Battery Organiser with Tester F946 Instructions for Use
Please read and retain these instructions for future reference v001: 26/03/19
Using the battery tester:
To test a battery, grasp and slide the battery
tester out of the unit. When testing a battery
make sure that the battery polarity is aligned
properly with the appropriate port. Battery
power is indicated by the LED combinations
below.
GOOD – All three: RED, YELLOW, GREEN LEDs
are lit.
WEAK – Only the RED and YELLOW LEDs are lit.
REPLACE – Only RED LED is lit. Battery current is
very low with minimal functionality.
Replace the tester securely into its slot after
testing.
Dimensions:
Height: 4.5cm
Width: 17.5cm
Length: 34.6cm
Weight: 412g
Materials:
ABS and HIPS
Accessories:
3 screws and 3 plastic anchors
Battery storage organiser holds:
48 x AA batteries
24 x AAA batteries
8 x D batteries
10 x C batteries
8 x 9V batteries
Using the battery organizer:
Store flat in a drawer or mount on a wall or in a cupboard (mounting hardware included). Insert the correct
battery size into the appropriate storage slots.
Note: A fully charged 1.2V rechargeable battery will only light the RED and YELLOW LEDs. This is normal.
Make sure the polarity is correct when testing, otherwise, no LED will light up giving a false reading.
Page 2
Battery Organiser with Tester F946 Instructions for Use
Please read and retain these instructions for future reference v001: 26/03/19
DO NOT TEST BATTERIES WITH VOLTAGE HIGHER THEN THE PORT CAPACITY OTHERWISE, THE
TESTER WILL BE DAMAGED.
Care:
Keep the battery organizer dry, wipe immediately if it gets damp or wet. Store and use in normal
temperature environments only. Do not drop the battery organiser. Keep away from dust and dirt. Wipe
occasionally with a damp cloth to clean.
DISPOSAL
• Dispose of all packaging, paper, cartons, plastic and plastic bags in accordance with your local recycling
regulations.
• At the end of the product’s lifespan please dispose of it at an authorised household waste recycling
centre.
