MODEL

252 Black composite with

1/2" NPS stem

SOURCE

Halogen

50MR16 50W / MR16 / GU5.3

12V remote transformer required - not included

Lamp not included

FINISH

BK

Black

OPTIONS

FWC

Field wiring
channels in
lieu of 8" leads

VOLTS

12

SOURCE

Halogen

75MR16 75W / MR16 / GU5.3

12V remote transformer required - not included

Lamp not included

FINISH

Painted

BK
BZ
CS
VE
WT

Black
Bronze
City silver
Verde
White

VOLTS

12

SOURCE

Halogen

50T4 50W / T4 / GY6.35

12V remote transformer required - not included

Lamp not included

FINISH

Painted

BK
BZ
CS
VE
WT

Black
Bronze
City silver
Verde
White

VOLTS

12

CAMBRIA 252

50W (max)

MR16 Halogen

Low Voltage (12V)

FEATURES

• 200° tilt, 360° rotation
(patented pivot system)

• Corrosion-proof composite
construction

• Stainless steel & brass hardware

• Holds up to 3 optical accessories

• UL / cUL listed

• Three (3) year warranty

CAMBRIA 204

75W (max)

MR16 Halogen

Low Voltage (12V)

FEATURES

• 340° tilt, 360° rotation

• Precision machined materials

• Stainless steel hardware

• S.P.S. Siphon Protection System

• Holds up to 3 optical accessories

• UL / cUL listed

• Three (3) year warranty

CARMEL 403

50W (max)

T4 Halogen

Low Voltage (12V)

FEATURES

• Use with or without optional mounting
arms

• 200° tilt, 360° rotation

• Die-cast housing, machined stem

• Stainless steel hardware

• S.P.S. Siphon Protection System

• UL / cUL listed

• Three (3) year warranty

MODEL

204
204-CRS

1/2" NPS side swivel stem
1/2" NPS center rear swivel

MODEL

403 Mini-flood with 1/2" NPS

adjustable stem

OPTIONS

HA24
HA30
HA36
SA24
SA30
SA36

24" hook arm
30" hook arm
36" hook arm
24" straight arm
30" straight arm
36" straight arm

ACCENT / FLOOD: LOW VOLTAGE

1033

COOPER LIGHTING

LUMIERE

`

®

SAMPLE NUMBER: 252-50MR16-12-BK

SAMPLE NUMBER: 204-75MR16-12-BK

SAMPLE NUMBER: 403-50T4-12-BK-HA24

Note: See "Accessories" section for Low Voltage Cable & Transformers, Mounting Accessories, Glare Shields, Lenses, Louvers, Color Filters and Lamps.

Shown with Glare
Shield accessory
(order separately).
