Owner's Manual

CRRFTSMRN

PROFESSIONAL
1

Reciprocating Saw

Variable Speed

• SAFETY
CAUTION: Read, understand and follow
all Safety Rules and Operating Instructions in this manual before using this product.

Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.

10-23-01
• OPERATION
• MAINTENANCE
• ESPAÑOL

TABLE OF CONTENTS

Warranty. Safety Instructions Safety Symbols
Description Operation Maintenance Accessories
Repair Parts..............................
FULL ONE YEAR WARRANTY ON CRAFTSMAN PROFESSIONAL RECIPROCATING SAW
If this CRAFTSMAN Professional Reciprocating Saw fails due to a defect in material or workmanship within one year from the date of purchase, Sears will repair it, free of charge.
WARRANTY SERVICE IS AVAILABLE BY SIMPLY RETURNING THE TOOL TO THE NEAREST SEARS STORE OR OTHER CRAFTSMAN OUTLET IN THE UNITED STATES.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Sears, Roebuck and Co., Dept. 817 WA, Hoffman Estates, IL 60179
..................................
..................
........................
...............................
..................................
.............................
..............................
....................Pages
2 3-7 7 8 8- 11 12-13 13 14-18
SAVE THESE INSTRUCTIONS!
READ ALL INSTRUCTIONS!
SAFETY INSTRUCTIONS
A WARNING: BE SURE to read and understand all instructions.
Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury.
WORK AREA SAFETY
1. ALWAYS keep your work area clean and well lit. Cluttered benches and
dark areas in\nte accidents.
2. DO NOT operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.
3. ALWAYS keep bystanders, children, and visitors away while operating a power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
1. Double insulated tools are equipped with a polarized plug (one blade is
wider than the other.) This plug will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install a polarized outlet. Do not change the plug in any way.
2. Double insulation B eliminates the need for the three wire grounded power
cord and grounded power supply system. Applicable only to Class II (double insulated) tools.
3. Before plugging in the tool, BE SURE that the outlet voltage supplied is
within the voltage marked on the tool's data plate. DO NOT use “AC only”
rated tools with a DC power supply.
4. ALWAYS avoid body contact with grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is grounded.
5. If operating the power tool in damp locations is unavoidable, ALWAYS use a Ground Fault Circuit Interrupter to supply power to your tool. ALWAYS wear electrician's rubber gloves and footwear in damp conditions.
6. DO NOT expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
7. DO NOT abuse the cord. NEVER use the cord to carry the tools or pull the plug from the outlet. Keep cord away from heat, oil, sharp edges or moving parts. Replace damaged cords immediately. Damaged cords increase the risk of electric shock.
SAFETY INSTRUCTIONS cont.
ELECTRICAL SAFETY cont.
8. When operating a power tool outside, ALWAYS use an outdoor extension cord marked "W-A" or 'W." These cords are rated for outdoor use and reduce the risk of electric shock.
NOTE: The extension cord must have adequate wire size AWG (American Wire Gauge) for safe, efficient use. Smaller gauge wires, have greater capacity (16 gauge wire has more capacity than 18 gauge wire).
Minimum Gauge for Extention Cords (AWG)
Voits
120 V
Ampere Rating
More than 0
Not more than 6
More than 6
Not more than 10
More than 10
Not more than 12
More than 12
Not more than 16
PERSONAL SAFETY
1. ALWAYS stay alert, watch what you are doing and use common sense when operating a power tool. DO NOT use tool while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in serious personal injury,
2. ALWAYS dress properly. DO NOT wear loose clothing or jewelry. Pull back long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts.
3. ALWAYS avoid accidental starting. BE SURE switch is “Off” before plugging in. Carrying tools with your finger on the switch or plugging in tools that have the switch in the “On” position invites accidents.
4. ALWAYS remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left attached to a rotating part of the tool may result in personal injury.
5. DO NOT overreach. ALWAYS keep proper footing and balance at all times. Proper footing and balance enables better control of the tool In
unexpected situations.
6. ALWAYS use safety equipment. Always wear eye protection.
Dust mask, non-skid safety shoes, hard hat, or hearing protection must be used for appropriate conditions
Total Length of Cord in Feet
0 25 ft.
AWG AWG AWG AWG
18
18 16 16
14
26 50 ft.
16
16
12
51 ­100 ft.
16
14 12
14
Not Recommended
101 ­150 ft.
14
12
...............
SAFETY INSTRUCTIONS cont.
TOOL USE AND CARE SAFETY
1. ALWAYS use clamps or other practical ways to secure and support the workpiece to a stable platform. Holding the work by hand or against your body is unstable and may lead to loss of control.
2. DO NOT force tool. Use the correct tool and blade for your application. The correct tool and blade will do the job better and safer at the rate for which it is designed.
3. DO NOT use tool if switch does not turn it “On” or “Off”. Any tool that
cannot be controlled with the switch is dangerous and must be repaired.
4. ALWAYS disconnect the plug from the power source before making any
adjustments, changing accessories,or storing the tool. Such preventive safety measures reduce the risk of starting the tool accidentally.
5. ALWAYS store idle tools out of reach of children and other untrained
persons.Tools are dangerous in the hands of untrained users.
6. ALWAYS maintain tools with care. Keep cutting tools sharp and clean.
Properly maintained tools with sharp cutting edges are less likely to bind
and are easier to control.
7. ALWAYS check for misalignment or binding of moving parts, breakage
of parts, and any other condition that may affect the tool’s operation.
If damaged, have the tool serviced before using. Many accidents are
caused by poorly maintained tools.
A WARNING: USE OF ACCESSORIES THAT ARE NOT
RECOMMENDED FOR USE WITH THIS TOOL MAY CREATE
A HAZARDOUS CONDITION.
8. ALWAYS use only accessories that are recommended for this tool.
Accessories that may be suitable for one tool can become hazardous when used on another tool.
SAFETY INSTRUCTIONS cont.
SERVICE SAFETY
1. Tool service MUST BE performed only at a Sears Service Center.
Service or maintenance performed by unqualified personnel
could result in a risk of injury.
2. When servicing a tool, ALWAYS use only identical replacement parts.
Follow Instructions in the Maintenance section of this manual. Use of unauthorized parts or failure to follow Maintenance Instructions may create a risk of electric shock or injury.
ADDITIONAL SPECIFIC SAFETY RULES
1. Know your power tool. Read operator's manual carefully. Learn the applications and limitations, as well as the specific potential hazards
related to this tool. Following this rule will reduce the risk of electric shock,
fire or serious injury.
2. ALWAYS hold tool by insulated gripping surfaces when performing an
operation where the cutting tool may contact hidden wiring or its own cord. Contact with a live” wire will make the exposed metal parts of the tool
“live" and shock the operator.
3. ALWAYS keep your hands away from cutting area. DO NOT reach under the material being cut because the nearness of the blade to your hand is hidden from your sight.
4. DO NOT use dull or damaged blades. Bent blades can break easily, or cause kickback.
5. ALWAYS wear safety glasses or eye shields when using this saw.
ALWAYS wear a dust mask or respirator for applications which
generate dust.
6. ALWAYS protect your lungs. Wear a face mask or dust mask if the operation is dusty. Following this rule will reduce №e risk of serious personal injury.
7. ALWAYS protect your hearing. Wear hearing protection during extended periods of operation. Following this rule will reduce the risk of serious
personal injury.
8. ALWAYS inspect and remove all nails from lumber before sawing.
Foliowng this rule will reduce the risk of serious personal injury.
9. SAVE THESE INSTRUCTIONS. Refer to them frequently and use them to instruct others who may use this tool. If someone borrows this tool, make sure they have these Instructions also.
SAFETY INSTRUCTIONS cont.
ADDITIONAL SPECIFIC SAFETY RULES cont.
A WARNING: Some dust particles created by power sanding,
sawing, grinding, drilling and other construction jobs contain chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks and cement and other masonry products.
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending upon how often you do this type of work. To reduce your exposure to these chemicals:
• Work in a well-ventilated area.
• Work with approved safety equipment, such as those dust masks that are specially designed to filter out microscopic particles.
A WARNING: The operation of any saw can
result in foreign objects being thrown into your eyes, which can result in severe eye damage. Before beginning power tool operation, ALWAYS wear safety goggles or safety glasses with side shield and a full face shield when needed. We recommend a Wide Vision Safety Mask for use over eyeglasses or standard safety glasses with side shield, both available at Sears Retail Stores.
The label on your tool may include the following symbols.
V........................................................................................Volts
A........................................................................................Amperes
Hz......................................................................................Hertz
W.......................................................................................Watts
min....................................................................................Minutes
.....................................................................................Alternating current
- - - - ...................................................................................Direct current
no......................................................................................No-load speed
El......................................................................................Class II construction
..ymin
...............................................................................
A .......................................................................................Indicates danger, warning
Revolutions or
reciprocation per minute
caution. It means attention!!! Your safety is involved.
IMPORTANT! READ ALL INSTRUCTIONS
DESCRIPTION
Your reciprocating saw has many built-in convenience features for fast, efficient cutting. These features include an adjustable/pivoting shoe for maximum control in a variety of cuts. An easy-to-grip rubber boot and a keyless blade clamp for easy blade changes.
OPERATION
A CAUTION: THE BLADE GUARD IS THERE FOR YOUR SAFETY.
DO NOT REMOVE IT.
A CAUTION: ALWAYS wear eye protection while operating this
power tool.
USING THE TRIGGER SWITCH TO CONTROL VARIABLE SPEED This saw is equipped with a variable speed trigger switch. The saw can be
turned ON or OFF by squeezing or releasing the trigger switch. The speed of the blade can be adjusted by the pressure you
apply to the trigger switch.
1. To increase the speed, apply more pressure to the trigger switch.
2. To decrease the speed, apply less pressure. Choosing the Correct Speed
The speed you use will depend on the type of materials that you are cutting:
1. Use high speeds for cutting wood.
2. Medium speed is best for non-ferrous materials.
3. Low speed is recommended for cutting metal. NOTEiMaterial thickness and blade selection will also affect your speed
selection. As a general rule, as the material thickness increases, the speed should be slower.
A CAUTION: Use a very slow speed when beginning a cut. Then
increase speed once the cut is started. Prolonged use at a very slow
speed may damage your saw.
8
OPERATION cont.
BLADE INSTALLATION AND REMOVAL This saw is designed to use all 1/2-in. universal shank blades.
A WARNING: To prevent personal injury, ALWAYS disconnect the
plug from power source BEFORE assembling parts, making adjustments or changing blades.
To Install Blade (Figure 2)
1. Disconnect saw from power source.
2. If necessary, extend the adjustable/ pivoting shoe away from tiie blade clamp for easier access.
3. Rotate the blade clamp collar clockwise about 180°.
4. Insert the blade through the rubber cover until it stops, then release the collar.
5. Pull up on blade to ensure that it is locked In.
To Remove Blade
1. Disconnect saw from power source.
2. If necessary, extend the adjustable/ pivoting shoe away from the blade clamp for easier access.
3. Rotate the blade clamp collar clockwise about 180°.
4. Pull the blade out of the blade clamp and release the collar.
ADJUSTING THE SLIDING / PIVOTING SHOE (Figures 3 and 4)
The shoe slides in or out to adjust the depth of cut to material being cut for maximum control and longer blade life.
To Slide Shoe In or Out: (See Fig. 3)
1. Pull shoe release lever and slide shoe out to desired cutting depth.
The shoe locks in 3 positions.
2. Push in lever to lock shoe in desired position.
NOTEiThe shoe also pivots to provide maximum control against the surface being cut.
To pivot Shoe: (See Fig. 4)
1. Rrmly hold saw and then pivot shoe to desired position. 9
OPERATION cont.
FLUSH CUTTING (Figure 5)
1. The compact design of the motor housing and the blade guard on this reciprocating saw allows for extremely close cutting in floors, corners and in other extremely close areas.
2. To maximize the flush cutting capability of this saw, insert the blade shaft into the blade holder with the teeth of the blade facing as close as possible to the work surface.
WOOD CUTTING (Figure 6}
1. ALWAYS clamp the workpiece down to prevent it from slipping.
2. Place blade and blade guard lightly against surface to be cut.
3. Turn on saw and allow it to come to full speed before applying pressure to the workpiece.
4. ALWAYS hold saw firmly with both hands while cutting. Whenever possible, saw guard must be held firmly against the material being cut. This will prevent the saw from jumping or vibrating and minimize blade breakage.
NOTE: Wear gloves if cutting for long periods.
10
OPERATION cont.
METAL CUTTING (Figure 7)
This saw has different metal cutting capacities depending upon the type of blade being used and metal being cut.
1. ALWAYS clamp the work down to
prevent it from slipping.
2. Use a finer blade for ferrous metals and a
coarse blade for non-ferrous metals.
3. When cutting thin gauge sheet metals,
ALWAYS clamp wood on both sides of the sheet. This will give you a clean cut without excess vibration or tearing of the metal.
4. DO NOT force the cutting blade. Forcing the blade will reduce blade life and cause
the blade to break.
NOTE: We recommend that you spread a thin film of oil or other coolant along
the line of cut ahead of the saw. This will allow easier operation and help extend
blade life. When cutting aluminum, use kerosene.
POCKET CUTTING: Wood Only
(Figure 8)
1. Measure the surface area to be cut and mark it clearly using a pen, pencil or chalk.
2. Install a pocket cutting blade into saw.
3. Tip the saw backwards until the back edge of the blade guard is resting on the work surface.
4. To avoid breaking the Wade, start the saw and use the slowest speed to begin the cut.
Then gradually increase №e speed as you
start to cut.
5. Hold the saw handle firmly and begin to make a slow, deliberate upward swing with the handle of the saw.
6. The Wade will begin to feed into the material.
7. ALWAYS be sure that the Wade is completely trough the material before continuing with the pocket cut.
NOTE: In areas where Wade visibility Is limited, use the edge of the saw guard as a guide.
............................
Fig. 8
Rock tool up to normal cutting potion after blade has cut
through material.
11
MAINTENANCE
SERVtCE
A WARNING: Preventive maintenance performed by unauthorized
personnel may result in misplacing of internal wires and components, which could cause a serious hazard.
1. Tool service MUST BE performed only by a Sears Service Center.
Service or maintenance performed by unqualified personnel could result in a risk of injury.
IMPORTANT NOTE: All service that requires opening the saw should only be performed at a Sears Service Center.
2. When servicing a tool, ALWAYS use only identical replacement parts. Follow instructions in the Maintenance Section of this manual. Use of unauthorized parts or failure to follow Maintenance Instructions may create a risk of electric shock or injury.
TOOL LUBRICATION
Your CRAFTSMAN Reciprocating Saw has been properly lubricated and is ready to use.
1. In two to six months, depending on use, take your tool to the nearest Sears
Service Center for a complete cleaning, inspection and lubrication.
2. Tools used constantly on production jobs will need lubrication more often.
3. Tools that haven't been used for long periods of time should
be lubricated before you use them.
WHEN SERVICING, USE ONLY IDENTICAL REPLACEMENT PARTS
A WARNING: To avoid accidents, ALWAYS disconnect the
tool from the power source BEFORE cleaning or performing any
maintenance.
1. Only the parts shown on pages 14-16 are intended to be repaired or
replaced by the customer. All other parts represent an important part of the double insulation system and should only serviced at a Sears Service Center.
12
MAINTENANCE cont.
CLEANING
A WARNING: To avoid accidents, ALWAYS disconnect the tool
from the power source BEFORE cleaning or performing any maintenance.
A CAUTION: Certain cleaning agents and solvents cause damage
to the plastic parts. These include gasoline, carbon tetrachloride, chlorinated cleaning solvents, ammonia and household detergents that contain ammonia.
1. Use a clean cloth to remove dirt, carbon dust, etc.
2. Electric tools are subject to accelerated wear and possible premature failure when they are used to work on fiber glass boats, sports cars, etc. The fiber glass chips and grindings are highly abrasive to electrical tool parts, such as bearings, brushes, commutators, etc. Consequently, it is not recommended
that this tool be used for extended work on fiber glass. During any use on fiber glass, it is extremely important that the tool is cleaned frequently with
compressed air.
A WARNING: ALWAYS wear safety goggles when cleaning tools I
with compressed air.
IMPORTANT:
To assure product SAFETY and RELIABILITY, repairs,maintenance and adjustment MUST be performed by a Sears Service Center.
ACCESSORIES
The following recommended accessories are currently available at your local Sears Store.
BLADES
Sears has a large selection of reciprocating saw blades that are ideal for all your cutting needs.
EXTENSION CORDS
Sears offers a large selection of extension cords that are ideal for all your cutting needs.
A WARNING: The use of attachments or accessories that are not
recommended might be dangerous.
13
Reciprocating Saw-Model No. 172.267700
The Model Number will be found on the Nameplate. Always mention the Model No. in ail correspondance regarding your tool
No. Part No.
1 2
3 4 SB21.5.17-00 Washer 5 SW61.61.0-00 6 7
9
10
11
12
13 14 15 16 17 SW21.5.06-00 18 SB21.5.13-00 19 SW55.57.0-00 20
21 22 SW07.01.03-00
23 24
25
26 27 28
SB21.5.14-00 SB21.5.19-00 Tortile Spring 1 SB21.5.18-00
SB21.5.09-00 SB21.5.05-00 SB21.5.12-00 SB21.5.02-00
SB21.5.03-00 SB21.5.08-00 SB21.5.01-00
SB21.5.0-00 SB21.5.04-00 SB21.5.07-00 SW62.39.0-00 Capreolate Pin 1
SB21.1.02-00 ST15.01.06-00
SW07.01.02-00 SW55.37.0-00 SW55.41.0-00 SB21.1.21-00 Top Cover ST04.03.46-00 SB21.1.01-00
Description Front Cover
Stop Patch
Rinq-Circlip
Washer Sheath
Tortile Spring
Front Housing Back Housing
Washer Outer Cover Ring-Circlip
Rubber Sleeve
Pin
Slide Block
Tortile Spring
Screw
Flange 1
Seal Powder Bearing Powder Bearing 1
Screw Screw 2
Spring Back Plate
Quantity
1
1 1 1 1 1 1 1 1 1 1 1 1 1
1 1 2
1
1
4
1 4 1
No.
29 SB21.1.10-00 30 SB21.1.03-00
31 ST04.03.47-00
32 33 34 SB21.0.08-00 Seal 35 SB21.0.06-00 36 37 38 39
40 41 42
43 44 45 SW02.42,10-00 46 SW01.31,26-00 47 48 49 50
51 52 53 54 55 56
Part No.
SB21.5.11-00 SB21.0.16-00
SW55.78.0-00
SB21.0.05-00 ST05.01.14-00-00 STB50.03.10-00
SB21.0.12-00
SB21.0.01-0-00
ST25.11.05-6A-00
SB21,0.02-0-00
SW55.58.1-00
SB21.0.03-0-00
ST05.01.13-00
SW09.01.02 Connector SW55.11.0-00 SB21.0.07-00 ST08.01.07-00 SW55.58.0-00
ST25.21.Û3.2A-00
SB21.0.13-0-00
ST05.02.09-00
Description
Reciprocating Rod
Limit Tube
Spring 1
Push Piece
Seal Gasket
Big Flange 1
Screw
Fan Baffle
Screw
Stator
Nameplate
Housing
Inter Wire
Left Handle
Screw
Switch 1
Cable and Plug 1
Right Handle 1
Cable Protector
Screw Brush Flange Cable Clamp
Screw
Inter Wire Rated Label 1
Bearing Sheath 1
Quantity
1 1
1 1 1
4 1 2 1 1
1 1
1
10
1 1
5
2 1 2 2
SEE BACK PAGE FOR PARTS ORDERING INSTRUCTIONS
Reciprocating Saw-Model No. 172.267700
The Model Number will be found on the Nameplate. Always mention the Model No. in all correspondance regarding your tool
СЛ
No.
57 SB21.0.11.0-00 Down Deccorated Cover
58 SW50.11.3-00 Ball-Bearing
59
60
61 SW61.55.0-00
62 ST05.05.01-00 63 ST03.20.10-00 64 ST02.20.00-00 65 66 SB21.0.09.00-00 67 68 69 70 SB21.2.01-00
71
72 73 74 SB21.2.12-00 75 SW57.29.0-00 76 77 78 79 80 SB21.3.10-00
81
82 83 84
Part No. Description Quantity
STB51.03.220-00
SW50.03.4-00
ST03.20.13-00
Top Deccorated Cover 1
SW51.05.0-00 STB02.04-00 SB21.2.02-00
SW57.2.11-00 SB21.39.0-00 SW50.03.3-00
STB01.03-00 SW50.51.0-00
SW61.51.0-00 ST14.01.01-00
SW61.12.0-00 ST14.12.00-00 ST04.03.48-00
SB21.3.01-00
Roter 1
Ball-Bearing 1
Ring-Circllp
Seal
Brush Holder 1
Carbon Brush
Brush Cover 2
Needle Bearing
Main Shaft
Balance Weight 2
Base Plate 1
Gearcase Cover
Capreolate Pin
Ball-Bearino
Flange 1
Screw 1
Pinion 1 Ball-Bearing Ring Circlip
Washer 1
Gear Case
Split Washer
Washer
Dish Spring 2
TPin
No. Part No. Description Quantity
1 1
1 1
2
2 1
1 1 4
3 1
1 1 1
1
85 86 87 SB21.3.22-00 88 89
101 102 103 104 105 SB21.8.00-00
SEE BACK PAGE FOR PARTS ORDERING INSTRUCTIONS
SW57.31.0-00
SW62.21.0-00
SB21.3.21-00 SB21.3.20-00
SB21.5.00-00 SB21.2.00-00 SB21.7.00-00
SB21.3.20-00
Screw 4
Capreolate
Spanner Bracket
Support Plate 1
Quick Blade Change Set
Gear Case Cover Set
Rotor Set
Spanner Set
Reciprocating Rod Set
1 1 1
1 1 1 1 1
О)
NOTES
17

Get it fixed, at your home or bure!

Your Home
For repair In your home of all major brand appliances,
lawn and garden equipment, or heating and cooling systems,
no matter who made It, no matter who sold it!
For the replacement parts, accessories and
owner’s manuals that you need to do-it-yourself.
For Sears professional installation of home appliances and items like garage door openers and water heaters.
1-800-4-MY-HOME® Anytime, day or night
(1 -800-469-4663) (U.S.A. and Canada)
www.sears.comwww.sears.ca
Our Home
For repair of carry-in products like vacuums, lawn equipment,
and electronics, call or go on-line for the nearest
Sears Parts and Repair Center.
1 -800-488-1222 Anytime, day or night (U.S.A. only)
www.sears.com
To purchase a protection agreement (U.S.A.) or maintenance
agreement (Canada) on a product serviced by Sears;
1-800-827-6655 (U.SA)
Pata pedir servicio de reparación
a domicilio, y pata ordenar piezas:
Ei:.
OSeaï^ RœbuckandCa ® Registered Trademark/™ Trademark/^'*Ser^ñce Mark of Sears, Roebuck and Co.
® Marca Registrada / ™ Marca de F- brica / Marca de Servicio de Sears, Roebuck and Co.
1-888-SU-HOGAR^”
(1-888-784-6427)
Marque de commerce / Marque déposée de Sears, Roebuck and Co.
1-800-361-6665 (Canada)
Canada pour service en ftançais;
1-800-LE-FOYER“'=
IB
(1-8006366937)
www.sears.ca
Loading...
