Cooper Lighting 494-S User Manual
SHAPER
24"
10"
28" ø
5" ø
3/4"
28" ø
32"
12"
36" ø
5" ø
3/4"
36" ø
42" ø
40"
14"
42" ø
5" ø
3/4"
PENDANTS
™
5" ø
24"
5"
24" ø
33-1/2" ø
33-1/2" ø
494-S SERIES
494-S Direct/Indirect Pendant features
a luminous bowl with a triple ring
trim and is available in two diameters
with multiple mounting options.
Sample Number: 494-S-34-CFL/8/32-347V-SCL-32
Series
494-S = Luminous
Bowl w/ Triple Ring
Trim
Size
34"
40"
Lamp
CFL/4/26
CFL/4/32
CFL/4/39
CFL/4/42
CFL/8/26
CFL/8/32
CFL/8/27
CFL/8/42
INC/3/100
INC/6/100
Notes:
1. Available in 34".
2. Available in 40".
3. Available with CFL only.
4. For polished finishes the bottom inside edge of the ring is satin to prevent upper ring reflections.
5. Consult the factory for available options.
6. Not available with 1SAC, SJWAC or SJCAC. Specify up to 45°.
1
1
2
2
1
1
1
2
1
2
34" ø STANDARD
Voltage
120V
3
277V
3
347V
3/4"
8"
4
Finish
MW (standard),
CC, OBRS, PB,
PC, PCP, PN, SAL,
SB, SC, SCL, SCP,
SN, SNL
38"
5"
40" ø
Options
1S
3S
QP
SJCAC
SJWAC
TP
TSS2B
TSS3B
TSS4B
ACR
DL
5
DM
IEM
6
SCA
FB
5" ø
3/4"
28" ø
40" ø
40" ø
40" ø STANDARD
Suspension Height
32'' (OA) - 34'' dia.
38'' (OA) - 40'' dia.
Or Specify
MATERIAL
Painted and plated cold
rolled steel. Matte white
acrylic bowl.
Stem Aircraft Cable
(Standard): One 5/8" stem
and three or four 3/32"
8"
cables with a standard
hang height of 24"(OA),
minimum 20" (OA).
INSTALLATION
Supplied with either a
circle strap mounting
canopy or bar strap that
mounts to a 4" J-box or
plaster ring. Integral
safety cable provided.
BALLAST
Integral electronic HPF,
multi-volt 120/277V (347V
Canada), thermally
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage.
LAMP/SOCKET
34": Four (4) or eight (8)
26W or 32W (GX24q-3)
4-pin triple CFL lamps or
three (3) 100W A-19
lamps.
40": Four (4) 39W (2G11)
high lumen CFL lamps,
(8) 27W (G211) high
lumen CFL lamp, 42W
(GX24q-4) 4-pin triple CFL
lamps or six (6) 100W
A-19 lamps. CFL socket
injection molded plastic.
INC socket fired ceramic
rated for 660W-250V.
Lamps furnished by
others.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
MATERIAL
Painted and plated cold
rolled steel or natural
aluminum. Optional
Trim Ring. Matte white
acrylic bowl.
Single Stem Aircraft
Cable (Standard): One
5/8" stem and three or
four 3/32" cables with a
standard hang height of
24" (OA) for the 28" dia. ,
32" (OA) for the 36" dia.
and 40" (OA) for the 42"
499 SERIES
499 Direct/Indirect Pendant features a
luminous bowl and is available in
three diameters with multiple
mounting options.
Notes:
1. Available in 28".
2. Available in 36".
3. Available in 42".
4. Available with CFL only.
5. Not available in 27W.
6. Consult the factory for available options.
7. Supplied by others.
8. Not available with 1SAC, SJWAC or SJCAC. Specify up to 45°.
Sample Number: 499-36-CFL/4/26-347V-OBRS-__
Series
499=
Direct/Indirect
Bowl
Size
28"
36"
42"
Lamp
CFL/4/26
CFL/4/27
CFL/4/32
CFL/4/40
CFL/4/50
CFL/6/40
CFL/8/40
CFL/8/50
INC/3/150
INC/6/100
INC/6/150
Voltage
1
120V
2
277V
1
347V
2, 3
3
2
3
3
1
2
3
4
4
Options
1S
3S
QPB
SJCAC
SJWAC
TSS2B
TSS3B
TSS4B
CBD
Finish
MW (standard),
CC, OBRS, PB, PC,
PCP, SAL, SB, SC,
SCL, SCP
DL
5, 6
DM
CFL
2, 3
IEM
7
REM
8
SCA
FB
TR
Suspension
Height
24'' (OA) - 28'' dia.
32'' (OA) - 36'' dia.
40'' (OA) - 42'' dia.
Or Specify
dia., minimum 20" (OA).
INSTALLATION
Supplied with either a
circle strap mounting
canopy or bar strap that
mounts to a 4" J-box or
plaster ring. Integral
safety cable provided.
BALLAST
Integral electronic HPF,
multi-volt 120/277V (347V
Canada), thermally
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage.
LAMP/SOCKET
28": Four (4) 26W or 32W
(GX24q-3) 4-pin triple CFL
lamps or three (3) 150W
A-19 lamps.
36": Four (4) 27W (2G11)
or four (4) or six (6) 40W
(2G11) high lumen
CFL lamps or six (6) 100W
A-19 lamps.
42": Four (4) or eight (8)
40W or 50W (2G11) high
lumen CFL lamps or six
(6) 150W A-21 lamps. CFL
socket injection molded
plastic. INC socket fired
ceramic rated for
660W-250V. Lamps
furnished by others.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
COOPER LIGHTING
967
