Class H Fuseblocks H600 Series
600 Volts
Form No. H600 Series
Page 1 of 3
Data Sheet: 1113
Bussmann
®
Catalog Symbol: H600 Series
Ampere Rating: ⁄Ω¡º to 600A
Voltage Rating: 600V
Agency Information:
UL Listed, UL 512, Guide IZLT, File E14853
CSA Certified, C22.2 No. 39, Class 6225-01, File 47235
Withstand Rating: 10,000A RMS Sym.
For use with Class K5 & H Fuses (Bussmann NOS and RES)
UL Flammability: 94VO
Materials: Thermoplastic
Class H Fuseblocks (600V) Catalog Data (for NOS and RES Fuses)
Terminal Type (Suffix No.) Dimensions (Inches) – See Next Page For Figures
Screw Box Lug w/
Basic J Dia.
Catalog Fig. ≈ Wire
Number No. A B C D E F G H C’ Bore K Range
⁄Ω¡º 1 H60030-1 S SR P PR C CR COR CO — 1 1.54 C, CR #2-14 CU, #2-12 AL
to 2 H60030-2 S SR P PR C CR COR CO — 2 6.25 1.73 2.90 1.56 .25 0.62 3.13 1.56 0.28 ≈ 0.5 .26 CO, COR #6-14 CU ONLY
30 3 H60030-3 S SR P PR C CR COR CO — 3 4.25 P, PR, S, SR #10-18 CU ONLY
31 1 H60060-1 — — — — C CR COR CO — 4
C, CR #2-14 CU, #2-8 AL
to 2 H60060-2 — — — — C CR COR CO — 5 (See Figures)
CO, COR #4-14 CU ONLY
60 3 H60060-3 — — — — C CR COR CO — 6
61 1 H60100-1 — SR‡ — — — CR COR — — 7 2.22 COR 1/0-8 CU ONLY
to 2 H60100-2 — SR‡ — — — CR COR — — 8 9.5 2.38 4.03 2.63 0.67 0.88 4.25 1.81 0.28 ≈ 0.5 0.34 CR 1/0-8 CU/AL
100 3 H60100-3 — SR‡ — — — CR COR — — 9 5.84 SR #8w/ Ring Terminal
101
1 H60200-1 — — — — — CR — — — 10 9.63 3.09 3.0 3.31 0.5 2.0 3.0 0.75 — 0.31
CR 250kcmil-6 CU/AL
to
200
3 H60200-3 — — — — — CR — — — 11 (See Figures)
201
1 H60400-1 — — — — — CR‡ COR‡— — 10 12.0 4.0 3.0 4.5 0.63 1.75 3.0 1.0 — 0.56 COR 500kcmil-4/0 CU ONLY
to
400
3 H60400-3 — — — — — CR†— — — 12 (See Figures)
CR 500kcmil-4 CU/AL
401
1 H60600-1 — — — — — CR — — — 10 14.0 4.97 3.0 5.5 1.125 1.75 4.0 1.0 — 0.56
CR (2) 500kcmil-4/0 CU/AL
to
600
3 H60600-3 — — — — — CR† — — — 13 (See Figures)
†No UL, No CSA Certification.
‡UL Recognized, CSA Certification
Poles
Amps
—
Clip with
Reinforced Spring
Pressure Plate
Pressure Plate & Clip
with Reinforced Spring
—
Clip with
Reinforced Spring
Clip w/ Reinforced
Spring (Copper Only)
Copper Only
0.25∑ Quick Connect
CE logo denotes compliance with European Union Low Voltage Directive
(50-1000Vac, 75-1500Vdc). Refer to Data Sheet: 8002 or contact
Bussmann Application Engineering at 314-527-1270 for more information.
1-15-03
SB02515
