METALUX
®
F-BAY POWER CONNECTIONS
Visit our web site at www.cooperlighting.com
Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 770.486.4800 FAX 770.486.4801 1/10 ADF060263
Items listed are the major options and accessories available on Metalux Recessed (Parabolic and Recessed) and Surface Fixtures. Additional options and accessories are available.
Consult Pre Sales Technical Support for additional information.
POWER CONNECTIONS DESIGNATION DESCRIPTION
Connect directly to F-Bay or Modular Motion
Sensor with a 3', 6', 9', 12' or 15' long modular
cord & plug set w/NEMA 15 amp twist lock plug.
MPC3=3' Modular Power Cord &
Plug (specify voltage for plug)
MPC6=6' Modular Power Cord &
Plug (specify voltage for plug)
MPC9=9' Modular Power Cord &
Plug (specify voltage for plug)
MPC12=12' Modular Power Cord
& Plug (specify voltage for plug)
MPC15=15' Modular Power Cord
& Plug (specify voltage for plug)
Modular Cord & Plug
Connect directly to F-Bay or Modular Motion
Sensor with a 3', 6', 9', 12' or 15' long 3/16"
standard Modular Power Cord.
Modular Cord
POWER CONNECTIONS DESIGNATION DESCRIPTION
MWS is a simple and cost effective modular wiring
system consisting of factory assembled components
ready to be snapped together into a complete branch
circuit wiring system.
With MWS, branch circuit wiring can be installed in
minutes instead of hours reducing labor by 80%.
MWS= Modular Wiring System
MWS
MDS6= 6' Modular Power Cord
with MWS 27DS18/2G06MP.
MC3=3' Cord
MC6=6' Cord
MC9=9' Cord
MC12=12' Cord
MC15=15' Cord
Connect directly to F-Bay or Modular Motion Sensor
with a 6' long Cord and MWS Connector.
