
replaced.
After normal usage, a minimum of 1 hour of charging
time is required to fully recharge battery pack.
The battery pack will become slightly warm to the
touch while charging. This is normal and does not
indicate a problem.
Do not place the charger and battery pack in an area
of extreme heat or cold. They will work best at normal
room temperature,
NOTE: The charger and battery pack should be placed
in a location where the temperature is more than 50°F
but less than 100°F,
When batteries become fully charged, unplug the
charger from power supply and remove the battery
pack,
BATTERY SHOWN CHARGING
(BATTERY SOLD SEPARATELY)
CHARGING A COOL BATTERY PACK
If battery pack is below normal temperature range, the
green LED on charger will come on. Allow battery pack to
reach normal temperature, then the red LED will come on,
NOTE: If the charger does not charge the battery pack
under normal circumstances, return both the battery pack
and charger to your nearest Sears Repair Center for
electrical check,
■ Charge the battery pack only with the charger provided,
■ Make sure the power supply is normal household
voltage, 120 V, 60 Hz, AC only,
■ Connect the charger to the power supply,
■ Place the battery pack in the charger aligning raised rib
on the battery pack with the groove in the charger. See
Figure 2.
■ Press down on the battery pack to be sure contacts on
the battery pack engage properly with contacts in the
charger,
■ Normally the red LED on charger will come on. This
indicates the charger is in fast charging mode,
■ Red LED should remain on for approximately 1 hour
then the green LED will come on. Green LED on
indicates battery pack is fully charged and charger is
in maintenance charge mode,
NOTE: The green LED will remain on until the battery
pack is removed from the charger or charger is
disconnected from the power supply.
(GREEN LED)
Fig, 2
OPERATION
CHARGING A HOT BATTERY PACK
When using the tool continuously, the batteries in the
battery pack will become hot. You should let a hot battery
pack cool down for approximately 30 minutes before
attempting to recharge. When the battery pack becomes
discharged and is hot, this will cause the green LED to
come on instead of the red LED, After 30 minutes, reinsert
the battery pack in the charger. If the green LED continues
to remain on, return battery pack to your nearest Sears
Repair Center for checking or replacing,
NOTE: This situation only occurs when continuous use of
the tool causes the batteries to become hot. It does not
occur under normal circumstances. Refer to “Charging
a Cool Battery Pack” for normal recharging of batteries.
If the charger does not charge your battery pack under
normal circumstances, return both the battery pack and
charger to your nearest Sears Repair Center for electrical
check.
USE 11041 BATTERY CHARGER ONLY WITH
BATTERY PACKS LISTED BELOW.
TYPE 1 BATTERY PACK MODEL NUMBERS
{require 1 hour to charge)
1310715,1322521,1322522,1323408,1323409,1323501,
1323502,1323505,1323506,1323513,1323514,1323516,
1323517, 1323903, 1323905, 1325101, 130235029,
130238003, 130238005, 130251008, 130279001,
130279002, 130279003, 130279004, 130279005,
130287001
CHARGER CAN ALSO BE USED FOR PRODUCTS
WITH THE FOLLOWING ITEM NUMBERS
10153,11044,11045,11068,11375,11403,11426,11427,
11428,11430,11442,11448,11453,11462,11485,11512,
11516,11538,11539,11540,11541,11542,11543,11544,
11545, 11546, 11574, 11575
Get it fixed, at your home or ours!
Your Home
For repair-in your home-of all major brand appliances,
lawn and garden equipment, or heating and cooling systems,
no matter who made it, no matter who sold it!
For the replacement parts, accessories and
owner’s manuals that you need to do-it-yourself.
For Sears professional installation of home appliances
and items like garage door openers and water heaters.
1-800-4-MY-HOME® (1-800-469-4663)
Call anytime, day or night (U.S.A. and Canada)
www.sears.com www.sears.ca
Our Home
For repair of carry-in items like vacuums, lawn equipment,
and electronics, call or go on-line for the location of your nearest
Sears Parts & Repair Center.
1-800-488-1222
Call anytime, day or night (U.S.A. only)
www.sears.com
To purchase a protection agreement (U.S.A.)
or maintenance agreement (Canada) on a product serviced by Sears:
1-800-827-6655 (U S A )
Para pedir servicio de reparación
a domicilio, y para ordenar piezas:
1-888-SU-HOGAR"“
(1-888-784-6427)
1-800-361-6665 (Canada)
Au Canada pour service en français:
1-800-LE-FOYER“'=
(1-800-533-6937)
www.sears.ca
® Registered Trademark / Trademark / Service Mark of Sears, Roebuck and Co.
® Marca Registrada / Marca de Fábrica / Marca de Servicio de Sears, Roebuck and Co.
Marque de commerce / Marque déposée de Sears, Roebuck and Co.
© Sears, Roebuck and Co.
Loading...
