Page 1
User Manual
Blender
CBL-S250M
Page 2
2
C O N T E N T S
IMPORTANT SAFEGUARDS
PARTS IDENTIFICATION
SPECIFICATIONS
IMPORTANT NOTES
OPERATING INSTRUCTIONS
SAFETY POWER CUT-OFF FEATURE & SAFETY BUILT-IN SWITCH
3
4
4
5
5-7
7
7
OPERATING INSTRUCTIONS
SAFETY POWER CUT-OFF FEATURE & SAFETY BUILT-IN SWITCH
Assemble the blender jar with the food onto the
main body. Plug in power plug into power supply
and adjust the control knob according to desired
speed.
1
2
0
1
2
P
After blending has completed, adjust the control
knob switch to ‘0’ position. Remove power plug
from power supply. Detach the blende r jar
according to diagram.
0
1
2
P
1
2
• This blender is fitted with a safety power cut-off feature which safeguards against
excessive loads. In case of overloading, the blender will automatically activate the
safety power cut-off protection and operation will come to a stop. If this occurs, set the
knob to OFF position, unplug the appliance and let it cool down to room temperature
before attempting to operate it again.
• The Safety built-in switch ensures that the appliance would only operate if the blender
jar is assembled correctly with main body.
Page 3
5
IMPORTANT NOTES
OPERATING INSTRUCTIONS
4
PARTS IDENTIFICATION
SPECIFICATIONS
• Never fill the blender jar with ingredients hotter than 65.
• Always ensure the lid is correctly assembled on the jar and the measuring cup is inserted
properly in the lid before powering on the appliance.
• Do not exceed the maximum indicator line of the blender jar when filling water and other
liquids.
• Always turn off the appliance and remove the power cord from the power supply after
every use.
• After blending has completed, allow hot foods to adjust to the room temperature before
serving
• Always keep the blender clean and dry after using.
• Please refer to the illustrations
• Ensure ingredients sizes do not exceed 2cmX2cmX2cm
• OPERATION TIME: Do not operate the blender more than 1 minute consecutively. Leave
the appliance to cool for 10 minutes before every re-use.
• CAUTION: If the blender gets stuck, cease operating blender immediately and remove
the obstruction.
• GRINDING TIME: Do not operate for more than 25 seconds each time. Ensure coffee
beans do not exceed the 30-80g. "Max" mark on the grinding cup. Allow a minute
interval before successive operating the blender again in order to prevent the appliance
overheating.
• CAUTION:
a) If the grinding blade is operating without grinding any food, power off and unplug
from the power supply, disassemble the grinding cup, shake the food and begin the
grinding function again
b) After grinding is finished, do not remove the grinding cup until the motor stops
• Use the following food test: carrot size less than 1.5cm x 1.5cm x 1.5cm with water
according to the rate (carrot 2:3 water) together. Ensure the total capacity does not
exceed 1.5L.
• Pour approx. 400–700ml water into the jar. Ensure the lid covers the jar properly and use
function ‘P’ for a few seconds.
2
1
3
4
5
6
7
6
8
9
1. Main body
2. Control knob
3. Measuring cup
4. Lid
5. Blender jar
6. Silicone sealing
7. Chopping blades
8. Grinding cup
9. Grinder unit
MODEL NO. CBL-S250M
RATED VOLTAGE / FREQUENCY 220-240V~ 50/60Hz
RATED WATTAGE 300-350W
CAPACITY 1250ml
Page 4
6
OPERATING INSTRUCTIONS
Place the Silicone sealing onto
the blender units according to
the diagram (Or remove for the
cleani ng. Ex-fac tory goods
have been fitted to the blender
units.)
Fit the blender blade unit onto
the blender jar according to the
diagram. Assemble the lid onto
the jar. Insert the measuring
cup properly in to the f ood
chute. (Note: the size of the
mixing ingredients should be
less than 2cm*2cm*2cm).
1
2
* Assemble the lid on the jar
* Insert the measuring cup
properly into the lid
1
2
Assemble the blender jar with
the food onto the main body.
Plug in power plug into power
supply and adjust the control
knob according to desired
speed.
1
2
0
1
2
P
After blending has completed,
adjust the control knob switch
to ‘0’ position. Remove power
pl ug fro m p ow er s upp ly.
De ta ch th e bl en de r j ar
according to diagram.
1
2
0
1
2
P
Place dry grinding food into
the grinding cup. Assemble the
grinder unit according to the
diagram.
1
2
3
IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS CAREFULLY BEFORE USE
• Before using the appliance, ensure that the power supply voltage corresponds to the
voltage indicated on the rating plate at the bottom of the appliance.
• In order to avoid electric shocks and other personal injuries, do not immerse the
appliance or other components such as power cord, power plug and motor base into
water or other liquids.
• This appliance is intended for household use only. Any other use is considered improper
and thus dangerous.
• Never allow this appliance to be used by persons (including children) with psychological,
physical or sensory impairments or with insufficient knowledge, unless closely
supervised and instructed by someone responsible for their safety. Always supervise
children and ensure they do not play with the appliance at all times.
• Never leave the appliance unattended while it is in operation.
• Never place hands into the blender jar when it is plugged into the power supply.
• Always operate the blender with the cover in place.
• Do not operate any appliance with a damaged cord or plug, or after the appliance
malfunctions, or is dropped or damaged in any manner. Return appliance to nearest
Customer Service Center (see Warranty for details) for examination, repair, and/or
mechanical or electrical adjustment.
• Always operate the blender with the cover in place.
• Do not operate any appliance with a damaged cord or plug, or after the appliance
malfunctions, or is dropped or damaged in any manner. Return appliance to nearest
Customer Service Center (see Warranty for details) for examination, repair, and/or
mechanical or electrical adjustment.
• Do not attempt to disassemble or modify the appliance or repair the power cord in any
event of a malfunction. If it is damaged or needs replacing, contact your nearest
Customer Service Centre or any similarly qualified technician in order to avoid a hazard.
• Always switch off and unplug appliance from the power supply when not in use, before
attaching or detaching moving parts or accessories, and before cleaning or removing
contents from the blender jar.
• BLADES ARE VERY SHARP. HANDLE CAREFULLY. Exercise caution when handling the
blender’s sharp cutting blades, especially when emptying the bowl and during cleaning.
Store out of children’s reach.
• CAUTION: Ensure that the blender is switched off before removing it from the stand.
• Exercise caution when hot liquid is poured into the blender as hot steam can escape
from the blender jar.
