Evaluation Report
Corsair iCUE 465X RGB
TEST EQUIPMENT
Test Environment Hemi-Anechoic Chamber with 6 dB(A) noise floor
Conditions 25(±2) degrees Celsius, 40-50% humidity
Sound Analyzer Bruel & Kjaer 2270-S G4 & 2250-L G4
Microphone Bruel & Kjaer Type 4955-A
Mic Calibrator Bruel & Kjaer Type 4231
Data Logger Picoscope TC-08
All data and graphs included in this test report can be used by any individual on the following conditions:
› It should be mentioned that the test results are provided by Cybenetics
› The link to the original test results document should be provided in any case
Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient
and silent power supplies are promoted
PAGE 1/9
info@cybenetics.com
4004 MESA GEITONIA, LIMASSOL, CYPRUS
EFFICIENCY AND NOISE
LEVEL CERTIFICATIONS
www.cybenetics.com
Evaluation Report
Corsair iCUE 465X RGB
TECHNICAL SPECIFICATIONS TABLE
Brand Corsair
Product Name iCUE 465X RGB
Type Midi Tower
Dimensions (L x W x H) 467 x 216 x 455mm
Motherboard Support Mini-ITX, Micro-ATX, ATX
Removable Motherboard Tray No
Front Door/Cover Yes (Glass)
Materials Body Steel, Plastic, Tempered Glass
Materials Side Panel
Expansion Slots 7x (plus two vertical)
Drive Bays
I/O Panel Power, 2x USB 3.0, 1x audio/mic combo jack, Reset Button
Left: Tempered Glass
Right: Steel
3.5 " : 2x Internal
2.5" : 4x Internal
Front: 3x 120mm RGB Fans ( 600 -1500 +/-10% RPM)
Pre-installed Fan(s)
Fan Support
Fan Bearing Type Hydro Dynamic Bearing (HDB)
Fan Power Connector 4-Pin (PWM)
Fan/LED Controller 3-stage fan controller & RGB button
Radiator Support
CPU Cooler Height (Max) 170mm
VGA Length (Max) 370mm
PSU Length (Max) 180mm
Cable Management Support Yes
Dust Filters Top, Bottom, Front
PSU Support Bottom Mount, ATX
Rear: No
Top: No
Front: 3x 120mm / 2x 140mm
Top: 2x 120mm / 1x 140mm
Rear: 1x 120mm
Front: 280/360mm
Top: 240mm
Rear: 120mm
Weight 8.16 kg
Warranty 2-years
All data and graphs included in this test report can be used by any individual on the following conditions:
› It should be mentioned that the test results are provided by Cybenetics
› The link to the original test results document should be provided in any case
Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient
and silent power supplies are promoted
PAGE 2/9
info@cybenetics.com
4004 MESA GEITONIA, LIMASSOL, CYPRUS
EFFICIENCY AND NOISE
LEVEL CERTIFICATIONS
www.cybenetics.com
Evaluation Report
Stock Fan(s) RPM
Corsair iCUE 465X RGB
INFO
Stock Fan Speed from 40% to 100%
Stock Fan(s) Noise Output – LAeq
INFO
Stock Fan Noise Output from 40% to
100%
All data and graphs included in this test report can be used by any individual on the following conditions:
› It should be mentioned that the test results are provided by Cybenetics
› The link to the original test results document should be provided in any case
Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient
and silent power supplies are promoted
PAGE 3/9
info@cybenetics.com
4004 MESA GEITONIA, LIMASSOL, CYPRUS
EFFICIENCY AND NOISE
LEVEL CERTIFICATIONS
www.cybenetics.com
Evaluation Report
GPU Fan(s) Noise Output – LAeq
Corsair iCUE 465X RGB
NVIDIA GeForce GTX 970 Noise Output from 40% to 100% Fan Speed
All data and graphs included in this test report can be used by any individual on the following conditions:
› It should be mentioned that the test results are provided by Cybenetics
› The link to the original test results document should be provided in any case
Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient
and silent power supplies are promoted
PAGE 4/9
info@cybenetics.com
4004 MESA GEITONIA, LIMASSOL, CYPRUS
EFFICIENCY AND NOISE
LEVEL CERTIFICATIONS
www.cybenetics.com
Evaluation Report
Noise Output LAeq – Test Tones
Corsair iCUE 465X RGB
INFO
Noise Output in DB(A) from 100 Hz to 20
kHz
Noise Output LZeq – Test Tones
INFO
Noise Output in DB(Z) from 100 Hz to 20
kHz
All data and graphs included in this test report can be used by any individual on the following conditions:
› It should be mentioned that the test results are provided by Cybenetics
› The link to the original test results document should be provided in any case
Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient
and silent power supplies are promoted
PAGE 5/9
info@cybenetics.com
4004 MESA GEITONIA, LIMASSOL, CYPRUS
EFFICIENCY AND NOISE
LEVEL CERTIFICATIONS
www.cybenetics.com
Evaluation Report
Noise Dampening Performance LAeq – Test Tones
Corsair iCUE 465X RGB
Noise Dampening Performance in dB(A) from 100 Hz to 20 kHz
All data and graphs included in this test report can be used by any individual on the following conditions:
› It should be mentioned that the test results are provided by Cybenetics
› The link to the original test results document should be provided in any case
Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient
and silent power supplies are promoted
PAGE 6/9
info@cybenetics.com
4004 MESA GEITONIA, LIMASSOL, CYPRUS
EFFICIENCY AND NOISE
LEVEL CERTIFICATIONS
www.cybenetics.com
Evaluation Report
Noise Dampening Performance LZeq – Test Tones
Corsair iCUE 465X RGB
Noise Dampening Performance in dB(Z) from 100 Hz to 20 kHz
All data and graphs included in this test report can be used by any individual on the following conditions:
› It should be mentioned that the test results are provided by Cybenetics
› The link to the original test results document should be provided in any case
Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient
and silent power supplies are promoted
PAGE 7/9
info@cybenetics.com
4004 MESA GEITONIA, LIMASSOL, CYPRUS
EFFICIENCY AND NOISE
LEVEL CERTIFICATIONS
www.cybenetics.com
Evaluation Report
Noise Dampening Performance LAeq – Pink & Chirp
Corsair iCUE 465X RGB
INFO
Chirp & Pink Noise Noise Dampening
Performance (dB[A])
Noise Dampening Performance LZeq – Pink & Chirp
INFO
Chirp & Pink Noise Noise Dampening
Performance (dB[Z])
All data and graphs included in this test report can be used by any individual on the following conditions:
› It should be mentioned that the test results are provided by Cybenetics
› The link to the original test results document should be provided in any case
Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient
and silent power supplies are promoted
PAGE 8/9
info@cybenetics.com
4004 MESA GEITONIA, LIMASSOL, CYPRUS
EFFICIENCY AND NOISE
Case Photo #2
QR Code
LEVEL CERTIFICATIONS
www.cybenetics.com
Evaluation Report
Corsair iCUE 465X RGB
All data and graphs included in this test report can be used by any individual on the following conditions:
› It should be mentioned that the test results are provided by Cybenetics
› The link to the original test results document should be provided in any case
Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient
and silent power supplies are promoted
PAGE 9/9
