Page 1
Coffee Maker
CCM-S10WH
0
Page 2
SAFETY REGULATION
Read all the instruction carefully. Keep this user manual for
future reference.
This appliance in not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
the use of appliance by a person responsible for their safety.
Use only original accessories supplied.
The current voltage which indicates on the plate must
correspond to your local voltage.
The appliance should be used only on condition that the type
of power supply corresponds to the marking label. Otherwise,
it will not work or even be damaged.
If the appliance falls into water, pull the power plug out from
the power socket immediately.
Never use the appliance unless it is fully assembled.
Do not overload outlets or extension cords. It can result in fire
or electric shock.
Do not use the appliance if the power supply cord or plug has
been damaged.
Unplug from outlet when not in use, before putting on or
taking off parts, and before cleaning.
The use of accessory attachments not recommended by
the appliance manufacturer may cause injuries.
1
Page 3
Do not immerse the cord, plug or appliance in water or other
PARTS IDENTIFICATION
2
types of liquid and do not pour water onto it to avoid from fire,
electrical shock or personal injury.
To protect against risk of electrical shock, do not force any
foreign objects such as pins and wires into any openings.
Never leave the empty carafe on the keeping warm plate
otherwise the carafe is liable to crack.
Never use the appliance if the carafe shows any signs of
cracks or carafe having a loose or weakened handle.
2
Page 4
1.
Water Tank Cover
6.
Bottom Cover
2.
Top Cover
7.
Filter
3.
Water Tank
8.
Funnel
4.
Main Housing
9.
Carafe
5.
ON/OFF Switch
Model
CCM-S10WH
Voltage
220-240V~
Frequency
50/60Hz
Power
750W
Capacity
1.25L
SPECIFICATION
OPERATING INSTRUCTIONS
Before Using
Carry out 2 or 3 boil-processes with fresh water (without
coffee). Once all the water has passed through, switch
off the appliance and let it cool down during 5 minutes.
Then repeat the process with fresh water.
Making Coffee
Fill the water tank with the required quantity of water.
Ensure that the water level is not lower than the
minimum mark and not higher than indication “MAX”.
Use fresh, cold water only. The number of cups can be
read on the water level window.
3
Page 5
Place the funnel into funnel holder and make sure the
funnel is assembled in place, and then put a paper filter
into funnel correctly.
Add proper coffee powder into paper filter. Usually a cup
of coffee need a level spoon of coffee powder, but you
may adjust according to personal taste, and then replace
the top cover.
Insert glass carafe with lid in place onto warming plate
horizontally, ensure center line of carafe aligns with that
of funnel.
Plug the unit into an outlet.
Press power switch to the “I” position, the indicator in it
will be illuminated and the appliance will begin working.
The brewing process can be interrupted by pressing the
switch to the “O” position at any time and the indicator in
it will go off, indicating your coffee maker is off. Once the
switch is pressed again to the “I” position, the appliance
will continue to brew.
NOTE: the appliance is designed with a pause-and-serve
feature, if you wish, at any time during brewing cycle, you can
temporarily remove carafe to pour and serve a cup of hot
coffee. The brewing cycle will not be interrupted and no coffee
will drip from the appliance, simply replace glass carafe onto
warming plate to restart the brewing cycle, But do not remove
glass carafe for longer than 30s, never return empty carafe
onto warming plate when it is still warm.
Remove carafe to serve when finish brewing
NOTE: the coffee you get will be less than the water you have
added as some water is absorbed by coffee powder.
CAUTION: When pour coffee, the momentary inclined angle
of carafe shall not be more than 45 degree from the vertical
position, you shall pour the coffee slowly until the carafe is
4
Page 6
empty, otherwise the coffee in the carafe will rush to the
CARE AND CLEANING
bottom of carafe lid, and the coffee will flow out from two
edges of lid and hurt person!
After brewing, the appliance will automatically switch to
the warming mode, which will continue to keep your
coffee warm until you turn off the appliance. It is
suggested that warming time shall be not more than 1
hour. For an optimum coffee taste, serve it just after
brewing.
Always turn the coffee maker off and unplug the
appliance when not in use.
CLEANING
Always remove the main plug from the wall socket
before cleaning the appliance.
Never immerse the appliance in water.
Wipe external surface with a damp cloth.
The carafe and the filter and the funnel can be washed
in hot soapy water.
5
Page 7
DESCALING
Descale your coffee maker regularly.
To keep your coffee maker operating efficiently,
periodically you should clean away the mineral deposits
left by the water according to the water quality in your
area and the use frequency, we recommend removing
mineral deposits as follows:
Fill the tank with water and declare to the max level as
indicated on water gauge (the scale of water and
declare is 4:1, the detail refers to the instruction of
declare. Please use “household declare”), you may also
use the citric acid instead of the declare (the one
hundred parts of water and three parts of citric acid).
Insert glass carafe onto the warming plate.
Make sure without coffee powder and funnel are
assembled in place.
Switch on the appliance and allow it to “brew” de-scaling
solution.
After “brew” one-cup solution, switch off the appliance.
Leave the solution stay for 15 minutes and repeat step
3-5.
Switch on the appliance and run off the solution until the
water tank is completely empty.
Rinse by operating the appliance with water at least 3
times.
6
Page 8
7
