Assembly Instructions
Caution: This Table is NOT a TOY.
Keep your child / children at bay during the assembly process.
Whenever lifting or moving the Table and to prevent damage to the Table, two adults
may be needed to execute these actions.
Caution: You must read this before you proceed
Table
1
Label Picture Description Qty
A
Table Top
1
B
Leg
4
Label
Picture Description Qty
① Allen Key 2
②
Bolt
(M8*55mm)
9
③
Washer
(M8.5*2mm)
9
④
Spring
Washer
(M8.5*2mm)
9
Parts List
Hardware
2
Overview
Assembly Steps
Before Beginning Assembly:
Assembly Preparation
This Table has multiple parts and may require up to 30 minutes to assemble. To give
you an overview of the Table parts, the above picture is to help you put the various parts
into perspective. Please read through the instructions below to familiarise youself with
the parts and steps before assembly.
Table Top (A)
Leg (B)
FRONT FACING
3
Step 1
Attach Leg(B) to Table Top(A) using Bolts(②), Washers(③), and Spring Washers(④)
with Allen Key(①).
Do not fully tighten the Bolts.
Repeat the same process with the remaining three Legs(B).
Step 2
Unpack and place all parts on a clean, non-marring surface.
With assistance from your adult partner, carefully place the Table Top(A) facedown.
4
Step 3
When tightening the Bolts tighten sequentially.
Do not tighten any Bolt fully and then move on towards the next one.
If there are still wobbles, loosen the Bolts and excute the same above process.
Your Table is ready for use.
This Table can only be used on the flat, level surface.
5
Stand the Table up, with assistance from your adult partner.
Exert pressure floorwards, onto the Table with both your hands.
This pressure will help the Legs and Table Top reach full alignment status.
Check for wobbles on a LEVEL surface.
If no wobbles are found proceed to tighten the Bolts in a sequential manner, until evenly
secured.
