Vault w/ visor
These installation instructions are valid with the above Ametrix styles
C-Scroll w/ visor
Exploded view and part call-out
J-box
(by others)
Roundel w/ visor
Swivel pendant shown
Installation Instructions
Sheet 1 of 5
Small, INDOOR
CPP/CPS
(Continuous Pendant)
Visor and Non-Visor
Warning
that all sources of power are turned off. All
work must meet local/national codes and be
performed by a certified electrician.
mount fixtures vertically.
: Before starting any work ensure
Do not
End pendant
assembly
Yoke arm
Pendant tube
10-32 x5/8"
End screw
Pendant nut
(x2)
Center pendant
assembly
Fixture wire
Center cover plate
Pendant tube
Power wire
from J-box
#10-32 x 5/8"
End screw
(2x)
#10-32 x 3/8"
Pan head screws
(2x)
ADY071477 REV A (ECN080352)
Vault w/ visor
These installation instructions are valid with the above Ametrix styles.
C-Scroll w/ visor Roundel w/ visor
Installation Instructions
Sheet 2 of 5
Small, INDOOR
CPP/CPS
(Continuous Pendant)
Visor and Non-Visor
Warning
that all sources of power are turned off. All
work must meet local/national codes and be
performed by a certified electrician.
mount fixtures vertically.
: Before starting any work ensure
Do not
PP Exploded assembly
#8-32 x1/2"
Screw
(2x)
Pendant yoke
#10-32 x5/8"
End Screw
1.
Secure pendant yoke to pendant tube using both pendant
nuts prior to installation.
1
Mounting power-side pendant to J-box
PP mounting
plate
PP canopy
Pendant
nut
PS Exploded assembly
#8-32 x1/2"
Screw
(2x)
Pendant yoke
#10-32 x5/8"
End screw
1.
Secure pendant yoke to pendant tube using both pendant
nuts prior to installation.
2
Mounting non power side pendant
PS mounting
plate
PS canopy
Pendant
nut
Run wiring into
pendant tube
#8-32 x1/2"J-box
Screw(by others)
(2x)
PS mounting
plate
Canopy
These instructions are valid for both PP and PS mounting
assemblies. Secure both pendant assemblies to ceiling before
attaching fixture head.
1. Remove canopy and allow it to slide down pendant.
2. Refer to power orientation supplementary sheet for power
location.
3. Run wiring from j-box down pendant tube and using
#8-32 x1/2" Pan head screws, secure mounting plate to j-box.
Reinforce J-box with additional bracing.
ADY071477 REV A (ECN080352)
PS mounting
plate
#8-32 x1/2"
Screw
(2x)
Canopy
These instructions are valid for both PP and PS mounting
assemblies
1. To secure non-power pendant, remove canopy and allow it
to slide down pendant.
2. Replace #8 Pan head screws with appropriate fasteners(by
others) Use additional bracing to secure pendant.
3. Secure mounting plate on center using dimensions provided
on next page.
Vault w/ visor
These installation instructions are valid with the above Ametrix styles
C-Scroll w/ visor
Center dimensions for PP and PS mounting assemblies
2ft fixture
28
733.40
3ft fixture
40
1036.22
Roundel w/ visor
7
"
8
25
"
32
Installation Instructions
Sheet 3 of 5
Small, INDOOR
CPP/CPS
(Continuous Pendant)
Visor and Non-Visor
Warning
that all sources of power are turned off. All
work must meet local/national codes and be
performed by a certified electrician.
mount fixtures vertically.
: Before starting any work ensure
Do not
PS (Pendant Swivel) mounting plate dimensions
15
1 "
"
32
5
"
16
8.25
15
1
16
49.4336.95
1
5
32
127.84
5
4
32
105.71
4ft fixture
7
52
"
8
1343
3
"
16
"
4.86
19
R
14.99
32
"
PP (Pendant) mounting plate dimensions
1
"
8
3.30
"
1
2
12.70
"
3
19.05
1"
25.40
"
4
2
52.84
7
62.08
3
32
16
"
31
"
1
32
49.92
"2
1
1
"
32
25.91
ADY071477 REV A (ECN080352)
Vault w/ visor
These installation instructions are valid with the above Ametrix styles.
C-Scroll w/ visor Roundel w/ visor
Installation Instructions
Sheet 4 of 5
Small, INDOOR
CPP/CPS
(Continuous Pendant)
Visor and Non-Visor
Warning
that all sources of power are turned off. All
work must meet local/national codes and be
performed by a certified electrician.
mount fixtures vertically.
: Before starting any work ensure
Do not
3
1.
Choose first fixture in run. First fixture depends on length of
run, refer to page four(4) for fixture identification. The final
fixture will have to have the extra wire capped off.
2.
Secure fixture head to pendant assembly using
#10-32x 5/8" end screw.
5
Securing first fixture to first pendant
Fixture wire
Canopy
#10-32 x5/8
End screw
Securing additional fixtures in run
Securing first fixture to wired center yoke
4
bracket
Power wire
from J-box
First fixture
head
#6-32 x 3/8"
Pan head screws
1.
Remove both #6-32 x3/8" Pan head screws and slide center
cover plate down.
2.
Run power wire from fixture through hub and into center
yoke bracket.
3.
Secure first fixture to center yoke bracket using #10-32 x5/8"
end screw.
6
Wiring fixtures to J-box
Fixture wire
#10-32 x 5/8
End screw
Center cover
plate
Fixture wire
#10-32 x 5/8"
Center cover
plate
1.
Mount next center or end pendant depending on length of
run.
2.
Run new fixture wire into center yoke bracket.
3.
Using #10-32 x5/8" end screws, secure new fixture head to
both pendants.
ADY071477 REV A (ECN080352)
End screw
Power wire
from J-box
Fixture wireFixture wire
Center cover plate
1.
Attach wires and ensure connections are properly matched.
(wire nuts by others)
2.
Replace center cover plate and secure using both #6-32 x
3/8" Pan head screws.
Vault w/ visor
Actual
Actual
These installation instructions are valid with the above Ametrix styles
C-Scroll w/ visor
Continuous Pendant Row Layouts
Roundel w/ visor
Installation Instructions
Sheet 5 of 5
Small, INDOOR
CPP/CPS
(Continuous Pendant)
Visor and Non-Visor
Warning
that all sources of power are turned off. All
work must meet local/national codes and be
performed by a certified electrician.
mount fixtures vertically.
: Before starting any work ensure
Do not
Nominal
Row
Length
(ft)
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Overall
Row
Length:
Pendant
(ft)
Row Breakdown/
Installation Sequence
2.6 2C
3.6 3C
4.6 4C
5.1 2C,2C
6.1 2C,3C
7.1 3C,3C
8.1 3C,4C
9.1 4C,4C
10.7 3C,3C,3C
11.7 4C,2C,4C
12.7 4C,3C,4C
13.7 4C,4C,4C
14.2 3C,3C,3C,3C
15.2 3C,3C,3C,4C
16.2 3C,4C,4C,3C
17.2 4C,4C,4C,3C
18.2 4C,4C,4C,4C
19.8 4C,3C,3C,3C,4C
20.8 3C,4C,4C,4C,3C
21.8 4C,4C,3C,4C,4C
21.8 4C,4C,3C,4C,4C
23.4 2C,4C,4C,4C,4C,2C
23.4 2C,4C,4C,4C,4C,2C
25.4 3C,4C,4C,4C,4C,3C
Nominal
Row
Length
(ft)
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Overall
Row
Length:
Pendant
(ft)
Row Breakdown/ Installa tion
Sequence
25.4 3C,4C,4C,4C,4C,3C
27.4 4C,4C,4C,4C,4C,4C
28.9 4C,4C,3C,3C,3C,4C,4C
29.9 3C,4C,4C,4C,4C,4C,3C
30.9 4C,4C,4C,3C,4C,4C,4C
31.9 4C,4C,4C,4C,4C,4C,4C
31.9 4C,4C,4C,4C,4C,4C,4C
32.5 2C,4C,4C,4C,4C,4C,4C,2C
34.5 3C,4C,4C,4C,4C,4C,4C,3C
35.5 4C,4C,4C,4C,3C,4C,4C,4C
36.5 4C,4C,4C,4C,4C,4C,4C,4C
38.0 4C,4C,4C,3C,3C,3C,4C,4C,4C
39.0 3C,4C,4C,4C,4C,4C,4C,4C,3C
39.0 3C,4C,4C,4C,4C,4C,4C,4C,3C
40.0 4C,4C,4C,4C,3C,4C,4C,4C,4C
41.0 4C,4C,4C,4C,4C,4C,4C,4C,4C
42.6 4C,4C,4C,4C,3C,3C,3C,4C,4C,4C
43.6 3C,4C,4C,4C,4C,4C,4C,4C,4C,3C
44.6 4C,4C,4C,4C,4C,3C,4C,4C,4C
45.6 4C,4C,4C,4C,4C,4C,4C,4C,4C,4C
46.1 3C,3C,4C,4C,4C,4C,4C,4C,4C,3C,3C
47.1 4C,4C,4C,4C,3C,3C,3C,4C,4C,4C,4C
48.1 3C,4C,4C,4C,4C,4C,4C,4C,4C,4C,3C
49.1 4C,4C,4C,4C,4C,3C,4C,4C,4C,4C,4C
(Custom row configurations are available however pricing may be affected)
ADY071477 REV A (ECN080352)
