INDUSTRIALS
457
COOPER LIGHTING
• Equipped with energy
Saving ballasts/complies
with federal energy
efficiency standards
• Die formed channels
• Heavy gauge apertured,
(IA) or closed top, (IC)
reflector
• Baked white enamel finish
• Pressure lock lampholders
(RS), spring loaded
lampholders (SL, HO)
• Wire guards available for
special application
• SilverLining Reflector
Finish available
(3)
• Apertured reflector (IA)
standard with 8% uplight
• Also available in tandem 8'
lengths
• UL/CUL Listed. Suitable for
damp locations.
DESCRIPTION
The IA Series is an energy
efficient family of light duty
industrials that features
premium performance and
durability. The series
incorporates sturdy embossed
reflectors that precisely direct
and effectively control light. The
IA Series can be installed using
various mounting methods and
numerous options and
accessories are available. The
series is available with both
Apertured (IA) and Closed Top
(IC) reflector combinations. The
IA Series can be utilized in
simple task and area lighting
and industrial applications.
IA, IC SERIES
4' or 8' Industrial
2 Lamps
INDUSTRIAL
DIMENSIONS
NOMINAL LENGTH A B
4', 8' 12" (305mm) 4 5/8" (117mm)
4' HO, 8' HO 12" (305mm) 5 3/8" (137mm)
NOTES:
(1)
Products also available in non-US voltages and frequencies for international markets.
(2)
Not available when specifying emergencies, voltage must be specific.
(3)
Silver lining not available on fixtures with HO.
For complete product data, reference the Fluorescent Specification binder. Specifications & dimensions subject to change without notice. Consult your Cooper Lighting
Representative for availability and ordering information.
COOPER LIGHTING - METALUX
®
Tandem
Blank=4' Length
8T=8' Length
Series
IA=Apertured Reflector
IC=Closed Top Reflector
ICW=Extra Wide Channel
Reference STW Series With
Symmetric Reflector
ORDERING INFORMATION
SAMPLE NUMBER: IA-232-120V-EB81-U
Number
of Lamps
2 Lamps
(Not included)
Wattage (Length)
40=34/40W T12 (48")
32=32W T8 (48")
48=40W T12 (48") SL
48HO=60W T12 (48") HO
48HO=44W T8 (48") HO
96=60/75W T12 (72") SL
96=59W T8 (96") SL
96HO=95/110W T12 (96") HO
96HO=86W T8 (96") HO
Voltage
(1)
120V=120 Volt
277V=277 Volt
347V=347 Volt
UNV=Universal Voltage 120-277
(2)
Silver
Reflector
SS=Silver-
Lining
Reflector
(3)
Options
GL=Single Element Fuse
GM=Double Element Fuse
Emergency - for EM installed, see
EM options table
Ballast Type
(1)
Blank=Standard Magnetic Ballast
LE3=T12 Magnetic Energy Saving
EB8
= T8 Electronic Instant Start.
Total Harmonic Distortion < 10%
EB8
/PLUS= T8 Electronic Instant Start.
High Ballast Factor >1.13. Total
Harmonic Distortion < 20%
ER8
= T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%
EB2
=T12 Electronic Rapid Start.
(For complete details on generic or to specify
manufacturer’s ballast see pg. 469)
No. of Ballast
1, 2 or 3
No. of
Ballast
1, 2 or 3
No. of Ballast
1, 2 or 3
No. of Ballast
1 or 2
Options
(See Options
Section)
Packaging
U=Unit Pack
4B=4 Bulk
