DESCRIPTION
5”
The APWR LED remote series is a UL924 code compliant solution for
emergency lighting. It operates on 3.6 volts and can be powered from
the APXH exit or APCH combo series. It is wet location listed and can be
used indoors or outdoors. The two head versions will create 17 feet of
emergency egress coverage. Housings color options are white or black.
SPECIFICATION FEATURES
Electrical
- 3.6V DC Input Voltage
Code Compliance
- UL 924 Listed
- Wet Location Listed (APWR)
Lampholder/Mounting Plate
Construction
- Flame resistant and impact
resistant, injection molded
thermoplastic
- 0 °C to 40 °C (32 °F to 104 °F)
temperature rating
- California Energy Code
compliant
- Lamp heads adjust 80° from
vertical with 358° rotation
- Universal mounting plate
- Available in white or black
Catalog #
Project
Comments
Prepared by
Head/Lamp Data
- Long Life LED Emergency Heads
- Fully adjustable
- High impact thermoplastic
- Matches housing finish
- 3.6V, .78W DC Long Lasting LED
Heads
Warranty
- Five-year warranty
Sure-Lites
Type
Date
2 7/8”
[ 73.03mm]
ORDERING INFORMATION
SAMPLE NUMBER: APWR2BK
Series Remote Heads Housing Color Catalog numbers
APWR
APWR SPACING
1 = one LED head
2 = two LED heads
_ = White
BK = Black
APWR1, APWR2, APWR1BK, APWR2BK
[ 127mm]
APWR SERIES
REMOTE HEADS
LED EMERGENCY HEADS
WET LOCATION LISTED
17'
spacing
Eaton
1121 Highway 74 South
Peachtree City, GA 30269
P: 770-486-4800
www.eaton.com/lighting
Specifications and
dimensions subject to
change without notice.
ENERGY DATA
Power Consumption is equal to LED head
wattage.
TD505039EN
2017-10-11
