Shoplights
SHP Series - LED Shoplights
The Metalux SHP LED Shoplight comes in two new lumen packages, expanded mounting options and a compact, low
profi le design. This fully integrated LED luminaire can be used in applications such as workshops and utility rooms where
task lighting and portability are important. The all new SHP shoplight can be surface mounted or suspended using the
included hanging chain, S-hooks or brackets. A 5 ft. grounded cord and plug, and pull chain allows for easy on/off operation
and installation. The SHP has a fi ve-year warranty and uses LEDs at a rated life of 50,000 hours.
LED
Construction and Performance
• Fully assembled 43" long metal housing with finished end caps
• Two unique lumen packages – standard (3200) and high output (4500)
• Frosted white polycarbonate lens for an even distribution
• 4000K CCT at CRI > 80 provides excellent color rendering for task applications
• Includes 36" chain-set, S-hooks and snap brackets for suspended or surface mount installation
• Standard 120V 5 ft. grounded power cord and plug, and pull chain for easy on/off operation
• Up to 109 lm/ W provides >40% energy savings over 2-lamp T8 shoplights
Reliability and Compliance
• cULus listed for dry locations, Energy Star, and FCC Class B compliant
• Five-year comprehensive warranty
• Excellent lumen maintenance L70 > 50K based on TM21
LED Compared to T12 Fluorescent Compared to T8 Fluorescent
Model# Product Description Lumens Wattage Fixture Wattage Energy Savings Fixture Wattage Energy Savings
4SHP3240R Utility LED Shoplight, 120V 3460 32W 62W 48% 56W 43%
4SHP4540R Utility LED Shoplight, 120V 4486 43W 62W 31% 56W 23%
Model# Product Description UPC Unit Carton (L x W x H) Energy Qualifi cation
4SHP3240R Utility LED Shoplight, 3200 lumens, 4000K, 120V 080083785599 44 in. x 4.3 in. x 3.5 in. Energy Star
4SHP4540R Utility LED Shoplight, 4500 lumens, 4000K, 120V 080083785605 44 in. x 4.3 in. x 3.5 in. Energy Star
®
®
Eaton
1121 Highway 74 South
Peachtree City, GA 30269
P: 770-486-4800
www.eaton.com/lighting
Canada Sales
5925 McLaughlin Road
Mississauga, Ontario L5R 1B8
P: 905-501-3000
F: 905-501-3172
© 2017 Eaton
All Rights Reserved
Printed in USA
Publication No. SA519024EN
September 26, 2017
Eaton is a registered trademark.
All other trademarks are property
of their respective owners.
Product availability, specifications, and
compliances are subject to change
without notice.
