Corning Optical Communication Wireless MA1K-CELL-PCSE Users manual

MobileAccess™ 1000 System

Installation and Configuration Guide

709C001501
UM-1000 Ver. 2.4
February, 2005

MA 1000 Installation and C o nfiguration Guide

MobileAccess 1000

© 2005 by MobileAccess

This document contains confidential and proprietary information of MobileAccess and may
not be copied, transmitted, stored in a retrieval system or reproduced in any format or
media, in whole or in part, without the prior written consent of MobileAccess. Information
contained in this document supersedes any previous manuals, guides, specifications, data
sheets or other information that may have been provided or made available to the user.
This document is provided for informational purposes only, and MobileAccess does not
warrant or guarantee the accurac y, adequacy, quality, validity, completeness or suitabilit y
for any purpose of the information contained in this docume nt. MobileAccess reserves the
right to make updates, improvements and enhancements to this document and the products
to which it relates at any time without prior notice to the user. MOBILEACCESS MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH RESPECT TO THIS
DOCUMENT OR ANY INFORMATION CONTAINED HEREIN.

MobileAccess Ltd. Vienna, Virginia Tel: [phone]

MobileAccess Ltd. Lod, Israel Tel: [phone]

http://www.MobileAccess.com

Email: [e-mail]

Copyright © 2006 MobileAccess.

Trademark acknowledgement

MobileAccess
trademarks, trade names and service marks of MobileAccess and other organizations, all of
which are the property of their respective owners.

II

TM

is a registered trademark of MobileAccess. This document contains other

MA 1000 Installation and C o nfiguration Guide

Policy For Warrantee And Repair

MobileAccess tests and inspects all its products to verify their quality and reliability.
MobileAccess uses every reasonable precaution to ensure that each unit meets their
declared specifications before shipment. Customers should advise their incoming i nspection,
assembly, and test personnel about the precautions required in handling and testing our
products. Many of these precautions can be found in this manual.

The products are covered by the following warranties:

General Warranty

MobileAccess warrants to the original purchaser a ll standard products sold by M obileAccess
to be free of defects in material and workmanship for one (1) year from date of shipment
from MobileAccess. During the warranty period, MobileAccess will repair or replace any
product that MobileAccess proves to be defective. This warranty does not apply to any
product that has been subject to alteration, abuse, improper installation or application,
accident, electrical or environmental over-stress, negligence in use, storage, transportation
or handling.

Specific Product Warranty Instructions

All MobileAccess products are warranted against defects in workmanship, materials and
construction, and to no furt her e xtent. An y claim for repair or re placement of unit s found t o
be defective on incoming inspection by a customer must be made within 30 days of receipt
of shipment, or within 30 days of discovery of a defect within the warranty period.

This warranty is the only warranty made by MobileAccess and is in lieu of all other
warranties, expressed or implied. MobileAccess sales agents or representatives are not
authorized to make commitments on warranty returns.

Returns

In the event that it is necessary to return any product against above warranty, the following
procedure shall be followed:

1. Return authorization is to be received from MobileAccess prior to
returning any unit. Advise MobileAccess of the model, serial number,
and discrepancy. The unit may then be forwarded to MobileAccess,
transportation prepaid. Devices returned collect or without
authorization may not be accepted.

2. Prior to repair, MobileAccess will advise the customer of our test results
and any charges for repairing customer-caused problems or out-of­warranty conditions etc.

3. Repaired products are warranted for the balance of the original
warranty period, or at least 90 days from date of shipment.

III

MobileAccess's liability on any claim, of any kind, including negligence for any loss or
damage arising from, connected with, or resulting from the purchase order, contract,
quotation, or from the performance or breach thereof, or from the design, manufacture,
sale, delivery, installation, inspection, operation or use of any equipment covered by or
furnished under this contact, shall in no case exceed the purchase price of the device which
gives rise to the claim.

EXCEPT AS EXPRESSLY PROVIDED HER EIN, MOBILEACCESS MAKES NO WARRANTY, EXPRESSED OR IMPLIED,
WITH RESPECT TO ANY GOODS, PARTS AND SERVICES PROVIDED IN CONNECTION WITH THIS AGREEMENT
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. MOBILEACCESS SHALL NOT BE LIABLE FOR ANY OTHER DAMAGE INCLUDING, BUT NOT
LIMITED TO, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH
FURNISHING OF GOODS, PAR TS AND SERVICE HERE UNDER, OR THE P ERFORMANCE, U SE OF, OR INABILITY TO
USE THE GOODS, PARTS AND SERVICE.

Reporting Defects

MA 1000 Installation and C o nfiguration Guide

Limitations Of Liabilities

The units were inspected before shipment and found to be free of mechanical and electrical
defects.

Examine the units for any damage that may have been caused in transit. If damage is
discovered, file a claim with the freight carrier immediately. Notify MobileAccess as soon as
possible.

NOTE: Keep all packing material until you have completed the inspection

WARNING: To comply with FCC RF exposure compliance requirements, antennas used

for this product must be fixed mounted on indoor permanent structures, providing a
separation distance of at least 20 cm from all persons during normal operation.

WARNING: Antenna gain should not exceed 10dB.
WARNING: Each individ ua l antenna used for t his transmitter must be insta lled to provide a

minimum separation distance of 20 cm or more from all persons and must not be co-located
with any other antenna for meeting RF exposure requirements.

WARNING: The design of the antenna installation needs to be implemented in such a way
so as to ensure RF radiation safety levels and non- environmental pollution during
operation.

ATTENTION:

Compliance with RF safety requirements:

• MobileAccess™ products have no inherent significant RF radiation.

• The RF level on the down link is very low a t the Remote Units (RHUs) downlink ports.

Therefore, there is no dangerous RF radiation when the antenna is not connected.

IV

MA 1000 Installation and C o nfiguration Guide

Laser Safety

LASER WARNING

Fiber optic ports of the M o bile Access 10 00/ 20 00 em it invisible la ser ra dia tion at t he 1 310 nm w ave length
window.

To avoid eye injury never l ook directly into the optical ports, pa tchcords or optical cables. Do not stare
into beam or view directly with optical instruments. Always assume that optical outputs are on.

Only technicians familiar with fiber optic safety practices and procedures should perform optical fiber
connections and disconnections of the MobileAccess 1000/2000 module s and the associated cables.

The MobileAccess 10 00/2000 complies with 21 CFR 1 040.10 and 1040.1 1 except for devia tions p ursuant
to Laser Notice NO. 50 (July 26, 2001) & IEC 60825-1, Amendment 2 (Jan. 2001).

Care of Fiber Optic Connectors

F/O Connectors Cauti on s
Do not remove the protective covers on the fiber optic connectors until a connection is ready to be

made. Do not leave connectors uncovered when not connected.
The tip of the fiber optic connector should not come into contact with any object or dust.
Refer to the cleaning procedure for information on the cleaning of the fiber tip.

Certification

MobileAccess prod ucts have met the approval s of t h e fol l owing certifying organizations:

ISO 9001

For US: FCC 47 CFT part 22,24,90

FDA-CDRH

For Canada: RSS-118, RSS-119, RSS-133

…

.

V

MA 1000 Installation and C o nfiguration Guide

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

-- Consult the dealer or an experienced radio/TV technician for help.

Warning!

Changes or modifications to this equipment not expressly approved by Mobile Access Ltd. could void the
user’s authority to operate the equipment.

VI

MA 1000 Installation and C o nfiguration Guide

Preface

This user guide provides all the information necessary to install and configure the
MobileAccess 1000 System.

Revision History

The revision history for this document is shown in Table 1-1.

Table 1-1: Revision history

Version Date Description

1.0 April 2003 Initial version.

2.0 October 2003 Updated version to MobileAccess.

2.1 November 2003 Review and editing

2.2 December 2003 Adding and updating RHU 1200

2.3 August 2004 Connections of RIU connections
1200 Add-on - update

2.4 Jan 2005 Laser warnings and maximum current

VII

MA 1000 Installation and C o nfiguration Guide

Table of Contents

1 Introduction ..........................................................................................................................1

1.1 About MobileAccess™ 1000 ..........................................................................................................1

1.1.1 Features ............................................................................................................................2

1.2 System Architecture .....................................................................................................................3

1.3 Configuration Options...................................................................................................................3

1.4 MA 410/430 Remote Management ................................................................................................5

1.5 MobileAccess Models....................................................................................................................6

2 System Elements ...................................................................................................................9

2.1 Remote Modules ..........................................................................................................................9

2.1.1 MA 1000 RHUs ...................................................................................................................9

2.1.1.1 RHU 1000 Front Panel ..........................................................................................10

2.1.1.2 RHU 1000 Rear Panel ...........................................................................................11

2.1.2 MA 1200 Add-on...............................................................................................................12

2.1.2.1 MA 1200 Front Panel ............................................................................................12

2.1.2.2 MA 1200 Rear Panel .............................................................................................13

2.1.3 MA-850 Module ................................................................................................................13

2.1.3.1 MA 850 Front Panel ..............................................................................................14

2.1.3.2 MA 850 Rear Panel ...............................................................................................15

2.2 Radio Interface Unit (RIU)..........................................................................................................16

2.2.1.1 RIU Front Panel....................................................................................................17

2.2.1.2 RIU Rear Panel..................................................................................................... 18

2.3 MA Base Units............................................................................................................................18

2.3.1.1 MA BU Front Panel ...............................................................................................19

2.3.1.2 BU Rear Panel......................................................................................................20

2.4 MobileAccess NMS System..........................................................................................................21

3 Site Preparation...................................................................................................................23

3.1 Infrastructure Preparation ..........................................................................................................23

3.2 Installation Requirements...........................................................................................................23

3.3 Coaxial Cable Connections..........................................................................................................23

3.3.1 General Cable Installation Proce dures................................................................................23

3.3.2 Fiber Optic Rules ..............................................................................................................24

3.3.3 RF Rules ..........................................................................................................................24

3.4 Power Consumption, Connections and Power Supplies .................................................................25

VIII

MA 1000 Installation and C o nfiguration Guide

3.4.1 Power Safety Instructions ................................................................................................. 25

3.4.2 Power Consumption of Units .............................................................................................25

3.4.3 Circuit Breakers................................................................................................................26

3.4.4 Types of Power Supplies...................................................................................................26

3.5 Installation Conventions .............................................................................................................27

4 System Installation.............................................................................................................29

4.1 Overview...................................................................................................................................29

4.2 Communication Room Installation...............................................................................................29

4.2.1 Rack Installation General Instructions................................................................................30

4.2.2 Rack Installation Safety I nstructions..................................................................................30

4.2.3 Single Building Rack Installation ........................................................................................31

4.2.4 Multi-Building Rack Installation..........................................................................................32

4.2.5 RIU Connections...............................................................................................................33

4.2.5.1 Basic Connections ................................................................................................33

4.2.5.2 Connections to Additional BUs...............................................................................34

4.2.6 BU Connections................................................................................................................34

4.2.7 Controller Connections......................................................................................................34

4.3 Remote Site Installation .............................................................................................................35

4.3.1 RHU 1000 Installation.......................................................................................................35

4.3.1.1 Wall Mount ..........................................................................................................35

4.3.1.2 Connections.........................................................................................................36

4.3.2 MA 1200 Add-on Installation .............................................................................................36

4.3.2.1 Assembly and Connections....................................................................................36

4.3.3 Antenna Connections........................................................................................................38

5 Appendix I: Optical Test Procedures .................................................................................. 39

5.1 General .....................................................................................................................................39

5.2 Optical Loss Testing...................................................................................................................39

5.2.1 Required Test Equipment..................................................................................................39

5.2.2 Test Procedure.................................................................................................................40

5.2.3 Example...........................................................................................................................41

5.3 Optical Back-reflection Testing....................................................................................................42

5.3.1 Required Test Equipment..................................................................................................42

5.3.2 Test Procedure.................................................................................................................42

IX

11

IInnttrroodduuccttiioonn

1.1 About MobileAccess™ 1000

MobileAccess™ 1000 converged wireless networks solutio n provides scalable in-building
coverage for multiple wireless data and voice services through a single c oax and broadband
antenna infrastructure.

The solution is based on combining a number of services, both voice and data, at each
covered location and distributing them through a common antenna infrastructure.

Figure 1-1. MA 1000 System Overview

Voice services are transmitted between the BTS side and the locations via optic fiber after
the appropriate conversion from RF to optic, and reconverted to RF at each end. The MA
1000 system provides entry level solutions that can be upgraded

infrastructure

Wireless 802.11/a/b/g coverage may be integrated into the MA 1000 system usi ng the MA
850 remote module (that supports wireless LAN service distribution).

to support additional services as required.

1

using the same

MA 1000 Installation and C o nfiguration Guide

To optimize system coverage under changing environmental conditions or load, as well as to
enable remote monitoring of all system elements from a central location, MobileAccess
provides the following MA 1000 system enhancement solutions:

• Manageable BTS interface devices that control the level of the BTS signal fed into
the system (Radio Interface Unit)

• Network Management System (NMS) consisting of controllers, adjustment and
management software

1.1.1 Features

• Support for all current and future technologies such as TDMA, CDMA, WCDMA and
GSM, and services such as PCS/CELLULAR, Paging, iDEN and 802.11 (a/b/g)
Wireless LAN

• All services are distributed through a

• All active components are located in the communication closet/room

• Modular, scalable and future-safe – additional remote units can

• Support for remote monitoring through MA 410/430 controllers

single

coax and antenna infrastructure

easily

be installed

• Eliminates RF interferences occurring where multiple antenna systems are used to
serve multiple services

• Enables fast deployment for corporate enterprises, property owners and WSP’s of
new services

• Reduces tenant disruption

• Low power required by the system eliminates the need for high power BTS/RBS,

reducing operator expenses

• Provides both local and remote monitoring and control capabilities

• Software programmable parameters including output power, AGC (on/off and

levels), and system gain

• Real time component setting capabilities for optimal performance (aging,
temperature, optical connectors, etc.,)

2

MA 1000 Installation and C o nfiguration Guide

1.2 System Architecture

The MA 1000 solution is based on the followi ng main elements:

• MA Base Units (BUs) – The BUs perform RF to optic conversion on the BTS side.

• MA Remote Hub Units (RHUs) 1000 – The MA 1000 performs the RF to optic

signal conversion at the antenna side for up to two services corresponding to the
RHU model. A third service can be added by connecting an add-on remote hub unit
(MA 1200) to the RHU 1000.

• MA 850 – The MA 850 is a wireless LAN module that provides secure and
centralized connections for 802.11a/b/g Access Points and distributes the wireless
services over the same coax and broadband infrastructure as the voice services.

All services are combined and distributed through the same antenna broadband
infrastructure.

To provide optimum coverage at all times and monitoring and control of all system elements
from a central location MA provides the following devices:

• MA Radio Interface Units (RIUs) – The RIUs provide interfaces for up to three
BTS/BDA signals, and automatically adjusts the output signal in respose to input
signal level in order to provide optimal coverage.

• MA 410/430 controllers – The controllers enable remote monitoring of the
system elements from a

single location

via advanced intuitive GUI.

1.3 Configuration Options

The MobileAccess™ 1000/1200 system includes three basic configuration options:

A) Basic configuration

The Base Unit drives a single or dual band, MobileAccess™ 1000 RHU. The dual band
RHU consists of a low band service (cellular 800, iDEN, Paging, or GSM 900) and a high
band service (PCS 1900 or DCS 1800).

Figure 1-2. MobileAccess 1000 Basic BU – RHU Configuration

3

MA 1000 Installation and C o nfiguration Guide

B) Using the MobileAccess 1200 add-on unit to provide an additional service

A MobileAccess™ 1200 add-on unit can be connected to a MA RHU 2000 unit to provide
a third service. The add-on unit ca n be Cellular, PCS, UMTS, 3G, or any future service.

Figure 1-3. MobileAccess 1000/1200 BU – RHU Plus Add-On

C) Using the MobileAccess 800 WLAN module to provide access to high data-

rate service

A WLAN module (MobileAccess™ 800) may also be added in a configuration that
includes both RHU 1000 and RHU 1200 or only RHU 1000.

Figure 1-4. MobileAccess 1000/1200 BU – RHU Plus Add-on Plus WLAN Configuration

4

MA 1000 Installation and C o nfiguration Guide

1.4 MA 410/430 Remote Management

The MobileAccess (MA) Network Management System (NMS) provides complete site
coverage and network management. It can be used to provision coverage that can
compensate for changing loads. It also provides real-time monitoring, control and
diagnostics capabilities for

MobileAccess

NOTE: The MA NMS System is fully described in the MA NMS System Configuration and
Operation Guide.

The MA NMS system consists of:

• MA 410/430 Controller – The controller provides the interface between the
system elements and the management and control mechanism. Two controller
models are available:

• MobileAccess 410™ – enables management of the connected devices through a

local or point-to-point dial-up connection. It can be remotely managed through a
connection to the MobileAccess 430 controller.

devices from a single location.

• MobileAccess 430™ – enables management of all connected elements and all

connected MA 410 controllers and the corresponding elements. Supports SNMP
(Simple Network Management Protocol) over TCP/IP connection.

• MA 430 may be managed through the Network Operator Center (NOC) through

Manager of Mangers element such as HP OpenView via SNMP.

• MCT – a Java based GUI application pro vided with both controllers. The MCT is
used after the installation procedure to adjust MobileAccess devices according to
the installation site characteristics in order to optimize coverage for the site.

The application is installed and ran from a computer that is connected either locally or
via remote dial-up modem to the controller site to be adjusted or monitored.

• MobileAccess Manager™ – a Java based GUI software application that provides
enhanced monitoring and control capabilities for all your
single location; each site can consist of a standalone MA 430 controller, or a MA 430
controller in a Master top ology with a number of MA 410 controllers connected as
slaves. The MobileAccess Manager application is not supplied with the controller

purchased separately.

– it is

The MA NMS application is installed on a server and is accessed from any client by
connecting to the server from any Web Browser wit h enha nced Java VM capabilities.

MA 430™

sites from a

5

MA 1000 Installation and C o nfiguration Guide

MA NMS manager provides the following features and capabilities:

• Remote SNMP management from a single location

• Client/server management capability over a TCP/IP network with enhanced

monitoring and control capabilities

• Intuitive GUI that enables end-to-end fault sourcing from RIU to antennas. The GUI
includes:

• System status at a glance through multi-color tree wit h upward propagation of fault

indications

• Graphical view of system elements including LED status displays and auxiliary

connections

• Multi-color event monitoring display

•

RF Connections

1.5 MobileAccess Models

Table 1-1: MobileAccess™ BU Models

MobileAccess Universal Base Units (1000, 1200, 2000 support)

WB-B8U Wide Band Base 8 Unit supporting 8 RHUs
WB-B4U Wide Band Base 4 Unit supporting 4 RHUs

Table 1-2: MobileAccess™ RHU Models with Add-on Capabilities

MobileAccess 1000 RHUs (ready for add-on units)

1000S-CELL-4 Single band-Cellular, 4 ports
1000S-IDEN-4 Single band-iDEN, 4 ports
1000S-PCS-4 Single band-PCS 4 ports
1000D-IDE N-PCS4 Dual band-iDEN/PCS, 4 ports
1000D-SMR-PCS4 Dual band-SMR/PAGIN G/PCS, 4 ports
1000D-CELL-PCS4 Dual band-Cell/PCS, 4 ports
1000D-CELL-DCS4 Dual band Cell/DCS 4P ready for add-on units
1000D-CL-M-DCS4 Dual band Cell multi operator/DCS 4P ready for add-on units
1000D-GSM-DCS4 Dual band GSM/DCS 4P ready for add-on units
1000D-GSMO-DCS4 Dual band GSM orange/DCS 4P ready for add-on units

6
