Owners Manual
Korus V400 and V600 Series Wireless Speakers
Manuel d’utilisation
Haut-parleurs sans fil des séries V400 et V600 de Korus
36-page self cover
saddle-stitched booklet
6620 Cypresswood Drive
Suite 120
Spring, TX 77379
832.717.4331
KorusSound.com
9901297_Rev-A2_Korus_V400_V600_Owners_Manual_29-Apr-2013_v21.indd 1 5/23/2013 4:31:22 PM
Product: KORUS
Document: User’s Guide
Color Side 1: Black; front cover bleeds all sides Flat size:
14 x 4 in.
Color Side 2: Black; back cover bleeds all sides Finished size: 7 x 4 in.
36-page self cover
saddle-stitched booklet
6620 Cypresswood Drive
Suite 120
Spring, TX 77379
832.717.4331
Table of Contents
Compatible Devices ........................................................ 1
Speaker Buttons and Lights ........................................... 2
Speaker Connectors ....................................................... 3
Available Batons ............................................................. 4
Setting Up Your First Baton ............................................ 4
Adding Another Baton to the Speaker’s Favorites List .. 6
Switching Between Previously Configured Batons ........ 7
Using a 3.5mm Audio Cable (not included) .................... 7
Understanding Your Wireless Range .............................. 8
Using the Korus Volume Control App ............................. 9
Positioning Your Speaker Correctly .............................. 10
Installing Batteries for the Korus V600 Series .............. 11
Using the USB Charge Cable ....................................... 12
Troubleshooting ............................................................ 13
Limited One-Year Warranty ...........................................13
Compatible Devices
Congratulations on purchasing the wireless
Korus speaker! This speaker can be used with
many devices available on the market today.
•iPhone
•iPad
•iPodTouch
•Mac® computers
•Windows® personal computers
Go to www.korussound.com/compatible-devices
for the latest list of devices compatible with the
Korus Batons.
®
®
®
Korus V400 and V600 Series Wireless Speaker Owner’s Manual 1
9901297_Rev-A2_Korus_V400_V600_Owners_Manual_29-Apr-2013_v21.indd 2-1 5/23/2013 4:31:22 PM
Product: KORUS
Document: User’s Guide
Color Side 1: Black; front cover bleeds all sides Flat size:
14 x 4 in.
Color Side 2: Black; back cover bleeds all sides Finished size: 7 x 4 in.
36-page self cover
saddle-stitched booklet
6620 Cypresswood Drive
Suite 120
Spring, TX 77379
832.717.4331
Speaker Buttons and Lights
Top View Button Light Indicator
1 Power
2 Connect
1 2453
3 Mute
4 Volume down
5 Volume up
2 Korus V400 and V600 Series Wireless Speaker Owner’s Manual Korus V400 and V600 Series Wireless Speaker Owner’s Manual 3
9901297_Rev-A2_Korus_V400_V600_Owners_Manual_29-Apr-2013_v21.indd 2-3 5/23/2013 4:31:23 PM
White: Speaker is On.
Amber: Speaker is in low power Standby mode.
White: The speaker is setup to search for and operate
with Batons already configured with the speaker and
currently stored in the speaker’s Favorites list
Amber: The speaker is setup to search for and operate
with new Batons that have not been configured with the
speaker.
Red flash: The Baton has been removed from the
speaker’s Favorites list.
Off: The speaker is being used with a 3.5mm audio
cable (not included).
White flash: Speaker sound is off.
Off: Speaker sound is on.
Decreases speaker volume.
Increases speaker volume.
Speaker Connectors
Back View Connector Description
1 Power
2 3.5mm audio-in jack
1 2
Connector for the AC power cord.
Connects your mobile device directly to the
speaker using a 3.5mm audio cable (not
included).
Product: KORUS
Document: User’s Guide
Color Side 1: Black; front cover bleeds all sides Flat size:
Color Side 2: Black; back cover bleeds all sides Finished size: 7 x 4 in.
14 x 4 in.
36-page self cover
saddle-stitched booklet
6620 Cypresswood Drive
Suite 120
Spring, TX 77379
832.717.4331
Available Batons
Included Batons vary by model.
Setting Up Your First Baton
1. Plug in your speaker, if necessary.
2. Power on your device.
3. Plug your Baton into your device.
You can use a speaker individually or up to 4 speakers simultaneously to broadcast in multiple rooms or
even outdoors.
Note: For the 30-pin connector Baton, you
will automatically be taken to the App Store.
Download and open the Korus volume control
app for your mobile device.
Note: The Korus volume control app needs to
be open (but can be minimized) when you are
USB 30-pin Lightning
®
using the 30-pin connector Baton.
4. Begin playing your music, video, or game.
Note: The Baton has a typical range of up
to 65 feet (20 meters). If the Baton is out of
Go to www.korussound.com for more information and a list of the latest Batons.
range, the speaker stops playing. When the
Baton is back in range, the speaker starts
playing automatically.
4 Korus V400 and V600 Series Wireless Speaker Owner’s Manual Korus V400 and V600 Series Wireless Speaker Owner’s Manual 5
9901297_Rev-A2_Korus_V400_V600_Owners_Manual_29-Apr-2013_v21.indd 4-5 5/23/2013 4:31:24 PM
Source
Device
Note: You can see a list of compatible source devices at www.korussound.com/compatible-devices.
Combine
(into any
configuration
of 2-4)
or separate
speakers
anytime.
Source
Device
Product: KORUS
Document: User’s Guide
Color Side 1: Black; front cover bleeds all sides Flat size:
Color Side 2: Black; back cover bleeds all sides Finished size: 7 x 4 in.
14 x 4 in.
36-page self cover
saddle-stitched booklet
6620 Cypresswood Drive
Suite 120
Spring, TX 77379
832.717.4331
Adding Another Baton to the Speaker’s Favorites List
1. Plug in your speaker, if necessary.
2. Plug your Baton into your device.
3. Begin playing your music, video, or game.
4. Press the speaker’s Connect button twice
to search for the new Baton. When in search
mode, the Connect button light turns amber.
When the Baton connects with the speaker,
the light turns bright amber.
5. Press and hold the speaker’s Connect button
to add the Baton to the speaker’s Favorites
list. When the Baton has been added to the
Favorites list, the Connect button light turns
bright white.
Each speaker can remember up to 10 Batons in
its Favorites list.
6 Korus V400 and V600 Series Wireless Speaker Owner’s Manual Korus V400 and V600 Series Wireless Speaker Owner’s Manual 7
9901297_Rev-A2_Korus_V400_V600_Owners_Manual_29-Apr-2013_v21.indd 6-7 5/23/2013 4:31:24 PM
Note: To remove an active Baton from the
speaker’s Favorites list, press and hold the
speaker’s Connect button. The light flashes
red when the Baton has been removed.
Note: To return to the original factory state,
press the speaker’s Connect button six times.
This will clear the speaker’s Favorites list.
Switching Between Previously Configured Batons
1. Plug in your speaker, if necessary.
2. Plug your Baton into your device.
3. Begin playing your music, video, or game.
4. Press the speaker’s Connect button once
to search for a previously configured Baton.
When the Baton is connected with the
speaker, the Connect button light turns bright
white.
Note: Press the speaker’s Connect button
multiple times to cycle through three or more
configured Batons.
Note: Press the speaker’s Connect button four
times to start “Play All” mode. The Connect
button light turns red. The speaker
will automatically connect with an active Baton
stored in the speaker’s Favorites list. Press
the Connect button again to disable “Play All”
mode. The Connect button light turns white.
Using a 3.5mm Audio Cable
(not included)
If you are going to use a 3.5 mm audio cable to
connect to the speaker, it will have priority over
the wireless Batons.
Product: KORUS
Document: User’s Guide
Color Side 1: Black; front cover bleeds all sides Flat size:
Color Side 2: Black; back cover bleeds all sides Finished size: 7 x 4 in.
14 x 4 in.
36-page self cover
saddle-stitched booklet
6620 Cypresswood Drive
Suite 120
Spring, TX 77379
832.717.4331
Understanding Your Wireless Range
Your Korus speaker operates over a high quality
wireless connection using the SKAA™ wireless
audio standard. To ensure optimal wireless range
and performance, please note the following
when using your Baton:
• DonotholdtheBatondirectlybutratherhold
your mobile device.
• AvoidplacingyourmobiledevicewithBatonin
a tight pocket.
• TheorientationofyourKorusspeakermay
The typical operating range for a mobile Baton
will be 65 feet (20 meters). The typical operating range for the USB Baton will be 98 feet (30
meters). Depending on your home construction,
you may experience shorter or farther operating
ranges.
Using the Korus Volume Control App
You can adjust the volume level of your Korus
speaker by using the hardware volume buttons
on the speaker or on your mobile device, or use
the on-screen volume control (varies by app).
Or, if you would like to individually control the
volume on 1 up to 4 speakers you can using
the Korus volume control app with your mobile
devices! Simply search for the free Korus volume
control app on your mobile device’s App store
and download.
This app also allows
you to label each
speaker or Baton to
something that is meaningful to you. Simply
press “Tap to name this
speaker” to label the
speaker or press “Tap
to name this Baton” to
label the Baton.
impact the wireless operating range.
• AroomwithdenseWiFitrafcfrommany
wireless devices like routers and/or computers
could reduce the wireless range.
8 Korus V400 and V600 Series Wireless Speaker Owner’s Manual Korus V400 and V600 Series Wireless Speaker Owner’s Manual 9
9901297_Rev-A2_Korus_V400_V600_Owners_Manual_29-Apr-2013_v21.indd 8-9 5/23/2013 4:31:24 PM
Product: KORUS
2”
Document: User’s Guide
Color Side 1: Black; front cover bleeds all sides Flat size:
Color Side 2: Black; back cover bleeds all sides Finished size: 7 x 4 in.
14 x 4 in.
36-page self cover
saddle-stitched booklet
6620 Cypresswood Drive
Suite 120
Spring, TX 77379
832.717.4331
Positioning Your Speaker Correctly
The Korus speaker fills the room with a deep
bass sound so you receive the maximum stereo
experience.
We recommend placing your speaker 2 inches
(5 cm) from a wall or corner to allow the sound
to reflect. This also achieves proper speaker
ventilation.
Tip: Use the built-in handle to manage any
excess power cord.
Korus V400 Series is shown
10 Korus V400 and V600 Series Wireless Speaker Owner’s Manual Korus V400 and V600 Series Wireless Speaker Owner’s Manual 11
9901297_Rev-A2_Korus_V400_V600_Owners_Manual_29-Apr-2013_v21.indd 10-11 5/23/2013 4:31:25 PM
2”
2”
2”
Installing Batteries for the Korus V600 Series
Note: Batteries for the Korus V600 Series
speaker are optional and not included. If you
choose not to use the batteries, you can use the
AC power cord (included).
Note: If the speaker will be unused for an
extended period of time (two months or more),
remove the batteries and store them separately.
1. Turn the
speaker over so
that the bottom
is facing up.
2. Unscrew the
two captive
screws that
secure the
battery door to
the bottom of
the speaker.
3. Remove the battery door and insert six D
batteries.
4. Replace the battery door and tighten the
captive screws.
5. Turn the speaker back over to its original
position and it is ready to use.
Note: The Korus speaker turns off when there is
no audio activity for 30 minutes and the speaker
is operating on battery power.
Product: KORUS
Document: User’s Guide
Color Side 1: Black; front cover bleeds all sides Flat size:
Color Side 2: Black; back cover bleeds all sides Finished size: 7 x 4 in.
14 x 4 in.
36-page self cover
saddle-stitched booklet
6620 Cypresswood Drive
Suite 120
Spring, TX 77379
832.717.4331
Using the USB Charge Cable (USB Charge Cable varies by model)
Use the USB charge cable to charge your mobile
device without having to unplug your Korus
Baton.
Note: Your Korus charging cable is for charging
your mobile device. It is not designed to support
data sync operations.
Note: The USB charge cable can impact the
wireless range between your mobile device and
Troubleshooting
If we have not answered all of your questions in
this guide, go to www.korussound.com/FAQ for
more information.
Limited One-Year Warranty
Your Warranty Rights and The Law
THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY HAVE OTHER RIGHTS
THAT VARY DEPENDING ON WHERE YOU
BOUGHT YOUR KORUS PRODUCT. TO FULLY
UNDERSTAND ALL YOUR RIGHTS PLEASE
CONSULT THE LAWS OF THE AREA WHERE
YOU PURCHASED THE PRODUCT.
the Korus speakers up to 30%. You may notice
this impact if your Korus speakers are further
than 25 feet from your mobile device.
Who Is Covered By This Warranty
Only the original purchaser of the Korus product
is covered under these warranty provisions.
THIS WARRNTY CANNOT BE TRANSFERRED
OR ASSIGNED BY THE ORIGINAL PURCHASER
TO OTHERS.
12 Korus V400 and V600 Series Wireless Speaker Owner’s Manual Korus V400 and V600 Series Wireless Speaker Owner’s Manual 13
9901297_Rev-A2_Korus_V400_V600_Owners_Manual_29-Apr-2013_v21.indd 12-13 5/23/2013 4:31:26 PM
Product: KORUS
Document: User’s Guide
Color Side 1: Black; front cover bleeds all sides Flat size:
Color Side 2: Black; back cover bleeds all sides Finished size: 7 x 4 in.
14 x 4 in.
36-page self cover
saddle-stitched booklet
6620 Cypresswood Drive
Suite 120
Spring, TX 77379
832.717.4331
Geography
These warranty provisions apply only to products
purchased within North America from a qualified
Korus vendor. Korus disclaims all warranties
on any products purchased outside of North
America or from a non-authorized seller.
Warranty Disclaimer
To the extent permitted by law the warranties
contained herein are exclusive and in lieu of
all other warranties or remedies whether oral,
written, express or implied. Korus expressly
disclaims all such other warranties, including but not limited to implied warranties
of merchantability, fitness for a particular
purpose and non-infringement. In no event will
Korus be liable for any incidental or consequential damages arising out of the use or inability to
14 Korus V400 and V600 Series Wireless Speaker Owner’s Manual Korus V400 and V600 Series Wireless Speaker Owner’s Manual 15
9901297_Rev-A2_Korus_V400_V600_Owners_Manual_29-Apr-2013_v21.indd 14-15 5/23/2013 4:31:26 PM
use the product, even if Korus has been advised
of the possibility of such damages, or for any
claim by any other party. Notwithstanding the
above, if you qualify as a “consumer” under the
Magnuson-Moss Warranty Act, then you may be
entitled to certain implied warranties allowed by
law for the Warranty Period. Further, some states
do not allow limitations on how long an implied
Limited Warranty lasts or allow the exclusion or
limitation of consequential damages, so such
limitations may not apply to you.
Warranty Provisions
This Korus product warranty is provided by
Nortek, Inc., 1730 Corporate Circle – Attn:
Customer Service, Petaluma, CA 94954.
Your Korus product is warranted only if purchased in North America from an authorized
seller against defects in materials and workmanship for a period of one (1) year from the date of
original retail purchase from an authorized Korus
dealer. If a defect exists, Korus at its option will
(1) repair the product at no charge using new or
refurbished parts, (2) exchange the product with
a functional equivalent product that is new or
refurbished, or (3) refund the original purchase
price. Under no circumstances for any refund
related to a warranty claim exceed the original
purchase price of the product.
What Is Not Covered Under This Warranty
This warranty covers only product failures related
to defects, materials, and workmanship. We do
not cover normal wear and tear, blown speakers,
cut cords, bent jacks, scratches, loss or theft.
This warranty excludes damages resulting from
abuse, accident, modifications or other causes
that are not solely related to defects in materials
and workmanship.
Acts Which Will Void Your Warranty
Customization or other tampering with the basic
structural integrity or software of your product
will void your warranty.
If the Serial Number on the product has been
removed, tampered with or defaced, or if the
product was not purchased from an authorized Korus dealer your warranty will be void.
Loading...
