Cooper Power Systems NS200 Users Guide

RFN NS200 User’s Guide

Document Number

CUG NS200

Revision 1

Eaton’s Cooper Power Systems

910 Clopper Road, Suite 201S

Gaithersburg, MD 20878 USA

www.eaton.com

Tel [phone]

Fax: [phone]

Contents

1 About the RFN NS200 ............................................................................................................................ 3

2 Regulatory Notices................................................................................................................................. 4

2.1 Regulatory Notices - English ............................................................................................................. 4

2.2 Regulatory Notices - French .............................................................................................................. 6

3 RFN NS200 Specifications .................................................................................................................... 9

CUG NS200, Revision 1 2 RFN NS200 User’s Guide

1 About the RFN NS200

The RFN NS200 is a radio frequency communications device designed for use in Eaton
radio communications products. The RFN NS200 provides a 915 MHz radio interface to
an RF mesh network.

The RFN NS200 operates from a power source of 5 VDC, received from the host device.
The supplied voltage is regulated by the on-board power supply circuit. The radio
modules operate in license-free bands at 915 MHz (902.75 to 927.25 MHz). The RFN
NS200 is fully compatible with mesh network hardware, protocols and operations. Five
radio transmission data rates are available: 9.6 kb/s, 19.2 kb/s, 38.4 kb/s, 76.8 kb/s and

153.6 kb/s. The transmission power of the 915 MHz radio is adjustable from 30 dBm to ­20 dBm.

CUG NS200, Revision 1 3 RFN NS200 User’s Guide
