OWNER’S MANUAL
Split Air Conditioner
Nordic Series
M
ODELS
For proper operation, please read and keep this manual carefully.
Designed by Cooper&Hunter International Corporation, Oregon, USA
www.cooperandhunter.com
:
CH-S09FTXN
CH-S12FTXN
CH-S18FTXN
CH-S24FTXN
Energy Label
Annual energy efficiency perfomance ratio is
calculated by overall capacity and average
operaing time (apr 500 hours) multiplication in
full-load coling mode operation.
Cooling capacity
is device cooling capaciy (demanded in kWh) in
full-load cooling mode operation. ERR energy
label index is ratio of cooling capacity to its
electric energy input attainment. Energy label
depends on ERR index rate.
Cooling mode energy label class
A
3.2 ≤ EER
B 3 ≤ EER < 3.2
C 2.8 ≤ EER < 3
D
E
F
G
*
for split and multi-split systems only.
2.6 ≤ EER < 2.8
2.4 ≤ EER < 2.6
2.2 ≤ EER < 2.4
EER < 2.2
Heating capacity
is device heating capaciy (demanded in kWh) in
full-load heating mode operation. COP capacity
index is ratio of heating capacity to its electric
energy input attainment.
Energy label depends on COP index rate.
Heating mode energy label class
Device Energy Lable
Manufacturer
Outdoor unit
Indoor unit
Cooling mode Energy Label Class
Maximum efficiency
Minimum efficiency
A
ir Conditioner
A
B
C
D
E
F
G
* for split and multi-split
3.6 ≤ COP
3.4 ≤ COP < 3.6
3.2 ≤ COP < 3.4
2.8 ≤ COP < 3.2
2.6 ≤ COP < 2.8
2.4 ≤ COP < 2.6
COP < 2.4
systems only.
Content
Operation Notices
Precautions............................................................................................................1
Parts name ............................................................................................................6
Screen Operation Guide
Buttons on remote controller .................................................................................7
Introduction for icons on display screen ................................................................7
Introduction for buttons on remote controller .........................................................8
Function introduction for combination buttons .....................................................12
Operation guide ...................................................................................................13
Replacement of batteries in remote controller .....................................................13
Emergency operation ..........................................................................................14
Maintenance
Clean and maintenance.......................................................................................14
Malfunction
Malfunction analysis ............................................................................................17
Installation Notice
Installation dimension diagram ............................................................................21
Tools for installation .............................................................................................22
Selection of installation location ..........................................................................22
Requirements for electric connection ..................................................................23
Installation
Installation of indoor unit......................................................................................24
Installation of outdoor unit ...................................................................................29
Vacuum pumping .................................................................................................32
Leakage detection ...............................................................................................32
Check after installation ........................................................................................33
Test and operation
Test operation ......................................................................................................33
Attachment
Configuration of connection pipe
Pipe expanding method
.......................................................................................36
.........................................................................34
This appliance is not intended for use by persons (including children) with reduced physical,
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do not dispose this product as unsorted municipal waste. Collection of
such waste separately for special treatment is necessary.
sensory
Precautions
WARNING
Operation and Maintenance
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Do not connect air conditioner to multi-purpose socket.
Otherwise, it may cause fire hazard.
Do disconnect power supply when cleaning air
conditioner. Otherwise, it may cause electric shock.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Do not wash the air conditioner with water to avoid
electric shock.
Do not spray water on indoor unit. It may cause electric
shock or malfunction.
After removing the filter, do not touch fins to avoid injury.
Do not use fire or hair dryer to dry the filter to avoid
deformation or fire hazard.
1
.
Precautions
WARNING
Maintenance must be performed by qualified
professionals. Otherwise, it may cause personal injury
or damage.
Do not repair air conditioner by yourself. It may cause
electric shock or damage. Please contact dealer when
you need to repair air conditioner.
Do not extend fingers or objects into air inlet or air
outlet. It may cause personal injury or damage.
Do not block air outlet or air inlet. It may cause
malfunction.
Do not spill water on the remote controller, otherwise the
remote controller may be broken.
When below phenomenon occurs, please turn off air
conditioner and disconnect power immediately, and then
contact the dealer or qualified professionals for service.
● Power cord is overheating or damaged.
● There’s abnormal sound during operation.
● Circuit break trips off frequently.
● Air conditioner gives off burning smell.
● Indoor unit is leaking.
If the air conditioner operates under abnormal conditions,
it may cause malfunction, electric shock or fire hazard.
When turning on or turning off the unit by emergency
operation switch, please press this switch with an insulating
object other than metal.
Do not step on top panel of outdoor unit, or put heavy
objects. It may cause damage or personal injury.
2
Precautions
WARNING
Attachment
Installation must be performed by qualified professionals.
Otherwise, it may cause personal injury or damage.
Must follow the electric safety regulations when installing
the unit.
According to the local safety regulations, use qualified
power supply circuit and circuit break.
Do install the circuit break. If not, it may cause malfunction.
An all-pole disconnection switch having a contact separation
of at least 3mm in all poles should be connected in fixed
wiring.
Including an circuit break with suitable capacity, please
note
magnet buckle
the circuit-short and
the following table.Air switch should be included
and heating buckle function, it can protect
overload.
Air Conditioner should be properly grounded. Incorrect
grounding may cause electric shock.
Don't use unqualified power cord.
Make sure the power supply matches with the
requirement of air conditioner.Unstable power supply or
incorrect wiring or malfunction. Please install proper power
supply cables before using the air conditioner.
Properly connect the live wire, neutral wire and
grounding wire of power socket.
Be sure to cut off the power supply before proceeding
any work related to electricity and safety.
3
Precautions
WARNING
Do not put through the power before finishing installation.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
The temperature of refrigerant circuit will be high, please
keep the interconnection cable away from the copper
tube.
The appliance shall be installed in accordance with
national wiring regulations.
Installation must be performed in accordance with the
requirement of NEC and CEC by authorized personnel
only.
The air conditioner is the first class electric appliance. It
must be properly grounding with specialized grounding
device by a professional. Please make sure it is always
grounded effectively, otherwise it may cause electric shock.
The yellow-green wire in air conditioner is grounding
wire, which can't be used for other purposes.
The grounding resistance should comply with national
electric safety regulations.
The appliance must be positioned so that the plug is
accessible.
All wires of indoor unit and outdoor unit should be
connected by a professional.
If the length of power connection wire is insufficient, please
contact the supplier for a new one. Avoid extending the
wire by yourself.
4
Precautions
WARNING
For the air conditioner with plug, the plug should be
reachable after finishing installation.
For the air conditioner without plug, an circuit break
must be installed in the line.
If you need to relocate the air conditioner to another
place, only the qualified person can perform the work.
Otherwise, it may cause personal injury or damage.
Select a location which is out of reach for children and
far away from animals or plants.If it is unavoidable,
please add the fence for safety purpose.
The indoor unit should be installed close to the wall.
Working temperature range
Indoor side DB/WB(℃) Outdoor side DB/WB(℃)
Maximum cooling 32/23 43/26
Maximum heating 27/- 24/18
NOTICE:
● The operating temperature range (outdoor temperature) for cooling only unit is
18℃~43℃; for heat pump unit is -20℃~ 43℃.
5
Parts Name
Indoor Unit
air inlet
air outlet
display
cooling indicator
heating indicator
aux.button
(Display content or position may be different from above
graphics, please refer to actual products)
temp. indicator
drying indicator
power indicator
receiver window
Outdoor Unit
panel
horizontal louver
B
S
remote control
air inlet
handle
air outlet
NOTICE:
Actual product may be different from above graphics, please refer to actual
products.
6
Buttons on remote controller
1
3
4
7
8
9
11
12
FAN
A R
HUM DITY
FILTER
TURBO
ON/OFF
FAN
X-FAN
TURBO
AUTO
HEALTH
TEMP
SLEEP
OPER
X-FAN
HOUR
ON/OFF
MODE
TIMER
LIGHT
2
5
6
10
13
1 ON/OFF button
2 MODE button
3 +/- button
4 FAN button
button
5
6 button
7 HEALTH SAVE button
8 X-FAN button
(Note: X-FAN is the same with BLOW)
9 TEMP button
10 TIMER button
11 TURBO button
12 SLEEP button
13 LIGHT button
Introduction for icons on display screen
air mode
Operation mode
Auto mode
Cool mode
Dry mode
Fan mode
Heat mode
Child Lock
Sleep mode
Temp. display type
:Set temp.
:Indoor ambient temp.
:Outdoor ambient temp.
AUTO
FAN
HEALTH
AIR
HUMIDITY
FILTER
TURBO
light
7
OPER
X-FAN
HOUR
ON/OFF
set fan speed
send signal
health mode
X-fan
set temperature
turbo mode
TIMER ON/TIMER OFF
set time
left & right swing
Up & down swing
Introduction for buttons on remote controller
Note:
● After putting through power, air conditioner will give out a sound and operation
indicator " " is ON (red indicator). You can operate the air conditioner through
the remote controller.
●
At ON status, after each pressing button on remote controller, the signal icon " "
indicates the signal has been sent to air conditioner.
● At OFF status, display screen on remote controller displays set temperature.
At on status, display screen on remote controller displays the corresponding startup
function’s icon.
ON/OFF button
1
Press this button can turn on or turn off the air conditioner. After turning on the unit,
operation indicator " " on indoor unit is ON (green indicator. Color may be different for different models)and indoor unit gives out a sound.
MODE button
2
Press this button can select your required operation mode.
AUTO COOL FANDRY HEAT
● After selecting auto mode, air conditioner will operate automatically according to
ambient temperature. Set temperature can’t be adjusted and also can’t be displa yed. Press "FAN" button can adjust fan speed. Press
angle.
●
After selecting cool mode, air conditioner operates under cool mode. Cool indicator
" " on indoor unit is ON. You can press "+" or "-" button to adjust set temperature.
Press "FAN" button can adjust fan speed. Press
angle.
● After selecting dry mode, air conditioner operates under dry mode at low speed.
Dry indicator
justed. Press
● After selecting fan mode, air conditioner operates only under fan mode, All mode
indicators on indoor unit is OFF. Operation indicator is ON. Press
adjust fan speed. Press
●
After selecting heat mode, air conditioner operates under heat mode. Heat indicator
"
" on indoor unit is ON. You can press "+" or "-" button to adjust set temperature
Press "FAN" button to adjust fan speed. Press " " button to adjust
(Cooling only unit can’t receive the signal for heating mode.)
" "
on indoor unit is ON. Under dry mode, fan speed can’t be ad-
" "
button to adjust swing angle.
" "
button to adjust swing angle.
" "
" "
button can adjust swing
button can adjust swing
"FAN" button can
swing angle.
8
.
Introduction for buttons on remote controller
Note:
For preventing cold wind, after starting up heating mode, indoor fan will blow fan
afterdelaying 1-5min. (Details time is decided by indoor ambient temperature)
Temperature setting range on remote controller: 16℃-30℃. Fan speed setting
range: auto, low speed, medium speed and high speed.
"+"
3
● After each pressing of "+" or "-" button, it can increase or decrease set temper-
ature 1℃. Hold "+" or "-" button, 2s later, set temperature on remote controller
will change quickly. After reaching to your required time, loosen the button.
Temperature indicator on indoor unit will also change accordingly. (Temperature
can’t be adjusted under auto mode)
● Under TIMER ON, TIMER OFF or Clock setting, you can press "+"or "-" button to
adjust time. (Refer to TIMER button for details)
4
Pressing this button can set fan speed circularly as: auto (AUTO), low( ),
medium( ), high( ).
Note:
● Under AUTO Speed,IDU fan motor will adjust the fan speed (high, medium or
● Fan speed under dry mode is low speed.
or "-" button
FAN button
Auto
low speed) according to ambient temperature.
5
● Press this button to start or stop up & down swing function.The remote controller
defaults to simple swing condition.
● Press + button and button at the same time at unit OFF to switch between
simple swing and static swing; blinks for 2 seconds.
● In static swing condition, pressing button, the swing angle of up & down louver
changes as below:
● If the unit is turned off during swing operation,the louver will stop at present
position.
button
no display
(horizontal louvers stops
at current position)
9
Introduction for buttons on remote controller
Note:
When selecting " " with remote controller, it’s auto swing. Horizontal louver of air
conditioner will swing up&down automatically at the maximum angle.
When selecting " 、 、 、
swing. Horizontal louver of air conditioner will stop at that position as shown by the
icon to swing.
、
6
● Press this button to start or stop left & right swing function. The remote controller
defaults to simple swing condition.
● Press + button and button at the same time at unit OFF to switch between
simple swing and static swing; blinks for 2 seconds.
● In static swing condition, pressing button, the swing angle of left & right louver
changes as below:
● If the unit is turned off during swing operation,the louver will stop at present
position.
● When selecting
air conditioner will swing left&right automatically at the maximum angle.
● When selecting
position swing. Horizontal louver of air conditioner will stop at that position as
shown by the icon to swing.
● When selecting
air conditioner will swing circularly according to the angle as shown by the icon.
button
(horizontal louvers stops
no display
at current position)
" "
with remote controller, it’s auto swing. Horizontal louver of
" 、 、 、 、 "
" "
(swing angle is displayed dynamically)
(swing angle is displayed dynamically)
, it’s the circulating swing. Horizontal louver of
Note: There is no this function for the units. If press this key, the main unit will
click, but it also runs under original status.
HEALTH SAVE button
7
HEALTH FUNCTION:
After pressing HEALTH button, remote controller will switch circularly as below:
"HEALTH"→"AIR"→"AIR HEALTH"→"no display"
●
When selecting "HEALTH" by remote controller, HEALTH function will be started up.
● When selecting "AIR" by remote controller, AIR function will be started up.
● When selecting "AIT HEALTH", AIR and HEALTH function will be started up.
● When there’s no display on remote controller, AIR and HEALTH function will be
turned off.
● AIR function is applicable for some models.
10
Introduction for buttons on remote controller
SAVE function:
Under cool mode, press SAVE button and the unit will operate under SAVE mode.
Dual-8nixie tube on remote controller displays "SE". Air conditioner will operate at
auto speed. Set temperature can’t be adjusted. Press SAVE button again to exit
SAVE mode. Air conditioner turn back to original set speed and set temperature.
● This function is applicable to partial of models.
X-FAN button
8
After pressing this button under cooling or dry mode, remote controller displays the
character of "X-FAN" and X-FAN function is started up. Press this button again to
cancel X-FAN function. The character of "X-FAN" will disappear.
Note:
●
After starting up X-FAN function, when turning off the unit, indoor fan will continue
to operate for a while at low speed to dry the residual water inside the indoor unit.
● When the unit operates under X-FAN mode, press "X-FAN" button can turn off
X-FAN function. Indoor fan stops operation immediately.
TEMP button
9
Press this button can see indoor set temperature, indoor ambient temperature or
outdoor ambient temperature on indoor unit’s display. Temperature is set circularly
by remote controller as below:
no display
● When selecting " " by remote controller or no display, temperature indicator on
indoor unit displays set temperature.
● When selecting " " by remote controller, temperature indicator on indoor unit
displays indoor ambient temperature.
● When selecting " " by remote controller, temperature indicator on indoor unit
displays outdoor ambient temperature.
Note:
● Outdoor ambient temperature display may can’t be selected for some models.
When indoor unit receives " " signal, it displays indoor set temperature.
● Only for the model whose indoor unit has dual-8 display.
TIMER button
10
At ON status, press this button once can set TIMER OFF. The character of HOUR
●
TIMER
ON. After each pressing of "+" or "-" button, time will increase or decrease half an
11
Introduction for buttons on remote controller
hour. When holding "+" or "-" button, 2s later, the time will change quickly until to
Cancel TIMER OFF: Press "TIMER" button again under TIMER OFF status.
● At OFF status, press this button once can set TIMER ON. Please refer to TIMER
off for detailed operation.
Cancel TIMER ON: Press "TIMER" button again under TIMER ON status.
Note:
● Time setting range: 0.5-24 hours.
● Time interval between two operations can’t exceed 5s. Otherwise, remote
controller will exit the setting status automatically.
TURBO button
11
When pressing this button under cooling or heating mode, air conditioner will enter
into quick cooling or quick heating mode. The character of "TURBO" is displayed
on remote controller. Press this button again to exit turbo function and the character
of "TURBO" will be disappeared on remote controller.
SLEEP button
12
Press this button under cooling, heating mode can start up sleep function.
" " icon will be displayed on remote controller. Press this button again to cancel
sleep function. " "icon on remote controller will be displayed.
LIGHT button
13
Press this button can turn off the light for indoor unit’s display. " " icon on remote
controller will disappear. Press this button again to turn on the light for indoor unit’s
display. " " icon on remote controller will be displayed.
Function introduction for combination buttons
Child lock function
Press "+" and "-" buttons simultaneously can turn on or turn off child lock function.
When child lock function is started up, " " icon will be displayed on remote
controller won’t send signal.
Switchover function for temperature display
After turning off the unit by remote controller, press "-" button and "MODE" button
simultaneously to switch between ℃and °F .
12
Operation guide
ON/OFF
1. After putting through the power, press " " button on remote controller to
turn on the air conditioner.
2. Press " " button to select your required mode: AUTO, COOL, DRY, FAN,
MODE
HEAT.
3. Press "+" or "-" button to set your required temperature. (Temperature can’t be
adjusted under auto mode).
4. Press " " button to set your required fan speed: auto, low, medium and
FAN
high speed.
5. Press " " button to select fan blowing angle.
Replacement of batteries in remote controller
1. Press the back side of remote controller marked
the cover of battery box along the arrow direction.
signal sender battery
reinstall
2. Replace two 7# (AAA 1.5V) dry batteries, and
make sure the position of "+" polar and "-" polar
remove
are correct.
3. Reinstall the cover of battery box.
Cover of battery box
NOTICE
● During operation, point the remote control signal sender at the receiving
window on indoor unit.
● The distance between signal sender and receiving window should be no
more than 8m, and there should be no obstacles between them.
or wireless telephone; remote controller should be close to indoor unit during
operation.
● Replace new batteries of the same model when replacement is required.
● When you don’t use remote controller for a long time, please take out the
batteries.
● If the display on remote controller is fuzzy or there’s no display, please
replace batteries.
13
Emergency operation
If remote controller is lost or damaged, please use auxiliary button to turn
on or turn off the air conditioner. The operation in details are as below:
conditioner. When the air conditioner is turned on, it will operate under
auto mode.
panel
aux. button
WARNING:Use insulated object
to press the auto button
Clean and maintenance
WARNING
■ Turn off the air conditioner and disconnect the power before cleaning the air
conditioner to avoid electric shock.
■ Do not wash the air conditioner with water to avoid electric shock.
■ Do not use volatile liquid to clean the air conditioner.
Clean surface of indoor unit
When the surface of indoor unit is dirty, it is recommended to use a soft dry cloth
or wet cloth to wipe it.
NOTICE:
● Do not remove the panel when cleaning it.
14
Clean and maintenance
Open panel
1
Pull out the panel to a certain ● Use dust catcher or water to
2
3
the water (below 45℃) to clean
it, and then put it in a shady
and cool place to dry.
4
panel cover tightly.
WARNING
operation environment, clean frequency can be increased.
15
Clean and Maintenance
NOTICE: Checking before use-season
1. Check whether air inlets and air outlets are blocked.
2. Check whether air switch, plug and socket are in good condition.
4. Check whether mounting bracket for outdoor unit is damaged or corroded.
If yes, please contact dealer.
5. Check whether drainage pipe is damaged.
NOTICE: Checking after use-season
1. Disconnect power supply.
3. Check whether mounting bracket for outdoor unit is damaged or corroded.
If yes, please contact dealer.
Notice for recovery
1. Many packing materials are recyclable materials.
Please dispose them in appropriate recycling unit.
2. If you want to dispose the air conditioner, please contact local dealer or
consultant service center for the correct disposal method.
16
Malfunction analysis
General phenomenon analysis
Please check below items before asking for maintenance. If the malfunction still
can’t be eliminated, please contact local dealer or qualied professionals.
Phenomenon Check items Solution
Indoor unit
can’t receive
remote
controller’s
signal or
remote
controller
has no
action.
No air
emitted
from
indoor
unit
● Whether it's interfered severely
(such as static electricity,stable
voltage)?
● Whether remote controller is
within the signal receiving
range?
● Whether there are obstacles?
● Whether remote controller is
pointing at the receiving
window?
● Is sensitivity of remote contro ller low; fuzzy display and no
display?
● No display when operating
remote controller?
● Fluorescent lamp in room?
● Air inlet or air outlet of indoor
unit is blocked?
● Under heating mode, indoor
temperature is reached to set
temperature?
● Heating mode is turned on just
now?
● Pull out the plug. Reinsert
the plug after about 3min, and
then turn on the unit again.
● Signal receiving range is 8m.
● Remove obstacles.
●
Select proper angle and point
the remote controller at the re ceiving window on indoor unit.
● Check the batteries. If the
power of batteries is too low,
please replace them.
● Check whether remote cont-
roller appears to be damaged.
If yes, replace it.
● Take the remote controller
close to indoor unit.
● Turn off the uoresent lamp
and then try it again.
● Eliminate obstacles.
● After reaching to set temper-
ature, indoor unit will stop bl owing out air.
● In order to prevent blowing
out cold air, indoor unit will be
started after delaying for sev eral minutes, which is a nor mal phenomenon.
17
Malfunction analysis
Phenomenon
Air conditioner can’t
operate
Mist is emitted from
indoor unit’s
air outlet
Set temperature can’t
be adjusted
Check items Solution
● Power failure?
● Is plug loose?
● Air switch trips off or fuse is
burnt out?
● Wiring has malfunction?
● Unit has restarted immediately
after stopping operation?
● Whether the function setting
for remote controller is
correct?
● Indoor temperature and hum-
idity is high?
● Unit is operating under auto
mode?
● Your required temperature
exceeds the set temperature
range?
● Wait until power recovery.
● Reinsert the plug.
● Ask professional to replace
air switch or fuse.
● Ask professional to replace it.
● Wait for 3min, and then turn
on the unit again.
● Reset the function.
● Because indoor air is cooled
rapidly. After a while, indoor
temperature and humidity will
be decrease and mist will
disappear.
● Temperature can’t be adju-
sted under auto mode.
Please switch the operation
mode if you need to adjust
temperature.
● Set temperature range:
16℃~30℃.
Cooling
(heating)
effect is
not good.
● Voltage is too low?
● Filter is dirty? ● Clean the lter.
● Set temperature is in proper
range?
● Door and window are open? ● Close door and window.
● Wait until the voltage
resumes normal.
● Adjust temperature to proper
range.
18
Malfunction analysis
Phenomenon Check items Solution
Odours are
emitted
Air conditioner
operates normally suddenly
Outdoor
unit has
vapor
“Wa t er
owing”
noise
Cracking
noise
● Whether there’s odour source,
such as furniture and cigarette,
etc.
● Whether there’s interference,
such as thunder, wireless
devices, etc.
● Heating mode is turned on?
● Air conditioner is turned on or
turned off just now?
● Air conditioner is turned on or
turned off just now?
● Eliminate the odour source.
● Clean the lter.
● Disconnect power, put back
power, and then turn on the
unit again.
● During defrosting under he-
ating mode, it may generate
vapor, which is a normal
phenomenon.
● The noise is the sound of
refrigerant owing inside
the unit, which is a normal
phenomenon.
● This is the sound of friction
caused by expansion and/or
contraction of panel or other
parts due to the change of
temperature.
19
Malfunction analysis
Error Code
● When air conditioner status is abnormal, temperature indictor on indoor unit will
blink to display corresponding error code. Please refer to below list for identific-
ation of error code.
Error code
Indoor
display
Error code
H1
E5
H4
U8
H6
C5
F1
F2
Note: If there're other error codes, please contact qualified professionals for
service.
Means defrosting status. It’s the normal phenomenon.
It can be eliminated after restarting the unit. If not,please
contact qualified professionals for service.
It can be eliminated after restarting the unit. If not,please
contact qualified professionals for service.
It can be eliminated after restarting the unit. If not,please
contact qualified professionals for service.
It can be eliminated after restarting the unit. If not, please
contact qualified professionals for service.
Please contact qualified professionals for service.
Please contact qualified professionals for service.
Please contact qualified professionals for service.
Above indicator diagram is only
for reference. Please refer to
actual product for the actual
indicator and position.
Troubleshooting
WARNING
■ When below phenomenon occurs, please turn off air conditioner and disconnect power immediately, and then contact the dealer or qualified professionals
for service.
● Power cord is overheating or damaged.
● There’s abnormal sound during operation.
● Circuit break trips off frequently.
● Air conditioner gives off burning smell.
● Indoor unit is leaking.
Do not repair or refit the air conditioner by yourself.
■ If the air conditioner operates under abnormal conditions, it may cause
malfunction, electric shock or fire hazard.
20
Installation dimension diagram
At least 15cm
Space to the ceiling
At least 15cm
Space to the wall
At least 300cm
Space to the wall
At least 15cm
Space to the obstruction
At least 30cm
Space to the wall
At least 200cm
Space to the obstruction
At least 250cm
Space to the oor
Space to the
obstruction
Space to the obstruction
At least 50cm
At least
30cm
Drainage pipe
At least 50cm
Space to the
obstruction
21
Tools for installation
1 Level meter 2 Screw driver 3 Impact drill
4 Drill head 5 Pipe expander 6 Torque wrench
7 Open-end wrench 8 Pipe cutter
9 Leakage detector
10 Vacuum pump 11 Pressure meter
13 Inner hexagon spanner 14 Measuring tape
Note:
● Please contact the local agent for installation.
● Don't use unqualied power cord.
12 Universal meter
Selection of installation location
Basic requirement
Installing the unit in the following places maycause malfunction. If it is unavoidable, please consult the local
dealer:
1.The place with strong heat sources,
vapors, ammable or explosive gas
or volatile objects spread in the air.
2.The place with high-frequency
devices (such as welding machine,
medical equipment).
3.The place near coast area.
4.
The place with oil or fumes in the air.
5.The place with sulfureted gas.
6.Other places with special circums tances.
7.Do not use the unit in the immediate
surroundings of a laundry a bath a
shower or a swimming pool.
Outdoor unit
1. Select a location where the noise and outow air emitted by the outdoor unit
will not affect neighborhood.
2. The location should be well ventilated and dry, in which the outdoor unit
won't be exposed directly to sunlight or strong wind.
3. The location should be able to withstand the weight of outdoor unit.
4. Make sure that the installation follows the requirement of installation
dimension diagram.
5. Select a location which is out of reach for children and far away from animals
or plants.If it is unavoidable, please add the fence for safety purpose.
,
Indoor unit
1. There should be no obstruction near air
inlet and air outlet.
2. Select a location where the condensat ion water can be dispersed easily and
won't affect other people.
3. Select a location which is convenient to
connect the outdoor unit and near the
power socket.
4. Select a location which is out of reach
for children.
5.
The location should be able to withstand
the weight of indoor unit and won't incr-
ease noise and vibration.
6.
The appliance must be installed 2.5m
above oor.
7. Don't install the indoor unit right above
the electric appliance.
8. Please try your best to keep way from
uorescent lamp.
22
Requirements for electric connection
Safety precaution
1. Must follow the electric safety regulations when installing the unit.
air switch.
3. Make sure the power supply matches with the requirement of air conditioner.
Unstable power supply or incorrect wiring or malfunction. Please install proper
power supply cables before using the air conditioner.
4. Properly connect the live wire, neutral wire and grounding wire of power socket.
5. Be sure to cut off the power supply before proceeding any work related to
electricity and safety.
7. If the supply cord is damaged, it must be replaced by the manufacturer, its
8. The temperature of refrigerant circuit will be high, please keep the interconnec tion cable away from the copper tube.
9. The appliance shall be installed in accordance with national wiring regulations.
Grounding requirement
grounding with specialized grounding device by a professional. Please make
sure it is always grounded effectively, otherwise it may cause electric shock.
2. The yellow-green wire in air conditioner is grounding wire, which can't be used
for other purposes.
3. The grounding resistance should comply with national electric safety regulations.
4. The appliance must be positioned so that the plug is accessible.
5. An all-pole disconnection switch having a contact separation of at least 3mm in
6. Including an air switch with suitable capacity, please note the following table. Air
switch should be included magnet buckle and heating buckle function, it can
protect the circuit-short and overload. (Caution: please do not use the fuse only
for protect the circuit)
Air-conditioner
09、12K
18、24K
Air switch capacity
16A
25A
23
Installation of indoor unit
Step one: choosing installation location
rm it with the client.
Step two: install wall-mounting frame
1. Hang the wall-mounting frame on the wall; adjust it in horizontal position with the
plastic expansion particles in the holes.
3. Fix the wall-mounting frame on the wall with tapping screws (ST4.2X25TA) and
.
Step three: open piping hole
1. Choose the position of piping hole according to the direction of outlet pipe. The
position of piping hole should be a little lower than the wall-mounted frame,
shown as below.
09、12K：
Wall
Mark in the middle of it
Space
to the
wall
above
150mm
Left
Φ55
Rear piping hole
24K：
Wall
Mark in the middle of it
Space
to the
wall
above
150mm
Left
Φ70
Rear piping hole
Level meter
Level meter
Wall
Space
to the
wall
above
150mm
Right
Φ55
Rear piping hole
Wall
Space
to the
wall
above
150mm
Right
Φ70
Rear piping hole
18K：
Wall
Space
to the
wall
above
150mm
Left
Φ55
Rear piping hole
Mark in the middle of it
Level meter
Wall
Space
to the
wall
above
150mm
Right
Φ55
Rear piping hole
2. Open a piping hole with the diameter of Φ55/70 on the selected outlet pipe
position. In order to drain smoothly, slant the piping hole on the wall slightly
downward to the outdoor side with the gradient of 5-10°.
24
left right
Installation of indoor unit
Note:
● Pay attention to dust prevention and
take relevant safety measures when
opening the hole.
● The plastic expansion particles are
not provided and should be bought
locally.
Step four: outlet pipe
1. The pipe can be led out in the
direction of right, rear right, left or
rear left.
left
rear right
right
rear left
Indoor
5-10
2. When select leading out the pipe
from left or right, please cut off the
corresponding hole on the bottom
case.
outdoor
Φ55/
Φ70
cut off
the hole
1. Aim the pipe joint at the corresponding
bellmouth.
union nutpipe joint
2. Pretightening the union nut with hand.
3. Adjust the torque force by referring to the following sheet. Place the open-end
wrench on the pipe joint and place the torque wrench on the union nut. Tighten
the union nut with torque wrench.
pipe
25
Installation of indoor unit
torque wrench
indoor pipe
open-end
wrench
union nut
pipe
Hex nut diameter Tightening torque (N.m)
Φ 9.52
4. Wrap the indoor pipe and joint of con nection pipe with insulating pipe, and
then wrap it with tape.
Step six: install drain hose
1. Connect the drain hose to the outlet pipe of
indoor unit.
drain hose
2. Bind the joint with tape.
Note:
● Add insulating pipe in the indoor
drain hose in order to prevent
condensation.
● The plastic expansion particles are
not provided.
outlet pipe
tape
Φ 6
Φ 12
Φ 16
Φ 19
15~20
30~40
45~55
60~65
70~75
insulating pipe
outlet
pipe
drain hose
insulating pipe
drain hose
Step seven: connect wire of indoor unit
1. Open the panel, remove the screw
on the wiring cover and then take
down the cover.
26
panel
screw
wiring cover
Installation of indoor unit
2. Make the power connection wire go
through the cable-cross hole at the back
cable-cross
hole
of indoor unit and then pull it out from
the front side.
power connection
wire
3. Remove the wire clip; connect the power connection wire to the wiring terminal
with wire clip.
18、 24K：09、 12K：
N(1) 2 3
blue black brown
Outdoor unit connection
yellowgreen
N(1) 2 3
blue black brown
Outdoor unit connection
yellowgreen
4. Put wiring cover back and then tighten the screw.
5. Close the panel.
Note:
● All wires of indoor unit and outdoor unit should be connected by a professional.
for a new one. Avoid extending the wire by yourself.
installation.
● For the air conditioner without plug, an circuit break must be installed in the line.
The circuit break should be all-pole parting and the contact parting distance
should be more than 3mm.
27
Installation of indoor unit
drain hose
band
connection pipe
indoor power cord
upper hook
lower hook of
wall-mounting frame
Step eight: bind up pipe
1. Bind up the connection pipe, power
cord and drain hose with the band.
indoor and
indoor unit
outdoor power cord
gas
pipe
band
2. Reserve a certain length of drain
hose and power cord for installation
when binding them. When binding to
a certain degree, separate the indoor
power and then separate the drain
hose.
liquid pipe
drain hose
3. Bind them evenly.
4. The liquid pipe and gas pipe should
be bound separately at the end.
Note:
● The power cord and control wire
can't be crossed or winding.
● The drain hose should be bound
at the bottom.
Step nine: hang the indoor unit
1. Put the bound pipes in the wall pipe and then make them pass through the wall
hole.
2. Hang the indoor unit on the wall-mounting frame.
3. Stuff the gap between pipes and wall hole with sealing gum.
4. Fix the wall pipe.
5. Check if the indoor unit is installed firmly and closed to the wall.
indoor
wall pipe
outdoor
sealing gum
Note:
● Do not bend the drain hose too excessively in order to prevent blocking.
28
Installation of outdoor unit
Step one: x the support of outdoor unit
(select it according to the actual installation situation)
1. Select installation location according to the house structure.
2. Fix the support of outdoor unit on the selected location with expansion screws.
Note:
● Take sufcient protective measures when
installing the outdoor unit.
●
Make sure the support can withstand at least
four times of the unit weight.
● The outdoor unit should be installed at least
3cm above the oor in order to install drain
joint.
● For the unit with cooling capacity of 2300W
~5000W, 6 expansion screws are needed;
for the unit with cooling capacity of 6000W
~8000W, 8 expansion screws are needed;
for the unit with cooling capacity of 10000W
~16000W, 10 expansion screws are needed.
at least 3cm above the floor
Step two: install drain joint
(Only for cooling and heating
unit)
1. Connect the outdoor drain joint into
the hole on the chassis, as shown in
the picture below.
2. Connect the drain hose into the drain
vent.
drain vent
Drain hose
chassis
outdoor drain joint
Step three: x outdoor unit
1. Place the outdoor unit on the
support.
2. Fix the foot holes of outdoor unit
with bolts.
foot holes
foot holes
29
Installation of outdoor unit
Step four: connect indoor and outdoor pipes
1. Remove the screw on the right han dle of outdoor unit and then remove
the handle.
screw
handle
2. Remove the screw cap of valve and
aim the pipe joint at the bellmouth of
pipe.
liquid pipe
liquid
valve
gas pipe
gas valve
3. Pretightening the union nut with
hand.
pipe joint
union nut
4. Tighten the union nut with torque
wrench by referring to the sheet
below.
Hex nut diameter
Φ 6
Φ 9.52
Φ 12
Φ 16
Φ 19
Tightening torque
(N.m)
15~20
30~40
45~55
60~65
70~75
1. Remove the wire clip; connect the power connection wire and signal control
wire (only for cooling and heating unit) to the wiring terminal according to the
09、 12K：
N(1) 2 3
blue black brown
handle
Indoor unit connection Indoor unit connection Indoor unit connection POWER
Note: the wiring board is for reference only,please refer to the actual one.
yellowgreen
18、 24K
N(1) 2 3
blue black brown
：
24K heat pump type：
(for some model)
yellow-
yellow-
green
green
N(1) 2 3 L N
blue blueblack brown
brown
L N
yellowgreen
30
Installation of outdoor unit
the drain hose
can't raise
upwards.
The water outlet
can't be placed
in water
2. Fix the power connection wire and signal control wire with wire clip (only for
cooling and heating unit).
Note:
● After tighten the screw, pull the power cord slightly to check if it is rm.
● Never cut the power connection wire to prolong or shorten the distance.
Step six: neaten the pipes
1. The pipes should be placed along the wall,
bent reasonably and hidden possibly. Min.
semidiameter of bending the pipe is 10cm.
2. If the outdoor unit is higher than the wall
hole, you must set a U-shaped curve in the
pipe before pipe goes into the room, in
order to prevent rain from getting into the
room.
Note:
● The through-wal height of drain hose
shouldn't be higher than the outlet
pipe hole of indoor unit.
● Slant the drain hose slightly dow nwards. The drain hose can't be
curved, raised and uctuant, etc.
U-shaped curve
drain hose
wall
● The water outlet can't be placed
in water in order to drain smoothly.
The drain hose can't be fluctuant
The drain hose
can't be fluctuant
31
The water
outlet can't be
fluctuant
Vacuum pumping
Use vacuum pump
1. Remove the valve caps on
the liquid valve and gas
valve and the nut of refri gerant charging vent.
2. Connect the charging hose
of piezometer to the refri gerant charging vent of gas
valve and then connect the
other charging hose to the
vacuum pump.
3. Open the piezometer com pletely and operate for
10-15min to check if the
pressure of piezometer re mains in -0.1MPa.
4. Close the vacuum pump
and maintain this status for
1-2min to check if the pres sure of piezometer remains
in -0.1MPa. If the pressure decreases, there may be leakage.
5. Remove the piezometer, open the valve core of liquid valve and gas valve
completely with inner hexagon spanner.
6. Tighten the screw caps of valves and refrigerant charging vent.
7. Reinstall the handle.
liquid valve
gas valve
refrigerant charging
vent
nut of refrigerant
charging vent
piezometer
valve cap
vacuum pump
inner hexagon
spanner
close
open
Lo Hi
Leakage detection
1. With leakage detector:
Check if there is leakage with leakage detector.
2. With soap water:
If leakage detector is not available, please use soap water for leakage detection.
Apply soap water at the suspected position and keep the soap water for more
than 3min. If there are air bubbles coming out of this position, there's a leakage.
32
Check after installation
Items to be checked Possible malfunction
The unit may drop, shake or emit noise.
Have you done the refrigerant leakage
test?
Is water drained well?
(heating) capacity.
It may cause condensation and water
dripping.
It may cause condensation and water
dripping.
Is the voltage of power supplyaccording to the voltage marked on the
nameplate?
Is electric wiring and pipeline installed
correctly?
Is the unit grounded securely? It may cause electric leakage.
Does the power cord follow the speci-
Is there any obstruction in the air inlet
and outlet?
The dust and sundries caused during
installation are removed?
The gas valve and liquid valve of
connection pipe are open completely?
It may cause malfunction or damaging
the parts.
It may cause malfunction or damaging
the parts.
It may cause malfunction or damaging
the parts.
(heating) capacity.
It may cause malfunction or damaging
the parts.
(heating) capacity.
Test operation
1. Preparation of test operation
● The client approves the air conditioner.
● Specify the important notes for air conditioner to the client.
2. Method of test operation
● Put through the power, press ON/OFF button on the remote controller to start
operation.
● Press MODE button to select AUTO, COOL, DRY, FAN and HEAT to check
whether the operation is normal or not.
● If the ambient temperature is lower than 16℃, the air conditioner can’t
startcooling.
33
Conguration of connection pipe
1. Standard length of connection pipe
● 5m, 7.5m, 8m.
2.Min. length of connection pipe is 3m.
3.Max. length of connection pipe and max. high difference.
Cooling
capacity
5000Btu/h
(1465W)
7000Btu/h
(2051W)
9000Btu/h
(2637W)
12000Btu/h
(3516W)
18000Btu/h
(5274W)
4. The additional refrigerant oil and refrigerant charging required after prolonging
connection pipe
● After the length of connection pipe is prolonged for 10m at the basis of
standard length, you should add 5ml of refrigerant oil for each additional 5m
of connection pipe.
● The calculation method of additional refrigerant charging amount (on the basis
of liquid pipe):
Additional refrigerant charging amount = prolonged length of liquid pipe ×
additional refrigerant charging amount per meter
● When the length of connection pipe is above 5m, add refrigerant according to
the prolonged length of liquid pipe. The additional refrigerant charging amount
per meter is different according to the diameter of liquid pipe. See the
following sheet.
Max length
of connection pipe
15 255 10
15 305 10
15 305 20
20 3010 20
25 3010 20
Max height
difference
Cooling
capacity
24000Btu/h
(7032W)
28000Btu/h
(8204W)
36000Btu/h
(10548W)
42000Btu/h
(12306W)
48000Btu/h
(14064W)
Max length
of connection pipe
Max height
difference
34
Conguration of connection pipe
Additional refrigerant charging amount for R22, R407C, R410A and R134a
Diameter of connection pipe
Liquid pipe(mm) Gas pipe(mm)
Φ6
Φ6 or Φ9.52
Φ12
Φ16
Φ19
Φ22.2
Φ9.52 or Φ12
Φ16 or Φ19
Φ19 or Φ22.2
Φ25.4 or Φ31.8
_
_
Outdoor unit throttle
Cooling only(g/m) Cooling and heating(g/m)
15
15
30
60
250 250
350
20
50
120
120
350
35
Pipe expanding method
pipe
pipe
smooth surface
Note:
Improper pipe expanding is the main cause of refrigerant leakage. Please expand
the pipe according to the following steps:
A: Cut the pipe
● Conrm the pipe length according to
the distance of indoor unit and
outdoor unit.
● Cut the required pipe with pipe cutter.
pipe cutter
E: Expand the port
● Expand the port with expander.
hard
expander
mold
pipe
leaning uneven burr
B: Remove the burrs
● Remove the burrs with shaper and
prevent the burrs from getting into
the pipe.
shaper
downwards
C: Put on suitable insulating pipe
D: Put on the union nut
● Remove the union nut on the indoor
connection pipe and outdoor valve;
install the union nut on the pipe.
union pipe
Note:
● "A" is different according to the
diameter, please refer to the sheet
below:
Outer diameter
(mm)
Φ6 - 6.35(1/4")
Φ9.52(3/8")
Φ12-12.7(1/2")
Φ15.8-16(5/8")
A(mm)
Max Min
1.3 0.7
1.6 1.0
1.8 1.0
2.4 2.2
F: Inspection
● Check the quality of expanding port.
If there is any blemish, expand the
port again according to the steps
above.
improper expanding
pipe
the length is equal
36
leaning damaged
surface
crack uneven
thickness
Designed by Cooper&Hunter International Corporation, Oregon, USA
www.cooperandhunter.com
E-mail: info@cooperandhunter.com
66162848
Loading...
