Cooper Power Systems RFW201 Users Guide
RFW-201 User’s Guide
Document Number
CUG RFW-201
Revision 1
Eaton’s Cooper Power Systems
910 Clopper Road, Suite 201S
Gaithersburg, MD 20878 USA
www.eaton.com
Tel (301) 515-7118
Fax: (301) 515-4965
Contents
1 About the RFW-201 ................................................................................................................................ 3
2 Regulatory Notices................................................................................................................................. 4
3 RFW-201 Specifications ........................................................................................................................ 7
CUG RFW-201, Revision 1 2 RFW-201 User’s Guide
1 About the RFW-201
The RFW-201 is a radio communications device designed for use in water meters. The
RFW-201 provides a 915 MHz radio interface to an RF mesh network.
The RFW-201 operates from a 3.6V lithium battery. The supplied voltage is then
regulated to 3.3VDC by the on-board power supply circuit. The radio module operates in
license-free bands at 915 MHz (902.75 to 927.25 MHz). RFW-201 Nodes are fully
compatible with mesh network hardware, protocols and operations. Five radio
transmission data rates are available: 9.6 kb/s, 19.2 kb/s, 38.4 kb/s, 76.8 kb/s and 153.6
kb/s. The transmission power of the 915 MHz radio is adjustable from 20 dBm to -20
dBm.
CUG RFW-201, Revision 1 3 RFW-201 User’s Guide
