Page 1
Table Top
Grill CCG-P38N
Page 2
General Safety Precautions
1. Thank you for your purchase of this appliance. Read all
instructions carefully. Keep this User Manual for future reference.
2. Always switch off and unplug the appliance from the electrical
outlet BEFORE cleaning and also when not in use.
3. Never immerse the appliance, power cord or plug into water or
other liquids. Please refer to the section on “Care and Cleaning”.
4. If it is a detachable power cord, always connect the power cord to
the appliance first BEFORE plugging it into the electrical outlet.
To disconnect the appliance, switch off the power on the electrical
outlet before removing the power plug.
5. Close supervision is necessary when operating the appliance
near children. Ensure that the power cord does not hang over the
work surface.
6. Do not operate the appliance with a damaged power cord set or
plug. Any repairs should always be carried out by an authorized
service centre.
7. Do not use the appliance for any purposes other than its intended
use. This appliance is intended for household use only.
8. Do not use the appliance in the outdoors or in a damp area.
9. Do not place the appliance on or near a hot gas or electric burner,
or near easily flammable materials.
10. This appliance should not be used by people who are physically
or mentally impaired (including children) unless proper guidance
is provided during operation.
Page 3
Parts Identification
Model No.
CCG-P38N
Rated Voltage
220-240V~
Rated Power
1650-1960W
Frequency
50/60Hz
1
2
3
4
5
1. Reversible Cooking Plate
2. Temperature Control Selector
3. Handle
4. Oil Tray
5. Supporting Base
Specifications
Page 4
Operating Instructions
Before using for the first time, wash the base, plate and oil tray
with lukewarm water. Dry thoroughly.
Place the oil tray on the base. To make subsequent cleaning
easier, cover the oil tray with aluminum foil. Oil collected can be
easily removed.
Important note: Please position plate correctly onto the power
base for proper operation. Decide which cooking surface is
required and place the plate over the oil tray. Use the guide tabs
on the handle to fit to slots on the supporting base.
Ribbed side is usually for foods such as meats and fish whilst the
flat plate is for cheese, vegetables and kebabs.
Insert the temperature control selector into the base, and then
switch it on. The temperature control selector will not fit into the
probe inlet if the plate has not been properly positioned on the
supporting base.
You may adjust the desired temperature while cooking.
When the indicator light is switched on, it is warming up
automatically. When indication light is switched off, it means your
desired temperature has already been reached.
Before cooking it is recommended to adjust the temperature to a
desired setting or to the maximum setting. You may start cooking
after 5 minutes when optimal temperature has been achieved.
After cooking, ensure the temperature control selector is in “OFF”
position. Only then should you remove the plug from the electrical
outlet.
CAUTION:
Do not scratch the plate surface. Use non-metallic utensils only.
Do not touch hot surfaces. Use oven mitts to remove plate by
holding the handles if the appliance is hot. Always place appliance
on a heat resistant surface.
Page 5
Extreme caution should be practiced when moving the plate which
contains hot liquids or oil.
Do not operate this appliance without the oil tray in place.
Care and Cleaning
Always disconnect the appliance from the electrical outlet before
cleaning.
Always allow your appliance to cool completely before cleaning.
Clean the exterior of the appliance using a damp cloth.
Never immerse the appliance completely in water or in any other
liquids.
Supporting base, oil tray and cooking plate may be washed in
lukewarm water and mild detergent. For dishwasher, place at the
top shelves for washing.
Wash plate and base with lukewarm water and dry thoroughly.
