COP-USA CD54W-35Y User Manual

Installation and Operation Manual

for

Six inches Middle-Speed Dome P/T

V1.1

Please read the operation manual carefully

before installing and using this unit

Operation Manual for Intelligent Speed Dome Camera

I. Points for Attention

1. Please read the operation manual carefully before installing and operating the product.

2. The product takes power supply of AC24V. The rated input voltage of the camera is

marked on the base or other corresponding place.

3. During the course of transportation, storage and installation, the product should be avoided

from incorrect operations such as heavy pressing, strong vibration etc., which can cause
damage of product as there are sophisticated optical and electronic devices inside the
machine.

4. Do not attempt to disassemble the camera. In order to prevent electric shock, do not

remove screws or covers. There are no user-serviceable parts inside.

5. Always follow all electrical standards for safety when it is in operation. Adopt the

particular power supply which is provided with the unit. RS-485 and video signal should
keep enough distance with high voltage equipments and cables when they are in
transmission. Precautions for anti-lightning and anti-surging should be taken if necessary.

6. Do not operate it in case temperature, humidity and power supply are beyond the limited

stipulations.

7. Do not let the camera aim at the sun or the object with extreme light whatsoever it is

switched on or not. Do not let the camera aim at or monitor bright and standstill object for
a long time.

8. Do not use aggressive detergent to clean the main body of the camera. Wipe di rt with dry

cloth. If needed, mild detergent can be used suitably.

9. Operate the intelligent speed dome camera with great care to avoid shock or vibration. It

operate incorrectly, the Speed Dome could be damaged

10. Be careful to avoid to crash, Never mount the unit on a ceiling that cannot support its

weight.

11. If necessary, use a commercial lens cleaning paper to clear the lens windows. Gently wipe

the lens window until clean.

1

Operation Manual for Intelligent Speed Dome Camera

II. Description of Functions

The intelligent dome camera is a hi-tech CCTV product which incorporates high-clarity
color camera, panoramic speed-variable PAN/TILT, multifunctional decoder, CPU processor,
memory chip into a whole. It can largely reduce connection and installation processes of
components in the system, rise up reliability of the system and facilitate installation and
maintenance. Therefore it has advantages of beautiful appearance, compact structure and easy
operation.

1. Integrated Multi-Protocol Decoder

2. Integrated speed-variable PAN/TILT

3. High Intelligent Degree

4. Functions of the Camera

a. With integrated decoder and multi-protocol, it can integrate 16 kinds of

communication protocols in maximum. As its baud rate of communication can be
adjusted, it is compatible with many normal systems by easy setup inside the dome
camera, so it has stronger versatility.

b. RS485 serial control: addresses of camera 1-1023.

a. Turning 360 º horizontally and continuously with unlimited positions and an

adjustable speed from

b. Running stably at low speed with super lower noise. Pictures have no shaking.
c. the location precision up to

a. As much as 64 preset positions can be preset
b. The camera can scan horizontally between two points

The positions of linear scan are optional and the dome camera can scan the range
larger or smaller than 180° between any two points with adjustable speed;

c. Six sets of programmable patrol

detention time are adjustable respectively ;

d. The Integrated Multi-Protocol.

inside the dome camera with selectable baud rate from

a. Description of the Focus Control Mode

manually.

b. Description of Backlight Compensation:

looks dim, the user can open the backlight compensation according to actual need.

c. Description of White Balance

user can set different modes by orders.

d. Description of ZOOM Control

to actual conditions.

e. Description of Electronic Shutter

camera is switched on.

f. AE Mode

Minimum illumination: it is used only when the external brightness is extremely low.

g.

: setup of Manual/Automatic.

Normally the camera works on the automatic state. In case the external brightness is
lower than 1Lux, the camera can be switch to the
automatically You can also set the

16x f =3.9 to 63mm (F1.6 DC Iris) 1 Lux (F1.6)
18x f =4.1 to 73.8 mm (F1.4 to F3.0)

0.2 -- 80rad/s; turning 0 - 90º vertically with a speed up to 12 rad/s.
±0.2°.

with powerless memory;

and scan speed can be modified.

with 16 position each set. The running speed and the

Multiple communication protocols are integrated

2400 bps to 9200 bps.

: the user can adjust the focus of the camera

when the object to be shot is dark and

: when the image has color distort on the screen, the

: user can “pull near” or “push far” the lens according

: it is fixed on 1/50 s ec after initializatio n when the

Minimum illumination state

Minimum illumination state manually.

LENS

1 Lux (common) / 0.01 Lux（B & W）

Minimum illumination

22x f =4 to 88 mm (F1.6 to F3.8)
23x f =3.6 to 82.8 mm (F1.6 to F3.7)
26x f =3.5 to 91 mm (F1.6 to F3.8)

0.2 Lux（F1.6 1/3s）

0.01 Lux（B & W）

0.01 Lux（B & W）

2

Operation Manual for Intelligent Speed Dome Camera

27x f =3.6 to 98 mm (F1.5 to F3.8)

Ⅲ . Setup of the Dome Camera

1. Connection of the System

1) The Systematic Drawing of the Dome Camera

Po wer I N

Pr ot ocol Adapt er

AC24 V OUT

Power Adapt er

RS- 485 RS- 485 RS- 485 RS- 485

Pr ot ocol Adapt er

BSW

Po we r I N

RS- 485

Do me Camer a

BSW

1 Lux (Common / 0.01 Lux（B & W）

C

Moni t or

VI DEO OUT

Mul t i pl exer

Mat r i x

Co d e Co n v e r t e r

RS2 3 2

V

AD Mat r i x

Philips Mat r i x

Figure 1

2) Address / Protocol Coding Switch Drawing

SW2

ON

12345 6

ON

Pr ot ocol Set

SW2: DIP1--DIP4 Sel ect Protocol
SW2: DIP5--DIP6 Sel ect Baud Rate

Bracket for fixed camer a

SW1

1234 5 6

Addr ess Set

78910

2

31

JP

120Ω t erminal resistor i s
opened f or RS485 bus

31

2

JP

120Ω termi nal resistor is
connected on RS485 Bus

Figure 2

2. Setup of Coding Switch of Dome Camera. As shown in Figure 2, SW1 is used to set

address of the dome camera from 1 – 1023. The ID-CODE from DIP-10 to DIP-1 are
equivalent to a 10-bit binary digit. DIP-10 is MSB while DIP-1 is LSB. The state “ON” of
each bit means 1 while “OFF” means 0. Following table sho ws states of coding switches
of some addresses.

Dome

Address

DIP-1 DIP-2 DIP-3 DIP-4 DIP-5 DIP-6 DIP-7 DIP-8 DIP-9 DIP-10
1 ON OFF OFF OFF OFF OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF OFF OFF OFF OFF
3 ON ON OFF OFF OFF OFF OFF OFF OFF OFF
4 OFF OFF ON OFF OFF OFF OFF OFF OFF OFF
5 ON OFF ON OFF OFF OFF OFF OFF OFF OFF
6 OFF ON ON OFF OFF OFF OFF OFF OFF OFF
7 ON ON ON OFF OFF OFF OFF OFF OFF OFF

ID-CODE Status

3

Operation Manual for Intelligent Speed Dome Camera

8 OFF OFF OFF ON OFF OFF OFF OFF OFF OFF
9 ON OFF OFF ON OFF OFF OFF OFF OFF OFF

10 OFF ON OFF ON OFF OFF OFF OFF OFF OFF
11 ON ON OFF ON OFF OFF OFF OFF OFF OFF
12 OFF OFF ON ON OFF OFF OFF OFF OFF OFF
13 ON OFF ON ON OFF OFF OFF OFF OFF OFF
14 OFF ON ON ON OFF OFF OFF OFF OFF OFF
15 ON ON ON ON OFF OFF OFF OFF OFF OFF
16 OFF OFF OFF OFF ON OFF OFF OFF OFF OFF
17 ON OFF OFF OFF ON OFF OFF OFF OFF OFF
18 OFF ON OFF OFF ON OFF OFF OFF OFF OFF

… … … … … … … … … … …

1023 ON ON ON ON ON ON ON ON ON ON

Table 1

For Example:

ON

12345 6

78910

Speed Dome Addr ess=1

ON

12345 6

78910

Speed Dome Addr ess=4

ON

12345 6

78910

Speed Dome Addr ess=2

ON

12345 6

78910

Speed Dome Addr ess=18

ON

1234 5 6

78 910

Speed Dome Addr ess=3

ON

12345 6

78910

Sp e e d Do me Addr ess=1023

3. Setup of the Protocol and the Default Baud Rate. As shown in Figure 2, SW2 is used

to set the protocol of communication and the baud rate used by the dome camera. DIP-4
to DIP-1 of SW2 is used to select protocols and 16 different protocols can be selected in
maximum. Following table shows states of coding switches of protocols selected by the
dome camera

Protocols

DIP-1 DIP-2 DIP-3 DIP-4 DIP-5 DIP-6

SAMSUNG ON OFF OFF OFF OFF ON
B01 ON OFF OFF OFF OFF ON
NEON ON OFF OFF OFF OFF ON
Santachi OFF ON OFF OFF OFF ON
PELCO-D ON ON OFF OFF OFF OFF
PELCO-P/4800
PELCO-P/9600 OFF ON

OFF OFF ON OFF

PANASONIC ON OFF ON OFF OFF ON
Longcomity OFF ON ON OFF OFF ON
HUNDA600 ON ON ON OFF OFF ON
LILIN OFF OFF OFF ON OFF ON
VICON ON OFF OFF ON ON OFF
MOLYNX OFF ON OFF ON OFF ON
KALATEL ON ON OFF ON ON OFF
VCL OFF OFF ON ON OFF ON
Reserved ON OFF ON ON OFF ON
ALEC OFF ON ON ON OFF ON
Ultrak ON ON ON ON OFF ON

DIP status Normal Baud Rate

ON OFF

Table 2

4

Operation Manual for Intelligent Speed Dome Camera

Some protocols and the states of the coding switches of normal baud rate of these
protocols are shown as follows:

B01/ 9600Bps

PEL CO- D/ 2400Bps

ON

123456

ON

123456

PEL CO- P/ 4800Bps

PEL CO- P/ 9600Bps

ON

123456

ON

123456

4. Setup of the Baud Rate of Communication. As shown in Figure 2, SW2 is used to set

the protocol of communication and the baud rate used by the dome camera. DIP-6 and
DIP-5 of SW2 are used to select the baud rate of communication and 4 different baud
rates can be selected in maximum. If the controller adopts non-standard baud rate, you
can adjust it to be identical with that of the controller as per the following table.

Baud Rate of Communication DIP-1 DIP-2 DIP-3 DIP-4
2400bps OFF OFF

4800bps ON OFF
9600bps OFF ON
19200bps ON ON

Setup of Baud Rate

DIP-5 DIP-6

5. Selection of the Terminal Resistor of the Dome Camera. As shown in Figure 2, JP is

the select switch of the 120 Ω terminal resistor on the bus RS485, on which
only one terminal resistor of the dome camera at the farthest end can be connected, while
the terminal resistors of other devices should be opened.

6. Special function control.

Some special protocol such as “Santachi”,”PELCO-D” and

“PELCO-P” without the command of control some especial functions, in order to use the
special functions of dome, so we changed the command of calling/setting NO.51 preset to
NO.64 preset to control them.

N Object of control
51

52

Auto scan

53
54 Camera power Power on Power off

55 Back light * On Off
56 ICR shor On Off

OSD (Some cameras have it’s
own menu, to open/close the

57

menu by the command “turn on
the OSD”, and use the command
“turn off the OSD” to

open/close the OSD)
58 Digital Zoom On Off
59 FOCUS Auto Manual
60 IRIS Auto Manual
61
62 Indoor Outdoor

White Balance Mode
63 ATW One Push WB
64

Keyboard control

Call the N position Preset the N position

Auto scan（low speed）
Auto scan（middle speed）
Auto scan（high speed）

Auto cruise
Set the start point of scan
Set the end point of scan

On Off

Auto Manual

5

Operation Manual for Intelligent Speed Dome Camera

Ⅳ. The Installation of the System

1. The style of the Installation

1) Dimension of the Product

Φ152
Φ219

Figure 3

262

2) The Style of Installation
a) Wall Installation

b) In-Ceiling Installation

Figure 4

262 300

Φ7

Figure 5

2. Steps of Installation (taking wall-mounting as example)

1. Unpacking the carton and carefully take out the dome camera and its attachments.

6

Operation Manual for Intelligent Speed Dome Camera

2. Rotate the vitreous cover counterclockwise and take out it. (see Figure 6) Note: It can be

ignored the steps 2,3,4,5 while the protocol and address are matching with the controller.

3.

Take out the black liner. (Figure 7)
Based on the ID-CODE shown as Figure 2, set up the protocol used by the camera and the

4.

baud rate as per the state according to Table 1. Check the address of the camera to see if it
is matched with that you need. If not, set the address of the dome camera at corresponding
position as per Table 1.

Takedown t he

Open

Figure 6 Figure 7

5.

Fix the black liner (see Figure 8).

bl ack l i ner

Fi x ed t he

bl ack l i ner

Figure 8

6.

Take out the cover of the wall-mounting bracket (see Figure 9).
Fix the bracket on the wall (see Figure 10).

7.

Drill the system control wires through the bracket (see Figure 11).

8.

Figure 9 Figure 10 Figure 11

7

Operation Manual for Intelligent Speed Dome Camera

9. Install the aluminum alloy ball on the bracket (Figure 12).

10. Rotate the vitreous cover clockwise and mount it（Figure 13）.

Figure 12 Figure 13

Connect the control wires of the system as per Figure 14.

11.

RED L I NE ( AC2 4 V I N)

BL ACK L I NE( AC2 4 V I N)

ORANGE L I NE( RS4 8 5 + )
YEL L OW LINE(RS485-)

Cl o s e

RE D CONNE CT OR
(POWER I N)

BL ACK CONNE CT OR
(RS485 CONT ROL I N)

VI DEO OUT

Figure 14

3. To ensure a smooth and successful installation, you must:

1. Have electrical work comply with latest national electrical code, national fire code,

and all applicable local codes and ordinances.
Coordinate work with other trades to avoid interference.

2.

3.

Verify existing site conditions and coordinate with owner’s representative and
appropriate utilities as required.

Obtain copies of all related plans, specifications, shop drawings and addenda to

4.

schedule and coordinate related work
Thoroughly review the project to ensure that all work meets or exceeds the above

5.

requirements. Bring alleged discrepancies to the attention of the CCTV Project
Coordinator.

Ⅴ . Technical data table

1、 Indoor/Outdoor Speed Dome

8

Operation Manual for Intelligent Speed Dome Camera

Power supply AC24V 50/60Hz
Power consumption

Sync system Internal
Preset 64 presets
Patrol 6
Auto pan scan

Pan Manual Control Speed
Pan Preset Speed
Pan rotation range
Title range
Tilt speed
Control mode RS485

Baud Rate 2400/4800/9600/19200 bps
Fan & heater Fan & heater auto-start (only outdoor dome)

Environment temp

2、 Camera Optional data table

Indoor dome：12W Outdoor dome：35W

360°Programmable

0—30°/s

80°/s max
360°continues
Tilt 90°
12°/s max(manual & preset speed)

Indoor dome：0℃ — +40℃
Outdoor dome –35℃ -- +55℃

Mode

Sync mode Internal
Image Inductor

Scanning system 2:1 interlacin g
Resolution >470TVL

Effective
Pixels

Sensitivity 1Lux(F1.6) 1Lux / 0.01Lux 0.2LuxF1.6 1/3s) 1Lux / 0.01Lux 1Lux / 0.01Lux
Iris Auto/ Manual
Focus Auto/ Manual
Zoom Rate

Angel of view

B.L compensation Auto/ Manual
White balance Auto/ Manual
Gain Control Auto/ Manual
Signal formal Auto/ Manual
S/N >46dB

Video output

PAN 470,000 pixels
NTSC 440,000 pixels

16× 18× 22× 23× 27×
Color Day/Night

switch

1/4″ Color CCD

≥ 480TVL
752×582(440K) 758×592(450K) 795×596(470K)
768×494(380K) 758×504(380K) 811×508(410K)

16× optical 18× optical 22× optical 23× optical 27× optical
f=3.9 to 63 mm f=4.1 to 73.8 mm f=4 to 88 mm f=3.6 to 82.8 mm f=3.6 to 98 mm

Wide: 47° Wide: 48° Wide: 47° Wide: 54°

TELE: 3° TELE: 2.7° TELE: 2.2° TELE: 2.5°

≥ 50dB

1.0±0.2Vp-p

Color Day/Night

switch

Day/Night
switch

Ⅵ. Troubleshooting

Problem Probable cause Solution

On power no action Power supply fault Replace

9

Operation Manual for Intelligent Speed Dome Camera

On power cannot self-check
have image but have motor
noise

Self-check ok, but have no

Self-check ok but cannot
control

Vague image

On power cannot control

Bad connection of the power Make correction
Transformer dam aged Replace
Mechanical failure Repair
Camera incline Reinstall
Power supply not enough Replace
Video signal fault Reinstall
Bad connection of the video Press to full connect
Camera damaged Replace
RS485 Bus bad connection Check the RS485 connection
Dome id setting is wrong Reselect
Protocol setting is wrong Reset and on power again
Bad connection of the video Press to full connect
Power supply not enough Replace
Self check error On power again
Bad connection of control Press to full connect
Bad control of matrix On power again

10
