Cooper and Hunter CH18MSPH230VO User Manual

SOPHIA
MULTI-ZONE
INVERTER
SPLIT AIR CONDITIONER WITH HEAT PUMP
USER'S MANUAL
OUTDOOR UNIT
Models: CH-18MSPH-230VO CH-28MSPH-230VO CH-36MSPH-230VO CH-48MSPH-230VO
IMPORTANT NOTE:
Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
This manual only describes the usage of the outdoor unit. When using the indoor unit, refer to the user’s manual of the indoor unit.
Table of Contents
User's Manual
1
Safety Precautions
2
Unit Parts and Major Functions
3
Manual Operation and Maintenance
................................................................
..............................
..............
04
05
09
SAFETY
FIRST
4
Troubleshooting.................................
10
a. Common Problems .................................
b. Troubleshooting Tips ...............................
10 11
Page 3
Introduction
Failure to observe a warning may result in death. The appliance must be installed in accordance with national regulations.
.
Failure to observe a caution may result in injury or equipment damage.
General
Precautions
Safety
Safety Precautions
1
Thank you for purchasing this air conditioner. This manual will provide information on how to operate, maintain, and troubleshoot your air conditioner. Following the instructions will ensure the proper function and extended lifespan of your unit.
Please pay attention to the following signs:
WARNING
CAUTION
WARNING
Ask an authorized dealer to install this air
conditioner. Inappropriate installation may cause water leakage, electric shock, or fire.
The warranty will be voided if the unit is not
installed by professionals.
If an abnormal situation arises (such as a
burning smell), turn o the power supply and call your dealer for instructions to avoid electric shock, fire, or injury.
DO NOT
control get wet. This may cause electric shock or fire.
DO NOT
objects into the air inlet or outlet. This may cause injury, since the fan may be rotating at high speeds.
DO NOT
hair spray, lacquer, or paint near the unit. This may cause fire or combustion.
CAUTION
DO NOT touch the air outlet while the swing flap is in motion. Fingers may get caught or the unit may break down.
DO NOT inspect the unit by yourself. Ask an authorized dealer to perform the inspection.
To prevent product deterioration, do not use the air conditioner for preservation purposes (storage of food, plants, animals, works of art, etc.).
DO NOT touch the evaporator coils inside
the indoor unit. The evaporator coils are sharp and may cause injury.
let the indoor unit or the remote
insert fingers, rods, or other
use a flammable spray such as
DO NOT operate the air conditioner with wet hands. This may cause electric shock.
DO NOT place items that might be aected by moisture damage under the indoor unit. Condensation can occur at a relative humidity of 80%.
DO NOT
expose heat-producing appliances to cold air or place them under the indoor unit. This may cause incomplete combustion or deformation of the unit due to the heat.
After long periods of usage, check the
indoor unit to see if anything is damaged. If the indoor unit is damaged, it may fall and cause injury.
If the air conditioner is used together with
other heating devices, thoroughly ventilate the room to avoid oxygen deficiency.
DO NOT
climb onto or place objects on top
of the outdoor unit.
DO NOT
operate the air conditioner when using fumigant insecticides. The chemicals may become layered with the unit and endanger those who are hypersensitive to chemicals.
DO NOT
let children play with the air
conditioner.
The air conditioner can be used by children aged 8 years and older and people with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, if they have been instructed about how to properly and safely operate the system.
DO NOT
operate the air conditioner in a wet room (e.g. bathroom or laundry room). This can cause electrical shock and cause the product to deteriorate.
Page 4
Unit Parts and Major Functions
Unit Parts
Wall-mounted type
Duct/ceiling type
2
And Major
Unit Parts
Functions
and Major
Unit Parts
Functions
Fig. 2.1
Indoor unit
1. Panel frame
2. Rear air intake grille
3. Front panel
4. Air purifying lter & air lter (behind)
5. Horizontal louver
6. LCD display window
7. Vertical louver
8. Manual control button (behind)
9. Remote control holder
Outdoor unit
10. Drain hose, refrigerant connecting pipe
11. Connective cable
12. Stop valve
13. Fan hood
Fig. 2.2
Indoor unit
1. Air outlet
2. Air inlet
3. Air lter
4. Electric control cabinet
5. Wire control
Outdoor unit
6. Drain hose, refrigerant connecting pipe
7. Connective cable
8. Stop valve
9. Fan hood
Page 5
and Major
Unit Parts
Functions
Floor and standing type (console) Compact four-way cassette type
Fig. 2.3
Indoor unit
1. Airow louver (at air outlet)
2. Air inlet, (containing air lter)
3. Remote control
4. Installation part
5. Display panel
Outdoor unit
6. Drain hose, refrigerant connecting pipe
7. Connective cable
8. Stop valve
9. Fan hood
Page 6
Fig. 2.4
Indoor unit
1. Drain pump (drain water from indoor unit)
2. Drain hose
3. Air outlet
4. Air inlet
5. Air-in grill
6. Display panel
7. Remote control
Outdoor unit
8. Drain hose, refrigerant connecting pipe
9. Connective cable
10. Stop valve
11. Fan hood
NOTE: For multi-split type air conditioners, one outdoor unit can be matched to dierent types of indoor units. All of the pictures in this manual are for demonstration purposes only. Your air conditioner may be slightly dierent, if similar in shape. The following pages introduce several kinds of indoor units that can be matched with the outdoor units.
Operating Conditions
Use the system under the following temperatures for safe and eective operation. If the air conditioner is used under dierent conditions, it may malfunction or become less ecient.
COOL Mode HEAT mode DRY mode
Indoor Temperature
Outdoor Temperature
62-90° F (17-32° C)
32-122° F (0-50° C)
5-122° F (-15-50° C)
(low temperature cooling models)
32-86° F (0-30° C)
5-76° F (-15-24° C)
62-90° F (17-32° C)
32-122° F (0-50° C)
Features
Protection of the air conditioner
White mist emerging from the indoor unit
Compressor protection
The compressor cannot restart for 3 minutes after it stops. Anti-cold air (cooling and heating models only)
The unit is designed not to blow cold air on HEAT mode, when the set temperature has not been reached and the indoor heat exchanger is in one of the following three situations:
A white mist may be generated due to a large temperature dierence between air inlet and air outlet in COOL mode in places with high relative humidity.
A white mist may be generated due to moisture created in the defrosting process when the air conditioner restarts in HEAT mode after defrosting.
A) Heating has just started B) The unit is defrosting C) The unit is heated at a low temperature
The indoor or outdoor fan stops running when defrosting (cooling and heating models only).
Frost may be generated on the outdoor unit during a heat cycle when the outdoor temperature is low and the humidity is high, resulting in lower heating eciency in the air conditioner.
Under these conditions, the air conditioner will stop heating operations and start defrosting automatically.
The time to defrost may vary from 4 to 10 minutes, depending on the outdoor temperature and the amount of frost buildup on the outdoor unit. Auto-restart (some models) In case of power failure, the system will immediately stop. When power returns, the operation light on the indoor unit will flash. To restart the unit, press the ON/OFF button on the remote control. If the system has an auto-restart function, the unit will restart with the same
Noise coming from the air conditioner
You may hear a low hissing sound when the compressor is running or has just stopped running. This is the sound of the refrigerant owing or coming to a stop.
You may also hear a low "squeaking" sound when the compressor is running or has just stopped running. This is caused by heat expansion and cold contraction of the plastic parts in the unit when the temperature is changing.
A noise may be heard due to the louver restoring itself to its original position when power is rst turned on.
Dust blowing out from the indoor unit.
This happens when the air conditioner has not been used for a long time or during its rst use.
Smell coming from the indoor unit.
The indoor unit gives o smells drawn from building materials, furniture, or smoke.
settings.
and Major
Unit Parts
Functions
Page 7
and Major
Unit Parts
Functions
The air conditioner turns to FAN ONLY mode from COOL or HEAT (for cooling and heating models only) mode.
When the indoor temperature reaches the set temperature, the compressor will stop automatically and the air conditioner will turn to FAN ONLY mode. The compressor will start again when the indoor temperature rises in COOL mode or falls in HEAT mode to the set point.
Droplets of water may form on the surface of the indoor unit when cooling occurs in relatively high humidity (dened as higher than 80%). Adjust the horizontal louver to the maximum air outlet position and select HIGH fan speed.
Heating mode (for cooling and heating models only)
The air conditioner draws in heat from the outdoor unit and releases it via the indoor unit during heating. When the outdoor temperature falls, heat drawn in by the air conditioner decreases accordingly. At the same time, heat loading of the air conditioner increases due to the larger dierence between the indoor and outdoor temperatures. If a comfortable temperature cannot be achieved by the air conditioner alone, it is recommended that you use a supplementary heating device.
Lightning or a car wireless telephone operating nearby may cause the unit to malfunction. Disconnect the unit from its power source and then reconnect the unit with the power source. Push the ON/OFF button on the remote control to restart operation.
Energy-Saving Tips
DO NOT
When the unit is cooling, close curtains to avoid exposure to direct sunlight.
Keep doors and windows closed to keep cool or warm air in the room.
DO NOT
Set a timer and use the built-in SLEEP/ECONOMY mode if applicable.
If you don’t plan to use the unit for a long time, remove the batteries from the remote control.
Clean the air filter every two weeks.
Adjust louvers properly and avoid direct airflow.
set the unit to excessive temperature levels.
place objects near the unit's air inlet or outlet.
Page 8
Closing curtains during heating
helps keep the heat in.
Doors and windows should be kept
closed.
Manual Operation and Maintenance
3
Operation Mode Selection
When two or more indoor units are operating simultaneously, make sure the modes do not conict with each other. HEAT mode claims precedence over all other modes. If the unit initially operated in HEAT mode, the other units can operate in HEAT mode only. For example: If the unit initially operated in COOL (or FAN) mode, the other units can operate under any mode except HEAT. If one of the units selects HEAT mode, the other operating units will stop operation and diplay ”--” (for units with a display window) or the auto and operation indication light will ash rapidly, the defrost indication light will turn o, and the timer indication light will remain on (for units without a display window). Alternatively, the defrost and alarm indication light (if applicable) will light up, or the operation indication light will ash rapidly, and the timer indication light will turn o (for the oor and standing types).
Optimal Operation
To achieve optimal performance, please note the following:
Adjust the direction of the airow so that it does not blow directly on people.
Adjust the temperature to achieve the highest possible level of comfort. Do not adjust the unit to excessive temperature levels.
Close doors and windows in COOL mode or HEAT mode.
Use the TIMER ON button on the remote control to select a time for the air conditioner to start.
• Do not place any object near the air inlet or outlet,
as the eciency of the air conditioner may be reduced and it may stop running.
• Clean the air lter periodically. Otherwise,
cooling or heating performance may be reduced.
• Do not operate the unit with the horizontal
louver in the closed position.
Manual Operations
and Maintenance
Maintenance
If you plan to leave the unit idle for a long time, perform the following tasks:
1. Clean the indoor unit and the air lter.
2. Select FAN ONLY mode and let the indoor fan run for a time to dry the inside of the unit.
3. Disconnect the power supply and remove the battery from the remote control.
4. Check the components of the outdoor unit periodically. Contact a local dealer or a customer service center if the unit requires servicing.
NOTE: Before you clean the air conditioner, be sure to switch o the unit and disconnect the power supply plug.
Suggestion: For units that feature an electric heater, when the outside ambient temperature is below 32° F (0° C), it is strongly recommended that you keep the machine plugged in to guarantee smooth operation.
When the air conditioner is to be used again:
Use a dry cloth to wipe o the dust accumulated on the rear air intake grille to avoid the dispersion of the dust from the indoor unit.
Check that the wiring is not broken o or disconnected.
Check that the air lter is installed.
Check if the air outlet or inlet is blocked after
the air conditioner has not been used for a long time.
Page 9
Troubleshooting
CAUTION
If one of the following conditions occurs, switch o the power supply immediately and contact your dealer for further assistance.
The operation light continues to flash rapidly after the unit has been restarted
The remote control buttons do not work
The unit continually trips fuses or circuit breakers
A foreign object or water enters the air conditioner
Other abnormal situations
Troubleshooting
Common Problems
The following symptoms are not malfunctions and in most situations will not require repairs:
Problem Possible Causes
The unit has a 3-minute protection feature that prevents it from
The unit does not turn on when the ON/OFF button is pressed
The unit changes from COOL mode to FAN mode
The indoor unit emits a white mist
Both the indoor and outdoor units emit a white mist
The indoor unit makes noises
overloading. The unit cannot be restarted within 3 minutes of being turned o.
Cooling and heating models: If the operation light and PRE-DEF (Pre-heating/ defrost) indicators are lit up, the outdoor temperature is too cold and the unit’s anti-cold wind is activated to defrost the unit.
In cooling-only models: If the “fan only” indicator is lit up, the outdoor temperature is too cold and the unit’s anti-freeze protection is activated to defrost the unit.
The unit changes its setting to prevent frost from forming on the unit. Once the temperature increases, the unit will start operating again.
The set temperature has been reached, at which point the unit turns o the compressor. The unit will resume operating when the temperature fluctuates again.
In humid regions, a large temperature dierence between the room’s air and the conditioned air can cause a white mist.
When the unit restarts in HEAT mode after defrosting, a white mist may be emitted due to moisture generated from the defrosting process.
A squeaking sound is heard when the system is OFF or in COOL mode. The noise is also heard when the drain pump (optional) is in operation.
A squeaking sound may occur after the unit is run in HEAT mode due to expansion and contraction of the unit’s plastic parts.
4
Both the indoor and outdoor units make noises
The outdoor unit makes noises
Page 10
A low hissing sound may occur during operation. This is normal and is caused by refrigerant gas flowing through both the indoor and outdoor units.
A low hissing sound may be heard when the system starts, has just stopped running, or is defrosting. This noise is normal and is caused by the refrigerant gas stopping or changing direction.
The unit will make dierent sounds based on its current operating mode.
Problem Possible Causes
Dust is emitted from the indoor or outdoor unit
The unit may accumulate dust during extended periods of non-use. The dust will be emitted when the unit isturned on. To mitigate this, cover the unit during long periods of inactivity.
The unit may absorb odors from the environment (such as furniture, cooking,
The unit emits a bad odor
cigarettes, etc.) that will be emitted during operation. The unit’s lters may have become moldy and should be cleaned.
The fan of the outdoor unit
During operation, the fan speed is controlled to optimize product operation.
does not operate
Troubleshooting Tips
When troubles occur, please check the following points before contacting a repair company.
Problem Possible Causes Solution
Power failure Wait for the power to be restored.
The unit is not working
Poor cooling performance
The unit starts and stops frequently
The power switch is o Turn on the switch. The fuse is burned out Replace the fuse.
The remove control batteries are dead The unit’s 3-minute protection has
been activated The temperature setting may be higher
than the ambient room temperature The heat exchanger on the indoor
or outdoor unit is dirty
The air filter is dirty
The air inlet or outlet of either unit is blocked
Doors and windows are open
Excessive heat is generated by sunlight
Refrigerant is low due to a leak or long-term use
There’s too much or too little refrigerant in the system
There is air, incompressible gas, or a foreign material in the refrigeration
Replace the remote control batteries.
Wait 3 minutes after restarting the unit.
Lower the temperature setting.
Clean the aected heat exchanger.
Remove the filter and clean it according to the instructions. Turn the unit o, remove the obstruction, and turn it back on.
Make sure that all doors and windows are closed while the unit is operating.
Close windows and curtains during periods of high heat or bright sunshine.
Check for leaks, re-seal if necessary, and top o refrigerant.
Check for leaks and recharge the system with refrigerant.
Evacuate the system and recharge it with refrigerant.
system
Determine which circuit is blocked and replace
The system circuit is blocked
the malfunctioning piece of equipment. The compressor is broken Replace the compressor. The voltage is too high or too low Install a manostat to regulate the voltage.
Troubleshooting
Poor heating performance
The outdoor temperature is lower than 44.5° F (7° C)
Cold air is entering through doors and windows
Refrigerant is low due to a leak or long-term use
Check for leaks and recharge the system
with refrigerant.
Make sure that all doors and windows are
closed during use.
Check for leaks, re-seal if necessary and
top o refrigerant.
Page 11
SYSTEM OPERATION
COOLING OPERATION
How it works:
In cooling mode, your indoor unit will absorb heat from the room, then the outdoor unit will discharge the heat to the outdoors. The cooling capacity decreases as the outdoor temperature increases. This causes the unit to work harder and longer to hold the selected room temperature.
Indoor Coil Freeze Protection:
Frost may form on the indoor coil during cooling operation when the outdoor temperature is below 50° F (10° C). Prolonged operation may cause ice to form on the indoor coil and block airow. If the indoor unit microcomputer detects ice on the indoor coil, it will stop the compressor to defrost the coil and protect the unit.
HEATING OPERATION
How it works:
In heating mode, your outdoor unit will absorb heat from the outdoor ambient, then the indoor unit will discharge the heat to the room. The heating capacity will decrease as the outdoor temperature decreases.
During extremely cold outdoor temperatures, you may need an additional heating source to supplement the heating output.
Defrost Function:
In heating mode, frost may form on the outdoor coil during humid and low outdoor temperature conditions. Prolonging operation may cause ice to form on the outdoor coil and block airow. This will reduce the unit's, heating capacity.
If the microcomputer detects ice on the outdoor coil, it will switch automatically to defrost mode to melt the ice and clear the coil. During defrost mode, heating will be discontinued and the indoor unit will ash the defrost indicator. The compressor will continue to run, but the indoor and outdoor fans will stop. It is normal to see steam or vapor coming from the outdoor unit in defrost mode. Defrost mode will terminate 12 minutes after the initiation of the defrost cycle or when the outdoor coil temperature is 50° F (10° C) or greater.
ENERGY-SAVING TIPS
1. Relaxing room temperature at night is OK: During the nighttime
hours, you don’t require the same level of conscious cooling or heating. Try using Sleep Mode to gradually relax the room temperature and allow the unit to run less and save energy.
2. Curtains and shades: In the summer, you need to block the effects of the sun. Close window curtains and shades on the south and west sides of your home to help block solar heat. In winter, the sun is your friend. Open curtains and shades to allow solar heat into your room.
3. Close doors: If you don’t need to heat and cool your entire home,
confine the heating and cooling to one room by closing doors. Limit the space you’re heating and cooling to the specified capability of the unit.
4. Service the unit: You may need only some basic maintenance.
The outdoor unit will greatly benefit from a good hosing out, especially in treed areas where seeds and other debris can stick to coil fins and make the unit work up to 15% harder.
5. Rearrange the room: If furniture obstructs airflow, you could be heating
and cooling the back of a chair or the front of a sofa instead of actual living space. Use the swing louvers to help point the air in the right direction for the room. Remove or rearrange obstacles that block airflow.
6. Lighting: Turning lights off can help reduce heat. Each light bulb is
a tiny heater. Your air conditioner wastes energy overcoming the heat from your lights to reach and hold your desired room temperature.
7. Is anyone home? If possible, while you’re away, turn your unit to Auto
mode and make sure windows and drapes are closed. Although the room temperature will be uncomfortable for a few minutes when you come home, the unit will bring the room back to your desired temperature in no time.
8. Don’t forget the fan: The fan is much llike a car: the faster it runs, the
more energy it uses. Sometimes we need the car to go fast, but slow is good enough most of the time. Try saving money by using the comfortable and quiet low fan speed as much as possible.
www.cooperandhunter.us
MULTI ZONE INVERTER AIR CONDITIONING SYSTEM WITH HEAT PUMP
This warranty should be registered on our web-site www.cooperandhunter.us The warranty is only valid when installed by a Licensed HVAC Technician
FOR WARRANTY SERVICE OR REPAIR:
Contact your installing contractor. You may find the installer’s name on the equipment or in your Owner’s packet.
Complete product registration below and send back by e-mail at warranty@cooperandhunter.us
PRODUCT REGISTRATION:
Model No.: ______________________________________________________________________________________________
Serial No.: _______________________________________________________ Date of Installation: ______________________
Owner Name: ____________________________________________________________________________________________
LIMITED WARRANTY STATEMENT
Address of Installation:_____________________________________________________________________________________
____________
Installing Contractor: ______________________________________________________________________
Address: ________________________________________________________________________________________
Phone No. / E-mail: _______________________________________________________________________________
Place Of Purchase:
Date of Purchase:
C&H distributor (hereinafter “Company”) warrants this product against failure due to defect in materials or workmanship under normal use and maintenance as follows. All warranty periods begin on the date of original installation. If the date cannot be verified, the warranty period begins one hundred twenty (120) days from date of manufacture. Damage resulting from failure to use, install or maintain the product in a manner consistent with our/manufacturer’s recommendations shall render the warranty void. Cooper&Hunter, at its option, may request a report from a qualified technician prior to honoring a warranty claim. If a part fails due to defect during the applicable warranty period Company will provide a new or remanufactured part, at Company’s option, to replace the failed defective part at no charge for the part. This limited warranty is subject to all provisions, conditions, limitations and exclusions listed below.
A warranty period of Seven (7) years on compressor to the original registered end-user.
A warranty period of Five (5) years on all parts to the original registered end user.
A warranty period of One (1) year on the remote control provided with the original unit.
Limited warranty applies only to systems that are properly installed by a state certified or licensed HVAC contractor,
under applicable local and state law in accordance with all applicable building codes and permits and operation instructions and good trade practices.
Warranty applies only to products remaining in their original installation location.
Defective parts must be returned to the distributor through a registered servicing dealer for credit.
________________________________________________________________________________________
_______________________________________________________________________________
____
; C&H installation
LIMITATIONS OF WARRANTIES: ALL IMPLIED WARRANTIES AND/OR CONDITIONS (INCLUDING IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE OR PURPOSE) ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY. SOME STATES OR PROVINCES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR CONDITION LASTS, SO THE ABOVE MAY NOT APPLY TO YOU. THE EXPRESS WARRANTIES MADE IN THIS WARRANTY ARE EXCLUSIVE AND MAY NOT BE ALTERED, ENLARGED, OR CHANGED BY ANY DISTRIBUTOR, DEALER, OR OTHER PERSON, WHATSOEVER.
THIS WARRANTY DOES NOT COVER
1. Labor or other costs incurred for diagnosing, repairing, removing, installing, shipping, servicing, or handling of defective parts, replacement parts, or new units.
2. Product cleaning required prior to warranty service and repair.
3. Normal maintenance as outlined in the installation and servicing instructions or user's manual, including filter cleaning and/or replacement and lubrication.
4. Failure, damage, or repairs due to faulty installation, misapplication, abuse, improper servicing, unauthorized alteration, or imp
5. Failure to start due to voltage conditions, blown fuses, open circuit breakers, or damages due to the inadequacy or interruption of electrical service.
6. Failure or damage due to floods, winds, fires, lightning, accidents, corrosive environments (rust, etc.), or other conditions beyond the control of Company.
7. Failure or damage of coils or piping due to corrosion on installations within one (1) mile of a sea coast or a corrosive body.
8. Parts not supplied or designated by Compan
9. Products installed outside the continental USA and Canada.
10. Electricity or fuel costs, or increases in electricity or fuel costs for any reason whatsoever, including additional or unusual use of supplemental electric heat.
11. Any cost to replace, refill, or dispose of refrigerant, including the cost of refrigerant.
12. Shipping damage or damage as a result of transporting the unit.
13. Accessories such as condensate pumps, line sets, and so forth.
14. Any special, indirect, or consequential prop provinces do not allow the exclusion of incidental or consequential damages, so the above limitation may not apply to you.
roper operation.
:
y, or damages resulting from their use.
erty or commercial damage of any nature whatsoever. Some states or
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or province to province.
Loading...
