Cooper Lighting J-E-PSW-FX-02 User Manual

Vault
These installation instructions are valid with the above Ametrix styles.
C-Scroll
Roundel
Installation Instructions
Sheet 1 of 3
Large, OUTDOOR
P2R
(Pendant, 2-way, Remote ballast)
Visor and Non-Visor
Warning
that all sources of power are turned off. All work must meet local/national codes and be performed by a certified electrician. mount fixtures vertically.
: Before starting any work ensure
Do not
Exploded view and part call-out
Canopy
Fixture head assembly
#8-32 x3/8" Set screw (2x)
Cover plate (2x)
Attention:
Large fixtures require additional bracing/structure
around J-box to support fixture.
2
Wiring the fixture
1
(by others)
#8-32 x3/8" Set screw (2x)
Cover plate
1. Remove both 1/4-20 x4 hex bolts from bottom of pendant.
2. Remove both #8-32 x3/8" set screws and allow canopy to
slide down pendant.
3. Run wires from J-box into pendant, ensure there is enough wire to reach cover plate.
4. Using appropriate fasteners, secure fixture to ceiling. Use additional bracing if necessary.
. Replace canopy and secure using both set screws.
5
3
Securing pendant to ceiling
J-box3/8" fasteners (by others)
Canopy
1/4-20 x4 Hex bolts (2x)
Sealing the fixture
1/4-20 x4 Hex bolts (2x)
Slide fixture assembly onto pendant and secure with both 1.
1/4-20 x4 hex bolts.
2. Attach appropriate wires and ensure all connections are properly matched
Secure cover plate
3.
ADY071474 REV A(ECN070347)
Cover plate
#8-32 x1/2" Socket cap screws (2x)
Cover plate gasket (2x)
#8-32 x5/8" Socket cap screws (3x)
Wire seal
1. To seal fixture, ensure door is secured with provided socket cap screws. Secure #6-32 x1/2" socket cap screws above door latches.
2. Secure #6-32 x5/8" socket cap screws into bottom of door.
3. Refer to supplementary sheets for torque specs and aiming
instructions.
Vault w/ visor
These installation instructions are valid with the above Ametrix styles
C-Scroll w/ visor
Roundel w/ visor
Installation Instructions
Sheet 2 of 3
Large, OUTDOOR
P2R
(Pendant, 2-way, Remote ballast)
Visor and Non-Visor
Warning
that all sources of power are turned off. All work must meet local/national codes and be performed by a certified electrician. mount fixtures vertically.
: Before starting any work ensure
Do not
6"
152.40
1
"
4
2
114.30
Mounting plate dimensions In[mm]
R
1"
25.40
1
"4
2
6"
114.30
152.40
3
"
4
19.05
3
"
4
19.05
Front View
ADY071474 REV A(ECN070347)
1
"
2
12.70
Side View
Length dependant
on order
