A
B
C
1"
1
1
1
"
4
3
"
4
4 pcs
4 pcs
12 pcs
1
IDENTIFY ALL PARTS AND HARDWARE
THAT ARE INCLUDED WITH YOUR
CHICKEN ROOSTING PERCH. GRAB A
SCREWDRIVER (OR HAND DRILL).
FIND A LEVEL PLACE TO BUILD IT AND
AN EXTRA SET OF HANDS WOULD BE
HELPFUL. START BUILDING!
ASSEMBLY INSTRUCTIONS
3
CENTER POLE
BOTTOM LOWER BASE
(TOP IS NOTCHED)
1
2
BOTTOM UPPER BASE
(BOTTOM IS NOTCHED)
Chicken Roosting Perch
4
x2
(2) CENTER POLE
SUPPORTS (ATTACHES TO
BOTTOM UPPER BASE (2))
5
x2
ROOSTING PERCHES
UPPER LANDING PAD
(2) CENTER POLE
SUPPORTS (ATTACHES TO
BOTTOM LOWER BASE (1))
7
Model# 223-40
6
x4
2
PLACE BOTTOM LOWER BASE (1) WITH
NOTCH FACING UP ON THE GROUND. TAKE
BOTTOM UPPER BASE (2) WITH NOTCH
FACING DOWN AND NEST INTO BOTTOM
LOWER BASE (1).
3
GET YOUR EXTRA SET OF HANDS. PLACE CENTER POLE
(3) ON TOP OF NOTCHED LOWER BASE (1+2) SO IT IS
CENTERED OVER THE NOTCHED AREA. MAKE SURE IT
IS NOT TWISTED. INSERT TWO SCREWS (C) INTO
PRE-DRILLED HOLES THROUGH THE UNDERSIDE CENTER
OF THE NOTCHED BASE AND TIGHTEN WITH YOUR
SCREWDRIVER OR HAND DRILL. SET UPRIGHT.
2
1
3
2
C
1
2x
CC
4
SECURE CENTER POLE SUPPORT (4) TO
CENTER POLE (3) WITH SCREWS (B)
THROUGH TOP AND BOTTOM PRE-DRILLED
HOLES AND LIGHTLY TIGHTEN. REPEAT ON
OPPOSITE SIDE.
B
4x
5
SECURE CENTER POLE SUPPORT (5) TO
CENTER POLE (3) WITH SCREWS (A)
THROUGH TOP AND BOTTOM PRE-DRILLED
HOLES AND LIGHTLY TIGHTEN. REPEAT ON
OPPOSITE SIDE. NOW, SECURELY TIGHTEN
ALL CENTER POLE SUPPORT SCREWS.
A
4x
B
B
B
B
4
.
.
4
A
A
A
A
.
6
.
6
6
6
.
STARTING AT THE LOWEST LEVEL INSERT ROOSTING
PERCH (6) INTO TONGUE/GROVE NOTCH AND USE
TWO SCREWS (C) TO SECURE TO CENTER POLE (3).
REPEAT MOVING UPWARDS WITH THE NEXT THREE
PERCHES.
C
SQUARELY PLACE UPPER LANDING PAD (7) ON TOP OF CENTER POLE (3). INSERT
7
TWO SCREWS (C) INTO PRE-DRILLED HOLES AND SECURELY TIGHTEN.
C
8x
2x
CC
.
6
CC
8
WE RECOMMEND EXTENDING THE LIFE OF YOUR CHICKEN ROOSTING PERCH WITH
OUTDOOR PAINT OR A CLEAR FINISH. THIS ROOSTING PERCH HAS BEEN STAINED BUT
USING A NON-TOXIC OUTDOOR PRODUCT OR A CLEAR POLYURETHANE WILL PROVIDE
ADDITIONAL PROTECTION AGAINST RAIN, MOISTURE, HUMIDITY AND SNOW FOR MANY
SEASONS TO COME. NOW! SET OUTSIDE FOR YOUR FREE-RANGE BIRDS OR WITHIN
YOUR COOP AREA AND LET YOUR BIRDS ENJOY!
CCCC
6
.
.
6
CC
.
7
