Epic
®
MODEL #EP70OB with B5/70E-WB6
DIMENSIONS
A-(2”DR)-12”
”
A-(6”DR)-16
(DR-Down Rod)
This Craftmade fan is
shipped with two down rods,
a 2” for mounting close to the
ceiling, a 6” rod for
mounting farther away.
WARRANTY
Limited Lifetime Warranty
SPECIFICATIONS
Blade Sweep – 70”
# of Blades – 5
Blade Pitch – 14°
Motor Size (MM) –
212 x 25
AMPS (HI Speed) –
0.91
Watts (HI Speed) – 102
RPM (HI/MED/LO) –
96/76/45
CFM (HI Speed) – 7680
Also Available in:
AG - Aged Bronze
AW - Antique White
RI - Rustic Iron
EP70OB with
B5/70E-WB6
Oiled Bronze Epic Fan with
Satin Finish Walnut blades.
STANDARD
OPERATION
Chain pull
OPTIONAL TCS
CONTROL SYSTEM
