Wireless Thermostat
CCRC30F-KIT
OWNER’S MANUAL
CCRC30F-KIT
FEA
TURES:
Current
Temperature
Target Temperature
Automatic
ON/OFF
°C/°F
Switchable
Room
Thermostat
433
MhzRFtechnology
13A,3250W
250V,50HZ
When the
TARGET
temperature is higher
than the CURRENT temperature:
1. INTRODUCTION
Congratulations on your purchase of this
Wireless Thermostat, CCRC30F-KIT
Please take the time to read and understand
this manual so you can begin to enjoy the
convenience and features this product brings to you.
The wireless thermostat is suitable for many kinds of
It will automatically turn on/off heating device as
the ambient temperature changing,in order to maintain
a constant room temperature.
Green LED indicator
LCD
part: Display wireless thermostat
ON or OFFstatus
LCD
part: Display the CURRENT
temperature
in °C/°F
LCD
part: Display the TARGET
temperature
in °C/°F
LEFT
button: + / ON, Set the target
temperature/
Always ON
RIGHT
button: - / OFF,Set the target
temperature/
Always OFF
Red LEDindicator and LOGO Label
The child protection Plug,UK Type
Rating Label
The childprotection Socket,UK
Type
Press or to choosethe target temperature:
Resolution:±1
°C or 1
Fig.1
Fig.2
7. ALWAYS ON
Users can manually change the work mode to Always ON
or Always OFF whatever the thermostat is in ON or OFF status:
Hold and press more than 3 seconds.
Always ON Mode:
Hold and press more than 3 seconds
As the heating device working,the CURRENT
temperature will be increasing and approach the
same as the TARGET temperature:
1.InFigure2,CURRENT
(30
°
C
≥
TARGET
(30
°
C
)
2.
The
wireless
thermostat
sends
commands
to
all
the sockets to turn OFF CCRC30F-PLUG.
3.
LCD
display
OFF
symbol
4.
LED
indicatorisOFF
5.
All
the
sockets
remain
OFF
status
until
the
temperature drops 1°C (TARGET - 1°C
.)
in this case the ON commandis sent to
all the sockets, turn ON the connected heating device once again..
So
theroom temperature willautomatically remain:
Room Temp.≥Target Temp.-1
1.InFigure1,CURRENT
(20°C)<
TARGET
(30°C)
2.
The
wireless
thermostat
sends
commands
to
all
the
sockets to turn ON the connected heating device.
3.
LCD
displayONsymbol
4.
The
red
LED
indicatorisON
5.
The
connected
heating
device
willbein
working
status to warm the house.
°C/ °F Switchable:
Hold and press & at the same time
about 3 seconds, then it will swtich between °C/ °F
9. SPECIFICAITON
CURRENT
temp.
range:0°
C~60°Cor32°F~140°F
TARGET
temp.
range:0°C~60°Cor32°F~140°F
Temperature
Resolution
:±1°Cor±1°
F
Each
PressofLEFT/RIGHT
Button:±1°Cor±1°
F
2pcs*1.5V
AA
battery
Wall
Mount
Holder&Table
Stand
CCRC30F-PLUG , Plug in Socket:
Connection:
250V~50Hz
Transmission
frequency:
433.92
MHz
Maximum
Rating:
3250W,13
A
Maximum
range:40metersinopen
area
EU,French,UK,Italy,Swiss,US
A
plug
/socket
optional
2. DESCRIPTION
3. DESCRIPTION
4. AUTO CODING
5. AUTO OPERATION
6. AUTO OPERATION
The red
+ / ON - / OFF
+ / ON - / OFF
Thermostat controal is always in transmitting status,when
RC30F-PLUG is plugged into home electricity for the first
time,the red LED indicator will be flashing, this means
it is in auto coding status:
If can’t search any transmite signal from thermsotat control unit
It will flash 2 minutes and then exit the coding progress.
If can search transmite signal, it will be back to normal.
It means coding sucessful.
Multi-Channels
Always ON/OFF
°
F
Always OFF Mode:
Wireless thermostat will be change to
Always OFF status,the connected heater
will be always OFF.
And the Target temperature will be disappear
from the LCD, LCD part shows OFF,all the
connected socket is kept OFF status,shows in Fig 4.
Wireless thermostat will be change to
Always ON status, the connected heater
will be always heating.
And the Target temperature will be disappeared
from the LCD, LCD part shows ON,all the
connected socket is kept ON status,shows in Fig 3.
It will be back to auto operaion just by keep pressing once again
more than 3 seconds
It will be back to auto operaion just by keep pressing once again
more than 3 seconds
MemoryFunction:
All the settings will be memoried even if cut off power
It includes code pairing method, target temperature settings.
CCWT450RCF, Remote thermostat control:
Low Battery Warning:
This product can be with 2pcs*1.5VAA battery,
symbol will be flashing when the battery is lower
than 2.7V,
C/
=
)
Target Temp.≥
8. ALWAYS OFF
Fig.3
Fig.4
Low Battery Warning
Memory Settings
heating device and protect some home appliances.
Thermostat control will detect temperature and transmit signal
every 20 seconds, so there are some time delay in auto operation.
Low Temperature Warning
High Temperature Warning
