ArcLine Recessed LED luminaire
1' x 4'
2' x 2' 2' x 4'
ArcLine is a premium grade specifi cation lensed troffer series. This innovative,
high quality luminaire is dedicated to the latest solid state lighting and driver
technology for optimal performance and energy effi ciency. The ArcLine is
compatible with all of today’s popular ceiling systems and is available with a
number of options and accessories for application versatility. The ArcLine series
features effi ciency, quality and performance. The series is an excellent choice
for commercial offi ce spaces, schools, hospitals or retail merchandising areas.
Available in recessed and surface versions
Advanced optical control
High performance effi cacy up to 141 lm/W
Over 60% energy savings compared to fl uorescent
Buy with confi dence - proven Metalux quality
1
EATON ArcLine – Recessed LED luminaire
EATON ArcLine – Recessed LED luminaire
2
Page 3
Construction
Connected Lighting
Recessed: 2' x 2', 2' x 4' and 1' x 4'
Shallow depth: 3.25"
Tool-less hinge d door acces s
cULus damp location / IC Rated /
RoHS compliant / DLC Qualified
Sustainable materials
Five-year warranty
Options
Eight stocked lumen package s in two CCTs
– 2' x 2': 2,500 (20.2W) and 3,500 (29.5W)
– 2' x 4': 4,500 (32.4W) and 5,500 (41.1W)
Lens op tion – Cur ved Frosted
Univer sal (120V-277V) or 347V
Emergency – EL7W and EL14W
Surface mount field inst all kit s
Flex wiring configurations
Chicago plenum rated version
Systems
3-1/4"
[83mm]
WaveLinx
Wireless Connected Lighting System
Adjustable occupancy sensing and daylight dimming control
Simple, secure wireless connectivity with out-of-the -box code
compliance
Easy to use mobile application allows for fast set up and unlocks
advanced control capabilities
Detection pattern covers standard ceiling applications up to 12 feet
LumaWatt Pro
Wireless Connected Lighting System
powered by Enlighted
Controls
Lutron and DALI options with
UL 924 Emergency options
Flexibility to meet b uilding codes
and safety requirement s
3
EATON ArcLine – Recessed LED luminaire
Integrated sensors fac tory wired
and tested
Simplicity - The lighting plan is the
controls plan
WaveLinx
Wireless Connected Lighting System
LumaWatt Pro
Wireless Connected Lighting System
Confi gurable dimming, occupancy, light, temperature and power use
sensing
Enterprise-class wireless networking with fully addressable settings
Powerful software for energy management and Internet of Things (IoT)
data capture and analytics
Low bay detection pattern covers low - and high -ceiling applications
up to 20 feet
Page 4
Performance
High- performance ef fic acy up to 141 lumens per watt
Energy savings in excess of 60% compared to traditional fluoresc ent troffers
Three Correlated C olor Temperatures (3000K, 3500K, 4000K) at typical 85 CRI
1' x 4': L91 @ 60,0 00 hrs., 2' x 2': L94 @ 60,000 hrs., 2' x 4': L95 @ 60,000 hrs.
Binning: Per ANSI, 3-s tep MacAdam ellipse
Energy data
2' x 4' ArcLine series Popular fl uorescent fi xtures
Catalog number Lumens* Wattage Fixture type Lumens* Wattage
24ALNG-LD5-67-UNV-L835-CD1-U 6709 51.3 Troffer 332 6629 81.7 -37%
24ALNG-LD5-55-UNV-L835-CD1-U 5565 41.1 Parabolic 332 5646 83.0 -50%
Indirect Basket 332 4583 83.7 -61%
24ALNG-LD5-45-UNV-L835-CD1-U 4505 32.4
24ALNG-LD5-42-UNV-L835-CD1-U 4264 30.6
2' x 2' ArcLine series Popular fl uorescent fi xtures
Catalog number Lumens* Wattage Fixture type Lumens* Wattage
22ALNG-LD5-35-UNV-L835-CD1-U 3572 29.5 Troffer 2U6T8 3862 52.1 -43%
22ALNG-LD5-31-UNV-L835-CD1-U 3158 25.7
22ALNG-LD5-25-UNV-L835-CD1-U 2522 20.2
*Lumens listed are delivered lumens.
Spec Full Lens 228T5 4698 61.6 -47%
Spec Dual Lens 228T5 4576 58.0 -44%
Spec Full Lens 232 4413 50.6 -39%
Troffer 232 4310 52.0 -41%
Indirect Basket 232 3873 72.0 -57%
Spec Full Lens 224 3080 51.5 -50%
Spec Dual Lens 224 2975 52.0 -50%
Parabolic 2U6T8 2791 63.1 -59%
Troffer 317 2601 42.9 -52%
Parabolic 317 2588 49.1 -58%
Spec Dual Lens 214 2403 30.0 -32%
Energy
savings
Energy
savings
Compliance and approvals
LM79 / LM80
Compliant
5
