ALL-PRO™
ERT710 - Specular Reflector
• Coil Spring retention
• Lamps:
EI700 EI700AT
EI700R EI700RAT
ERT712 - White Reflector
• Socket supporting trim
• ERT712 - Friction clip retention
• ERT712TS - Torsion spring retention
• Lamps:
RECESSED DOWNLIGHTING Incandescent
EI700 EI700AT EI700R EI700RAT EI700NB EI700ATNB
ERT707 - Metal Baffle
• Coil spring retention
• Lamps:
EI700 EI700AT EI700R EI700RAT
75W R30, 65W BR30, 50W PAR30, 75W PAR30L
50W PAR30, 75W PAR30L, 65W BR30, 75W R30
40W A19, 65W BR30, 75W PAR30, 75W PAR30L, 75W R30, 90W BR40
50W PAR30, 65W BR30, 75W R30, 75W PAR30L
Height: 2-7/8” [73mm]
OD: 7-1/4”[184mm]
ERT712TS ERT712
Height: 5-3/8” [136mm]
OD: 7-1/4”[184mm]
Height: 2-7/8” [73mm]
OD: 8”[203mm]
EI700AT EI700RAT EI700NB EI700ATNBEI700 EI700R
ERT710G
High Gloss Appliance White Trim with Gold Reflector
trim trim
ERT712TS
High Gloss Appliance White Trim with White reflector and Torsion Spring Construction
ERT707WHT
High Gloss Appliance White Trim with White Baffle
ERT710
High Gloss Appliance White Trim with Clear Specular Reflector
ERT712
High Gloss Appliance White Trim with White reflector
ERT707
High Gloss Appliance White Trim with Black Baffle
ERT713 - Black Metal Baffle
• Socket supporting trim
• ERT713 - Friction clip retention
trim trim
• ERT713TS - Torsion spring retention
• Lamps:
EI700 EI700AT EI700R EI700RAT
40W A19, 65W BR30, 75W PAR30, 75W PAR30L, 90W BR40
40W A19, 65W BR30, 75W R30, 75W PAR30, 75W PAR30L, 90W BR40
ERT713TS ERT713
Height: 5” [127mm]
OD: 7-1/4”[184mm]
ERT713TS
High Gloss Appliance White Trim with Black Baffle and Torsion Spring Construction
ERT713
High Gloss Appliance White Trim with Black Baffle
ERT713WHT - Metal Baffle
• Socket supporting trim
• ERT713WHT - Friction clip retention
trim trim
• ERT713WHTTS - Torsion spring retention
• Lamps:
EI700 EI700R EI700AT EI700RAT EI700NB EI700ATNB
* When using an Air-Tite trim to meet California Title 24 air tight compliance, an additional gasket is required between the finished ceiling and the trim flange ring. For California
Title 24 compliance use accessory trim gasket GA-ATRIM. Order separately in a 6 pack: GA-ATTRIM-6PK
40W A19, 65W BR30, 75W R30, 75W PAR30, 75W PAR30L, 90W BR40
ERT713WHTS ERT713WH
Height: 5-3/8” [136mm]
OD: 7-1/4”[184mm]
ERT713WHTTS
High Gloss Appliance White Trim with White Baffle and Torsion Spring Construction
ERT713WHT
High Gloss Appliance White Trim with White Baffle
COOPER LIGHTING
250
ALL-PRO™
ERT710 - Specular Reflector
• Coil Spring retention
• Lamps:
ET700
ET700R
ERT712 - White Reflector
• Socket supporting trim
• ERT712 - Friction clip retention
• ERT712TS - Torsion spring retention
• Lamps:
ET700
RECESSED DOWNLIGHTING Incandescent
ET700R
ERT707 - Metal Baffle
• Coil spring retention
• Lamps:
ET700
ET700R
65W BR30, 75W R30, 75W PAR30, 150W R40, 150W PAR38
65W BR30, 75W R30, 75W PAR30, 75W PAR30L, 150W R40
85W BR30, 120W BR40, 100W R30, 75W PAR30L, 100W A19
65W BR30, 75W PAR30L
65W BR30, 75W R30, 75W PAR30
65W BR30, 75W R30, 75W PAR30, 75W PAR30L
Height: 2-7/8” [73mm]
OD: 7-1/4”[184mm]
ERT712TS ERT712
Height: 5-3/8” [136mm]
Height: 2-7/8” [73mm]
OD: 8”[203mm]
OD: 7-1/4”[184mm]
ERT710G
High Gloss Appliance White Trim with Gold Reflector
trim trim
ERT712TS
High Gloss Appliance White Trim with White reflector and Torsion Spring Construction
ERT707WHT
High Gloss Appliance White Trim with White Baffle
ET700 ET700RET700 ET700R
ERT710
High Gloss Appliance White Trim with Clear Specular Reflector
ERT712
High Gloss Appliance White Trim with White reflector
ERT707
High Gloss Appliance White Trim with Black Baffle
ERT709 Large Aperture Metal Baffle
• Coil spring retention
• Lamps:
ET700
ERT713 - Black Metal Baffle
• Socket supporting trim
• ERT713 - Friction clip retention
• ERT713TS - Torsion spring retention
• Lamps:
ET700
ET700R
ERT713WHT - White Metal Baffle
• Socket supporting trim
• ERT713WHT - Friction clip retention
• ERT713WHTTS - Torsion spring retention
• Lamps:
ET700
ET700R
120W R40, 120W PAR38
75W PAR30L, 85W BR30, 100W R30, 100W A19, 120W BR40
65W BR30, 75W PAR30L
75W PAR30L, 85W BR30, 100W R30, 100W A19, 120W BR40
65W BR30, 75W PAR30L
Height: 2-5/8” [67mm]
OD: 8”[203mm]
ERT713TS ERT713
Height: 5” [127mm]
ERT713WHTS ERT713WHT
Height: 5-3/8” [136mm]
OD: 7-1/4”[184mm]
OD: 7-1/4”[184mm]
ERT709WHT
High Gloss Appliance White Trim with White Baffle
trim trim
ERT713TS
High Gloss Appliance White Trim with Black Baffle and Torsion Spring Construction
trim trim
ERT713WHTTS
High Gloss Appliance White Trim with White Baffle and Torsion Spring Construction
ERT709
High Gloss Appliance White Trim with Black Baffle
ERT713
High Gloss Appliance White Trim with Black Baffle
ERT713WHT
High Gloss Appliance White Trim with White Baffle
* When using an Air-Tite trim to meet California Title 24 air tight compliance, an additional gasket is required between the finished ceiling and the trim flange ring. For California
Title 24 compliance use accessory trim gasket GA-ATRIM. Order separately in a 6 pack: GA-ATTRIM-6PK
COOPER LIGHTING
254
EI700U EI700UAT
ERT710 - Specular Reflector
• Coil Spring retention
• Lamps:
75W PAR30,
EI700U EI700UAT
ERT712 - White Reflector
• Socket supporting trim
• ERT712 - Friction clip retention
• ERT712TS - Torsion spring retention
• Lamps:
EI700U EI700UAT
ERT707 - Metal Baffle
• Coil spring retention
• Lamps:
EI700U EI700UAT
75W PAR30L,
85W BR30, 90W BR40, 100W R30, 100W R40, 100W PAR38
60W A19, 75W PAR30, 75W PAR30L, 85W BR30, 100W R30, 120W BR40
65W BR30, 75W R30, 75W PAR30, 75W PAR30L, 90W PAR38, 90W BR40, 100W R40
Height: 2-7/8” [73mm]
OD: 7-1/4”[184mm]
ERT712TS ERT712
Height: 5-3/8” [136mm]
Height: 2-7/8” [73mm]
OD: 8”[203mm]
OD: 7-1/4”[184mm]
ERT710G
High Gloss Appliance White Trim with Gold Reflector
trim trim
ERT712TS
High Gloss Appliance White Trim with White reflector and Torsion Spring Construction
ERT707WHT
High Gloss Appliance White Trim with White Baffle
HALO
ERT710
High Gloss Appliance White Trim with Clear Specular Reflector
ERT712
High Gloss Appliance White Trim with White reflector
ERT707
High Gloss Appliance White Trim with Black Baffle
RECESSED DOWNLIGHTING Incandescent
®
ERT709 Large Aperture Metal Baffle
• Coil spring retention
• Lamps:
EI700U EI700UAT
ERT713 - Black Metal Baffle
• Socket supporting trim
• ERT713 - Friction clip retention
• ERT713TS - Torsion spring retention
• Lamps:
EI700U EI700UAT
ERT713WHT - White Metal Baffle
• Socket supporting trim
• ERT713WHT - Friction clip retention
• ERT713WHTTS - Torsion spring retention
• Lamps:
EI700U EI700UAT
90W BR40
60W A19, 75W PAR30, 75W PAR30L, 85W BR30, 120W BR40
60W A19, 75W PAR30, 75W PAR30L, 85W BR30, 100W R30, 120W BR40
Height: 2-5/8” [67mm]
OD: 8”[203mm]
ERT713TS ERT713
Height: 5” [127mm]
ERT713WHTS ERT713WH
Height: 5-3/8” [136mm]
OD: 7-1/4”[184mm]
OD: 7-1/4”[184mm]
ERT709WHT
High Gloss Appliance White Trim with White Baffle
trim trim
ERT713TS
High Gloss Appliance White Trim with Black Baffle and Torsion Spring Construction
trim trim
ERT713WHTTS
High Gloss Appliance White Trim with White Baffle and Torsion Spring Construction
ERT709
High Gloss Appliance White Trim with Black Baffle
ERT713
High Gloss Appliance White Trim with Black Baffle
ERT713WHT
High Gloss Appliance White Trim with White Baffle
* When using an Air-Tite trim to meet California Title 24 air tight compliance, an additional gasket is required between the finished ceiling and the trim flange ring. For California
Title 24 compliance use accessory trim gasket GA-ATRIM. Order separately in a 6 pack: GA-ATTRIM-6PK
COOPER LIGHTING
259259259
