DC-DC Converters PCB Mount Type
Ordering information
MG S 10 24 05 -O
1 2 3 4 5 6
1 Series name
2 Single output
3 Output wattage
4 Input voltage
5 Output voltage
6 Optional
MODEL
MGS10
R
MGS10053R3 MGS100505 MGS100512 MGS100515 MGS10123R3 MGS101205 MGS101212 MGS101215
MAX OUTPUT WATTAGE[W] 8.58 10.0 10.8 10.5 8.58 10.0 10.8 10.5
DC OUTPUT
VOLTAGE[V] 3.3 5 12 15 3.3 5 12 15
CURRENT[A]
2.6 2.0 0.9 0.7 2.6 2.0 0.9 0.7
SPECIFICATIONS
MODEL
VOLTAGE[V] DC4.5 - 9 (Surge voltage 12.5V, 100ms max) DC9 - 18 (Surge voltage 25V, 100ms max)
INPUT
CURRENT[A]
EFFICIENCY[%]
VOLTAGE[V] 3.3 5 12 15 3.3 5 12 15
OUTPUT
PROTECTION
CIRCUIT AND
OTHERS
CURRENT[A]
LINE REGULATION[mV]
LOAD REGULATION[mV]
RIPPLE[mVp-p]
RIPPLE NOISE[mVp-p]
TEMPERATURE
REGULATION[mV]
DRIFT[mV]
START-UP TIME[ms]
OUTPUT VOLTAGE SETTING[V]
OVERCURRENT PROTECTION
REMOTE ON/OFF Provided (Negative logic L : ON, H : OFF)
2.6 2.0 0.9 0.7 2.6 2.0 0.9 0.7
*2
*2
MODEL
MAX OUTPUT WATTAGE[W] 8.58 10.0 10.8 10.5 8.58 10.0 10.8 10.5
DC OUTPUT
VOLTAGE[V]
CURRENT[A]
MGS10053R3 MGS100505 MGS100512 MGS100515 MGS10123R3 MGS101205 MGS101212 MGS101215
*1
2.02typ 2.30typ 2.46typ 2.39typ 0.83typ 0.94typ 1.02typ 0.99typ
*1
85typ 87typ 88typ 88typ 87typ 89typ 89typ 89typ
20max 20max 48max 60max 20max 20max 48max 60max
20max 20max 48max 60max 20max 20max 48max 60max
Io=30% -
75max 75max 100max 100max 75max 75max 100max 100max
Io=0 - 30%
225max 225max 300max 300max 225max 225max 300max 300max
Io=30% -
120max 120max 150max 150max 120max 120max 150max 150max
Io=0 - 30%
300max 300max 400max 400max 300max 300max 400max 400max
-20 to +50C
50max 50max 150max 180max 50max 50max 150max 180max
-40 to +50C
80max 80max 240max 290max 80max 80max 240max 290max
*
3
20max 20max 48max 60max 20max 20max 48max 60max
30max (Minimum input, Io=100%)
3.21 - 3.42 4.90 - 5.21 11.64 - 12.36 14.55 - 15.45 3.21 - 3.42 4.90 - 5.21 11.64 - 12.36 14.55 - 15.45
Works over 105% of rating and recovers automatically
MGS10243R3 MGS102405 MGS102412 MGS102415 MGS10483R3 MGS104805 MGS104812 MGS104815
*1
3.3 5 12 15 3.3 5 12 15
2.6 2.0 0.9 0.7 2.6 2.0 0.9 0.7
SPECIFICATIONS
INPUT
OUTPUT
PROTECTION
CIRCUIT AND
OTHERS
MODEL
VOLTAGE[V] DC18 - 36 (Surge voltage 50V, 100ms max) DC36 - 76 (Surge voltage 100V, 100ms max)
CURRENT[A]
EFFICIENCY[%]
VOLTAGE[V] 3.3 5 12 15 3.3 5 12 15
CURRENT[A]
LINE REGULATION[mV]
LOAD REGULATION[mV]
RIPPLE[mVp-p]
RIPPLE NOISE[mVp-p]
TEMPERATURE
REGULATION[mV]
DRIFT[mV]
START-UP TIME[ms]
OUTPUT VOLTAGE SETTING[V]
2.6 2.0 0.9 0.7 2.6 2.0 0.9 0.7
*2
*2
OVERCURRENT PROTECTION
REMOTE ON/OFF Provided (Negative logic L : ON, H : OFF)
MGS10243R3 MGS102405 MGS102412 MGS102415 MGS10483R3 MGS104805 MGS104812 MGS104815
*1
0.42typ 0.47typ 0.50typ 0.49typ 0.21typ 0.24typ 0.25typ 0.25typ
*1
87typ 89typ 90typ 90typ 87typ 89typ 90typ 90typ
20max 20max 48max 60max 20max 20max 48max 60max
20max 20max 48max 60max 20max 20max 48max 60max
Io=30% -
75max 75max 100max 100max 75max 75max 100max 100max
Io=0 - 30%
225max 225max 300max 300max 225max 225max 300max 300max
Io=30% -
120max 120max 150max 150max 120max 120max 150max 150max
Io=0 - 30%
300max 300max 400max 400max 300max 300max 400max 400max
-20 to +50C
50max 50max 150max 180max 50max 50max 150max 180max
-40 to +50C
80max 80max 240max 290max 80max 80max 240max 290max
*
3
20max 20max 48max 60max 20max 20max 48max 60max
30max (Minimum input, Io=100%)
3.21 - 3.42 4.90 - 5.21 11.64 - 12.36 14.55 - 15.45 3.21 - 3.42 4.90 - 5.21 11.64 - 12.36 14.55 - 15.45
Works over 105% of rating and recovers automatically
MG-8
GENERAL SPECIFICATIONS
ISOLATION
ENVIRONMENT
SAFETY AGENCY APPROVALS UL60950-1, C-UL, EN60950-1
OTHERS
*1 Rated input 5V, 12V, 24V or 48V DC Io=100%
*2
*3 Drift is the DC output accuracy for eight hours period after a half-hour warm-up at 25C.
* Parallel operation with other model is not possible.
INPUT-OUTPUT DC1,500V or AC1,000V 1minute, Cutoff current=10mA, DC500V 1,000MW min (20±15C)
OPERATING TEMP.,HUMID.AND ALTITUDE
STORAGE TEMP.,HUMID.AND ALTITUDE
VIBRATION 10 - 55Hz 98.0m/s
IMPACT 490.3m/s
-40 to +85C, 20 to 95%RH (Non condensing) (Required derating), 5,000m (16,400feet) max
-40 to +100C, 20 to 95%RH (Non condensing), 9,000m (30,000feet) max
2
2
(50G) 11ms, once each along X, Y and Z axis
(10G), 3minute period, 60minutes each along X, Y and Z axis
CASE SIZE/WEIGHT 22.0X12.0X9.5mm [0.87X0.48X0.38 inches] (WXHXD) / 7g max
COOLING METHOD Convection/Forced air
Ripple and r
ipple noise is measured by using test board with ceramic capacitor 1
F at 50mm from output pins.
External view
MGS10
2.54
[0.1]
－
Vin＋Vin RC NC＋Vout－Vout NC
17.78
[0.7]
22
[0.87]
0.5
[0.02]
Model
0.5
2.11
[0.09]
0.25
12
[0.02]
3.5
[0.01]
9.5
[0.48]
[0.14]
[0.38]
2.8
[0.11]
¶
Recommended Pad and Hole dia.
(TOP VIEW)
¶ Tolerance ±0.5 [±0.02]
¶ Dimensions in mm, [ ]= inches
¶ Pin terminal material : Copper
¶ Planting treatment of terminal : Lead free plating
¶ Case material : PBT
¶ Weight 7g max
7-f0.9
¶¶Unit : 0.1inch
Dimension : mm
