Cooper Lumark SF Falcon User Manual

OPTIONS (add as suffix)

9

F=Single Fuse (120, 277 or 347V. Specify Voltage)

10

FF=Double Fuse(208, 240 or 480V. Specify Voltage)

10

TR=Tamper-Resistant Entry Hardware
PE=Factory-Installed Internal Photocontrol (Specify Voltage)

BZ=Bronze
WH=White
BK=Black
GN=Green
AP=Grey
LL=Lamp Included (Must Specify Wattage with Fluorescent)

ACCESSORIES (order separately)
PE/MT=Field-Installed Photocontrol
TRSD-6/32=Tamper-Resistant Screwdriver
SF/TR=Tamper-Resistant Screw
NKS-XX=2/3" O.D. Slipfitter for Knuckle Mount

(Must Specify Color)

SF/V-XX=Top Visor (Specify Color. BZ Standard)
SF/VS=Vandal Shield
SF/WG=Wire Guard

RBC-XX=Round Outlet Box Cover (Specify Color)
FA5-XX=2" Slipfitter for Trunnion Fixture

(Specify Color. BZ Standard)

RAB-XX=Right Angle Pipe Bracket for Slipfitters

(Specify Color. BZ Standard)

SAB-XX=Steel Angle Bracket for Trunnion

(Specify Color. BZ Standard)

SPK=Landscape Post (Standard Color Dary Grey)

OPTIONS + ACCESSORIES

LAMP TYPE WATTAGE

Metal Halide

70, 100 & 175W

High Pressure Sodium 35, 70, 100 & 150W

Compact Fluorescent 26, 32, 42, 52, 57, 60, 64 & 70W

NOTES: 1 Medium-base only. 2 HPS only. 3 120V only. 4 MH with HPF CWA ballast only. 5 Products also available in non-US voltages and 50Hz for international markets. Consult factory for availability and ordering information.

6 Not available in Canada. 7 Canada only. 8 Compact fluorescent only. 9 Must be specified in order as shown and separated by a dash. 10 100W MH maximum. 11 Consult Lumark Stock Guide for available wattages.

ORDERING INFORMATION

SAMPLE NUMBER: MHSF-T-100-240V-FF-TR-PE-GN-LL

OPTIONS +
ACCESSORIES

9

(See Below)

LAMP TYPE
MH=Metal Halide
HP=High Pressure Sodium
PL=Compact Fluorescent

FIXTURE TYPE
SF=Falcon

MOUNTING
K=Knuckle
T=Trunnion

LAMP WATTAGE
HID

1

35=35W

2, 3

50=50W
70=70W
100=100W
150=150W

2

175=175W

4

Compact Fluorescent
26/32/42=26, 32, or 42W
26=26W
32=32W
42=42W
52=(2) 26W
57=57W
60=60W
64=(2) 32W
70=70W

VOLTAGE

5

120V
208V

6

240V

6

277V
347V
480V
DT=Dual-Tap (120/277V)
MT=Multi-Tap (120/ 208/240/277V)
TT=Triple-Tap (120/277/347V)

7

E=Electronic Ballast (50/60Hz)

8

POWER FACTOR
__=Normal
H=High Power Factor

SERIES
SF=Falcon

LAMP TYPE
HP=High

Pressure
Sodium

MH=Metal Halide

LAMP WATTAGE

11

35=35W

2, 3

50=50W
70=70W
10=100W
15=150W

2

17=175W

4

MOUNTING
K=Knuckle
T=Trunnion

WIRING OPTIONS
__=Standard
MT=Multi-Tap
TT=Triple-Tap

7

STOCK SAMPLE NUMBER (Lamp Included): MHSF10K-MT

NOTES [stock]: Options not available with stock products. Order Accessories as separate items for field installation.

Refer to standard ordering information to add options and accessories.

DOOR + LATCH

Tempered glass lens is impact and

thermal shock resistant. Easily

released die-cast aluminum

doorframe with stainless steel

toolless latch allows easy access for

re-lamping. Enclosure latch can be

secured with a single point stainless

steel screw, provided, or with

optional vandal resistant head.

HOUSING

Die-cast aluminum housing is

finished in weather and abrasion

resistant dark bronze polyester

powder paint. Optional colors are

available.

GASKET

Full-circumference silicone gasket

seals out external contaminants.

SOCKET

Pulse rated, 4KV, medium-base

porcelain lamp socket standard for

HID. Electronic compact 4-pin

fluorescent sockets standard for PL

lamp options.

REFLECTOR

Formed aluminum hammered

reflector optimizes beam efficiency

and control.

MOUNTING

Adjustable ANSI 1G rated stem

mounting arm fits 1/2" NPS outlet

box cover. (RBC round outlet box

cover not included, order

separately). Optional heavy-gauge

steel adjustable trunnion mounting

provides additional durability when

required.

LOW WATTAGE FLOODLIGHT

SF FALCON

35-175W MH/HPS

26-70W PL

FLOODLIGHTING

SHIPPING DATA

Approximate Net Weight:

17 lbs. (8 kgs.)

APPLICATION

The Falcon floodlight can be wall, pole, or
ground mounted making it ideal for all
commercial, industrial, and residential low
wattage floodlighting applications.

LUMARK

®

Visit our web site at www.cooperlighting.com

Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 770.486.4800 FAX [phone] ADH042543

TOP VISOR [SF/V-XX]

Easy to install top visor accessory
provides additional cutoff and glare
control.

VANDAL SHIELD [SF/VS]

Easy to install polycarbonate vandal
shield lens provides durable protection
against projected objects.

WIRE GUARD [SF/WG]

Easy to install wire guard features a
heavy-gauge welded construction with
corrosion resistant polyester powder
coat finish. Protects glass from
projected objects.

TAMPER-RESISTANT SCREW

[SF/TR]

Easy to install stainless steel tamper
resistant screw secures toolless latch
and discourages entry into the unit
from vandals.

PERFORMANCE FLEXIBILITY

Built strong for tough, low mount environments

ACCESSORIES [ORDER SEPARATELY]

™

10 11/16"
[272mm]

10 1/2" [267mm] 7 1/2" [189mm]

HIGH OUTPUT + SMALL PACKAGE

Powerful illumination in a small

package defines the Falcon floodlight

series. Ideal for illuminating signs,

walkways or highlighting

architecture, the Falcon bridges high

efficiencies and rugged construction

making it ideal for any general

purpose floodlighting application.

OPTICAL FLEXIBILITY

Offered in HID and Compact

Fluorescent lamp sources, the Falcon

is available in wattages up to 175W

MH, 150W HPS H.I.D. and 26-42W,

twin 26-32W Compact Fluorescent

and now 60W PLH Compact

Fluorescent. Leveraging the instant

restrike advantages of fluorescent

with the high output, cold weather

capabilities of HID sources, PLH

lamp technology offers -20°C cold

weather starting and a 20,000 hour

lamp life.

BUILT TOUGH

Built strong for tough, low mount

environments, the Falcon knuckle

and fixture assembly is vibration

rated to 1G in three (3) unique

planes and is offered with optional

vandal shields and wire guards for

additional protection against man

made and environmental hazards.

For additional strength in mounting,

a rugged trunnion mounting option is

available.

FALCON FLOODLIGHT

Low Wattage Floodlight

Specification Features

DOOR + LATCH

Tempered glass lens is impact and thermal shock resistant.

Easily released die-cast aluminum doorframe with stainless

steel toolless latch allows easy access for re-lamping.

Enclosure latch can be secured with a single point stainless

steel screw, provided, or with optional vandal resistant head.

HOUSING

Die-cast aluminum housing is finished in weather and

abrasion resistant dark bronze polyester powder paint.

Optional colors are available.

GASKET

Full-circumference silicone gasket seals out external

contaminants.

SOCKET

Pulse rated, 4KV, medium-base porcelain lamp socket

standard for HID. Electronic compact 4-pin fluorescent

sockets standard for PL lamp options.

REFLECTOR

Formed aluminum hammered reflector optimizes beam

efficiency and control.

MOUNTING

Adjustable ANSI 1G rated stem mounting arm fits 1/2" NPS

outlet box cover. (RBC round outlet box cover not included,

order separately). Optional heavy-gauge steel adjustable

trunnion mounting provides additional durability when

required.

[Trunnion-Mount]

[Knuckle-Mount]

PHOTOMETRICS

FOOTCANDLE TABLE [MH+HPS]

Select mounting height and read across for footcandle
values of each isofootcandle line. Distance in units of
mounting height.

Mounting Footcandle Values for
Height Isofootcandle Lines

ABCD

10' 20.00 8.00 4.00 2.00
15' 9.00 3.60 1.80 0.90
20' 5.00 2.00 1.00 0.50

VERTICAL AIMING=0°

FOOTCANDLE TABLE [PL]

Select mounting height and read across for footcandle
values of each isofootcandle line. Distance in units of
mounting height.

Mounting Footcandle Values for
Height Isofootcandle Lines

ABCD

10' 4.00 2.00 0.80 0.40
15' 1.80 0.90 0.36 0.18
20' 1.00 0.50 0.20 0.10
VERTICAL AIMING=0°

012

2

1

0

1

2

12

A B C

D

MHSF17K

175-Watt MH
14,000-Lumen Clear Lamp

012

2

1

0

1

2

12

A B C

D

HPSF15K

150-Watt HPS
16,000-Lumen Clear Lamp

FOOTCANDLE TABLE [MH+HPS]

Select mounting height and read across for footcandle
values of each isofootcandle line. Distance in units of
mounting height.

Mounting Footcandle Values for
Height Isofootcandle Lines

ABCD

10' 20.00 8.00 4.00 2.00
15' 9.00 3.60 1.80 0.90
20' 5.00 2.00 1.00 0.50
VERTICAL AIMING=0°

012

2

1

0

1

2

12

A B C

D

MHSF17K-V

175-Watt MH
14,000-Lumen Clear Lamp

With Optional Top Visor “SF/V-XX” Installed.

012

2

1

0

1

2

12

A B C

D

HPSF15K-V

150-Watt HPS
16,000-Lumen Clear Lamp

With Optional Top Visor “SF/V-XX” Installed.

012

2

1

0

1

2

12

A B C

D

PLSF42K

42-Watt PLH (42W Triple Tube)
3,200-Lumen Clear Lamp

012

2

1

0

1

2

12

A B C

D

PLSF60K

60-Watt PLH (60W Triple Tube)
4,000-Lumen Clear Lamp

3" [77mm]

2"

[51mm]

.45" Dia.

[12mm]

5" [127mm]

TRUNNION-MOUNT DRILLING DIMENSIONS

LAMP TECHNOLOGY

PLH lamp technology offers -20°F cold weather
starting and a 20,000 hour lamp life.

™
