Page 1
Industrial Fluorescent
Ultra 47 F-Bay
Page 2
Maximize Energy Savings Without
Sacrificing Performance With The
Ultra 47 Fluorescent High-Bay
Cooper Lighting researches, develops and
utilizes the latest lamp and ballast technology
on the market.
With the launch of the GE T5HO 47W UltraStart® Watt Miser® System, Cooper
Lighting is now offering the Ultra 47 HBI, HBL, HBE, I5 and VT4 series of
products with the most energy efficient T5 high-output fluorescent system.
The design of these products utilizing the GE T5HO 47W UltraStart
®
Miser
System allows Cooper Lighting to achieve increased fixture efficiency
resulting in a similar amount of light as a 54–watt T5HO system while
delivering increased energy savings.
®
Watt
Page 3
System Benefits
• Increased Energy Savings
• Equivalent Light Output
• Lower Maintenance Costs
• Lower Watts / Sq. ft.
• 5 – Year 55C Warranty on
Lamps and Ballasts*
SYSTEM WAT TS* *
6 LAMP 54
WATT HIGH-BAY
6 LAMP ULTRA
47 HIGH-BAY
290 300 310 320 330 340 350
SYSTEM LUMENS**
6 LAMP 54
WATT HIGH-BAY
6 LAMP ULTRA
47 HIGH-BAY
310
24,662
341
LUMENS PER WATT**
6 LAMP 54
WATT HIGH-BAY
6 LAMP ULTRA
47 HIGH-BAY
68 70 72 74 76 78 80 82 8466
72
25,586
81
24,200 24,400 24,60 0 24,80 0 25,40025,000 25,60025,200 25,80024,000
*GE warranty applies to 4 and 6 lamp open uplight configurations in the HBI, HBL and HBE series.
**Data based upon in-fixture testing of catalog number HBI647–UPL utilizing
IESNA LM–63–02 photometric testing standard.
1
Page 4
Industrial Fluorescent
Energy Solutions
Based on:
Room Si ze: 25 0' x 182 '
Ceiling Height: 30'
Workp lace: 2. 5'
Rack Height: 15'
Rack Width : 16'
FIXTURE
QUANTITY
INPUT WATTS
TOTAL WAT T S
ENERGY SAVINGS
ENERGY SAVED kW
$ / kW * Hr
HOURS ON PER DAY
ENERGY SAVINGS / YEAR
6 LAMP 54 WATT T5
Aisle Vertical fc
Aisle Horizontal fc
Warehouse Open Area fc
Watts / Sq. ft.
Total Watts
No. of Fixtures
12. 8
27. 45
28.89
0.57
26257
77
6 LAMP 54 WATT T5
HIGH-BAY
HBI654–UPL
77
341
26257
6 LAMP ULTRA 47
Aisle Vertical fc
Aisle Horizontal fc
Warehouse Open Area fc
Watts / Sq. ft.
Total Watts
No. of Fixtures
6 LAMP ULTRA 47
HIGH-BAY
HBI6 47–UPL
77
310
23870
9%
2.387
$ 0.12
12
$ 1,254.61
13.04
27. 58
29
0.52
23870
77
Based on:
Room Si ze: 25 0' x 182 '
Ceiling Height: 30'
Workp lace: 2. 5'
Rack Height: 15'
Rack Width : 16'
FIXTURE
QUANTITY
INPUT WATTS
TOTAL WAT T S
ENERGY SAVINGS
ENERGY SAVED kW
$ / kW * Hr
HOURS ON PER DAY
ENERGY SAVINGS / YEAR
400 WATT HID
Aisle Vertical fc
Aisle Horizontal fc
Warehouse Open Area fc
Watts / Sq. ft.
Total Watts
No. of Fixtures
15. 74
27. 7 7
29.52
1.03
47008
104
400 WATT HID
MHSS40
104
452
4700 8
6 LAMP ULTRA 47
6 LAMP ULTRA 47
Aisle Vertical fc
Aisle Horizontal fc
Warehouse Open Area fc
Watts / Sq. ft.
Total Watts
No. of Fixtures
HIGH-BAY
HBI6 47–UPL
77
310
23870
49%
23 .138
$ 0.12
12
$ 12,161.33
13.04
27. 58
29
0.52
23870
77
2
Page 5
GE T5HO 47W
**Dat a based upon GE lamp and b allas t
specifications
per ANSI test procedures.
UltraStart
®
Watt-Miser
3 Advantages
You Can’t Deny
Energy Savings Advantage
Lamp Lumens
System Lumens (4 Lamp)
System Watts
Cathode Energy Cut Ballast
Lumens per Watt
Life Advantage
Lamp Life (3hrs / 12hrs )
Warranty (Lamp / Ballast)
UL Certified 55C Ambient
Thermal fold-back protection
Maintenance Advantage
Lamp Operation
Starting Time
Striation Control
Independent Lamp End of Life
UL Type CC Anti-arcing
RoHS Reduction Hazardous Substance
®
54W System
5,000
20,000
234W
NO
85 LPW
30K / 36K
3 yr + 5 yr
NO
NO
Ser-par
> 1.1 Sec
NO
NO
YES
NO
Ultra 47W System**
4,800
19,200
202W
YES – 94% efficiency
95 LPW
30K / 36K
5 yr + 5 yr
YES – 5 yr warranty
YES – protects against overheating
Parallel – one fails others remain on
< 700ms – important with sensors
YES – reduces striations
YES – only one lamp shuts down @EOL
YES – arcing protection
YES – think of future disposal today
Energy Savings
4 Lamp 5 Lamp 6 Lamp
$116 $14 5 $174
*Energ y savings per on e 54W T5 lamp, 30,00 0 hour
burn, & $0.12 kWhr ene rgy cost.
**Dat a based upon GE lamp and b allas t specifications
per ANSI test procedures.
Page 6
Ordering Information & Photometry
HBI T5
Series
HBI=High Bay
Industrial
No. of Lamps
4=4 Lamps
5=5 Lamps
6=6 Lamps
Lamp Type
47T5=47W T5HO Lamps (48”)
Distribution
N=Narrow Beam (Standard)
M=Medium Beam
W=Wide Beam
Shielding
Blank=None
WG=Wireguard & Doorframe
A=Prismatic Acrylic Lens & Doorframe (HBE only)
A/WG=Acrylic Lens, Wireguard & Doorframe (HBE only)
CL=Clear Acrylic Lens & Doorframe (HBE only)
CL/WG=Clear Lens, Wireguard & Doorframe (HBE only)
Length
Blank=4’ Length
8T=8’ Length
Series
I5=T5 Industrial
Mounting Arrangement
Blank=Stand Alone
R=Continuous Row
No. of Lamps
2=2 Lamps
3=3 Lamps
4=4 Lamps
Lamp Type
47T5=47W T5HO Lamps (48”)
Distribution Optic
Blank=Medium (Specular Aluminum)
G=Wide (High Reflectance White)
Shieldingt
Blank=Open
FL=Frosted Acrylic Lens
CL=Clear Acrylic Lens & Door Frame
ASY= Asymmetric Directional
WG=Heavy Duty Wireguard
Louver
Voltage
UNV=Universal
120/277 Voltage
120V=120 Volt
277V=277 Volt
Options
Lamps Installed
L5841=T5 Lamp, 85CRI 4100K
L5850=T5 Lamp, 85CRI 5000K
NOTES:
with wide distribution optic only.
motion sensor or emergency ballasts.
Top Connector Box options. See accessories.
ent environments not to exceed 149°F (65°C) in open uplight configurations and less lens
option.
(8)
When ordering MS option, specify UNV (for 120 or 277V), 347 or 480V.
(2)
(2)
Voltage
UNV=Universal 120/277
Voltage
120V=120 Volt
277V=277 Volt
Options
Lamps Installed
L5841=T5 Lamp, 85CRI 4100K
L5850=T5 Lamp, 85CRI 5000K
(6)
Ballast Type
EHT=T5HO Linear Electronic Program Rapid
Start High Ambient
Total Harmonic Distortion < 10%
(1)
NOTES:
Requires use of MC or MPC cord accessories, specify voltage for plugs.
must be specified when ordered with plugs or emergency ballasts.
specify voltage as UNV (for 120 or 277V), 347 or 480V.
T5 UNC versions.
exceed 149°F (65°C) in open uplight configurations and less lens option.
when ordering.
(4) (5)
(5)
EHT/HT5/HCT5 ballast systems suitable for ambient environments not to
I5
(3)
(4)
(1)
Requires use of MC or MPC cord accessories, specify voltage for plugs.
(7)
TAP option available with a maximum of two ballasts, including EM battery pack.
Ballast Type
T5 Systems
EHT=T5HO Linear Electronic Start High Ambient
Total Harmonic Distortion < 10%
(3)
Voltage must be specified when ordered with plugs,
(4)
Must specify lamps when ordering.
(6)
EHT ballast systems suitable for ambi-
(6)
(5)
For use with
(2)
Options
MP=Modular Power
Receptacle (Used for all
Cord or Cord and Plug
(1)
options)
NUA=No Uplight Aperture
Housing.
UPL=Uplight Apertures on
Reflector
MWS=Modular Wiring System
MS=360° or 180° Motion Sensor Installed,
120V through 347V or 480V
G2=Gasketed Door (Requires Selection
of Lensed Doorframe)
SDF=Slotted Doorframe (Requires Selection
of Lensed Doorframe)
(3)
(4)
Options
NUA=No Uplight Apertures Housing
UPL=Uplight Apertures on Reflector
PI/CPI=Plug-In (1, 2 or 3).
TILW=Tandem Inline Wiring
MWS=Modular Wiring System
MS=360° or 180° Motion Sensor
Installed, 120V through 347V, or 480V
MP=Modular Power Receptacle (Used for
all Cord or Cord and Plug options)
TAP=Top Access Plate
TACBP=Top Connector Box Plate
Use
When ordering MS option,
2 lamp ballast configurations only for
(7)
(3)
(2)
Voltage
(6)
Must specify lamps
(6)
(1)
(5)
Packaging
U=Unit Pack
PALC=Job Pack In
Carton
PAL=Job Pack Out
of Carton
(6)
Packaging
U=Unit Pack
PALC=Job Pack In
Carton
PAL=Job Pack Out
of Carton
(8)
4
Page 7
HBE T5 & HBL T5
Series
HBE=High Bay
Efficiency
HBL=High Bay
Linear
No. of Lamps
4=4 Lamps
6=6 Lamps
8=8 Lamps
10=10 Lamps
Lamp Type
47T5=47W T5HO Lamps (48”)
Distribution
N=Narrow Beam (Standard)
M=Medium Beam
W=Wide Beam
Shielding
Blank=None
WG=Wireguard
A=Prismatic Acrylic Lens & Doorframe (HBE only)
A/WG=Acrylic Lens, Wireguard & Doorframe (HBE only)
CL=Clear Acrylic Lens & Doorframe (HBE only)
CL/WG=Clear Lens, Wireguard & Doorframe (HBE only)
PHOTOMETRICS
(1)
Voltage
UNV=Universal
120/277 Voltage
120V=120 Volt
277V=277 Volt
Options
Lamps Installed
L5841=T5 Lamp, 85CRI 4100K
L5850=T5 Lamp, 85CRI 5000K
(5)
Ballast Type
EHT=T5HO Linear Electronic Program Rapid
Start High Ambient
Total Harmonic Distortion < 10%
(1)
NOTES:
Voltage must be specified when ordered with plugs or emergency ballasts.
(2)
When ordering MS option, specify as UNV (for 120 or 277V), 347 or 480V.
use of MC or MPC cord accessories, specify voltage for plugs.
systems suitab le for ambien t environments not to exceed 149°F (65°C) in open uplight
configurations and less lens option.
bined with Modular Power Receptacle (MP). For MWS with MP, choose MP in figure logic
and then choose MWS.
(4)
(5)
Must specify lamps when ordering.
Options
MP=Modular Power
Receptacle (Used for all Cord
or Cord and Plug options)
UPL=Uplight Apertures on
Reflector
MWS=Modular Wiring System
MS=360° or 180° Motion Sensor Installed,
120V through 347V or 480V
(3)
(4)
Requires
EHT/HT5/HCT5 ballast
(6)
Cannot be com-
Packaging
U=Unit Pack
PALC=Job
(3)
Pack In Carton
PAL=Job Pack
Out of Carton
(6)
(2)
Coefficients of Utilization
Effective floor cavity reflectance 20%
rc 80% 50% 30%
rw 70 50 30 10 50 30 10 50 30 10
RCR
117 117 117 117 107 107 107 101 101 101
0
107 102 97 94 93 90 87 88 86 83
1
97 89 82 76 82 77 72 77 73 70
2
89 78 70 64 72 66 61 69 63 59
3
81 70 61 54 64 58 52 61 55 51
4
75 62 54 47 58 51 45 55 49 44
5
69 56 48 41 53 45 40 50 44 39
6
64 51 43 37 48 41 36 46 40 35
7
60 47 39 33 44 37 32 42 36 31
8
56 43 35 30 41 34 29 39 33 29
9
53 40 32 27 38 31 27 36 30 26
10
Zonal Lumen Summary
Zone Lumens %Lamp %Fixture
0-30
7212 28.0 28.2
0-40
11157 43.4 43.6
0-60
18599 72.3 72.7
0-90
23829 92.7 93.1
90-120
137 0.5 0.5
90-130
307 1.2 1.2
90-150
965 3.8 3.8
90-180
1757 6.8 6.9
0-180
25586 99.5 100.0
Coefficients of Utilization
Effective floor cavity reflectance 20%
rc 80% 50% 30%
rw 70 50 30 10 50 30 10 50 30 10
RCR
99 99 99 99 91 91 91 86 86 86
0
89 84 80 76 77 74 71 73 70 68
1
80 73 66 61 66 61 57 60 59 55
2
73 63 56 50 58 52 47 55 50 46
3
66 56 48 42 51 45 40 48 43 38
4
61 49 41 35 45 39 34 43 37 33
5
56 44 36 31 41 34 29 39 33 29
6
52 40 32 27 37 31 26 35 30 25
7
48 36 29 24 34 27 23 32 27 22
8
45 33 26 21 31 25 21 30 24 20
9
42 31 24 19 29 23 19 27 22 18
10
Zonal Lumen Summary
Zone Lumens %Lamp %Fixture
0-30
7543 29.3 30.2
0-40
11643 45.3 46.6
0-60
19248 74.9 77.0
0-90
23832 92.7 95.4
90-120
140 0.5 0.6
90-130
259 1.0 1.0
90-150
607 2.4 2.4
90-180
1155 4.5 4.6
0-180
24988 97.2 100.0
Page 8
Cooper Lighting, LLC.
Customer First Center
1121 Highway 74 South
Peachtree City, GA 30269
P: 770-486-4800
F: 770-486-4801
www.cooperlighting.com
International Sales, USA
Cooper Lighting, LLC.
1121 Highway 74 South
Peachtree City, GA 30269
P: 770-486-4800
F: 770-486-4801
Canada
Cooper Lighting, LLC.
5925 McLaughlin Road
Mississauga, Ontario L5R 1B8
P: 905-507-4000
F: 905-568-7049
The Cooper Lighting Family
Halo
Metalux
Lumark
Sure-Lites
Neo-Ray
Corelite
Portfolio
Iris
Shaper
io
Lumière
Invue
McGraw-Edison
Streetworks
Fail-Safe
PDS
MWS
RSA
Ametrix
Domestic Facilities
Cranbury, New Jersey
Elk Grove Village, Illinois
Canadian Facility
Calgary, Alberta T2E 7V9
Mississauga, Ontario L5R 1B8
Irving, Texas
Ontario, California
Peachtree City, Georgia
25% PCRF
Cooper Lighting and Metalux are valuable trademarks of Cooper Industries in the United States and other countries.
You are not permitted to use the Cooper Trademarks without the prior written consent of Cooper Industries.
Cooper Industries plc
600 Travis, Ste. 5600
Houston, TX 77002-1001
P: 713-209-8400
www.cooperindustries.com
Printed in USAADF110284
Loading...
