Coolpad Snap User Manual
Coolpad Snap
User Manual
Table of Contents
HELLO FROM COOLPAD ............................................................... 1
GETTING STARTED ........................................................................ 2
Device Layout ........................................................................................... 2
Main Keys ................................................................................................. 3
Charging the Battery ................................................................................. 3
Power Phone On & Off ............................................................................. 4
SIM Card................................................................................................... 5
Home Screen ............................................................................................ 6
APPS ................................................................................................ 8
Phone ....................................................................................................... 8
Recent Calls ............................................................................................. 9
Contacts.................................................................................................. 10
Messages ............................................................................................... 12
Calendar ................................................................................................. 14
Camera ................................................................................................... 15
Gallery .................................................................................................... 16
Clock ....................................................................................................... 17
Browser................................................................................................... 18
SETTINGS ...................................................................................... 19
Sound Settings ....................................................................................... 19
Taking Screenshots ................................................................................ 19
Airplane Mode ......................................................................................... 20
Bluetooth Settings ................................................................................... 20
Location Settings .................................................................................... 22
Display Settings ...................................................................................... 22
Wireless Settings .................................................................................... 23
GET UPDATES ............................................................................... 25
Specs & Hardware .................................................................................. 26
In-box Contents ...................................................................................... 27
Declaration of Hazardous Substances .................................................... 28
HEALTH AND SAFETY INFORMATION ....................................... 29
Important Health Information and Safety Precautions ............................ 29
TIA Safety Information ............................................................................ 38
Safety information ................................................................................... 40
FDA Consumer Update .......................................................................... 45
Consumer Information on SAR ............................................................... 53
TRADEMARKS AND COPYRIGHTS ............................................. 57
STANDARD LIMITED WARRANTY .............................................. 58
Severability ............................................................................................. 61
Hello from Coolpad
Thank you for purchasing your Coolpad Snap mobile phone! Please follow these simple
but important instructions for optimal use of your new phone.
Application features and functions may vary among countries, regions or hardware
specifications, and any third-party application malfunctions are the responsibility of those
manufacturers.
Exercise caution when editing User Registration Settings as this may cause functional or
compatibility problems for which Coolpad will not be responsible.
We offer self-service for our smart terminal device users. Please visit the Coolpad
Americas official website (at www.coolpad.us) for more information on supported product
models. Information on the website takes precedence.
1
Getting Started
Get off to a running start with your new Coolpad Snap!
Device Layout
2
Main Keys
Key
Function
Volume key • Press to adjust the phone volume.
Camera key • Press to access the Camera app.
Messages key • Press to access the Messages app.
Contacts key • Press to access the Contacts app.
Clear key • Delete character in Edit mode.
Send key
End key
Navigation key • Press up, down, left or right to navigate.
OK key • Press to confirm an option.
• Press to answer or send a call.
• Press to enter call log.
• Press to end a call.
• Press to return to the Home screen.
• Press and hold to power on or off the device.
Charging the Battery
1. Connect the microUSB end of the data cable to the USB port on your device. This is
located on the lower right side of your phone.
2. Connect the USB end to the travel adapter.
3. Connect the travel adapter to an electrical outlet to fully charge your phone.
3
• Use the travel adapter that comes with your phone; using other adapters may damage
your phone.
• Charging your phone through a USB cable that is attached to a laptop takes more
time than charging it with the travel adapter.
Power Phone On & Off
Press and hold the End key until the phone powers on. The Home screen will then
be displayed. If screen lock is set up, enter the PIN code to access the Home screen.
If you don’t know your PIN code or if you have forgotten it, contact your service provider.
Do not store the PIN code within your phone, instead store the PIN code in a location that
is accessible without using the phone.
Press and hold the End key to power off your phone.
4
SIM Card
1. Open the back cover.
2. Remove the battery.
3. Insert the Nano SIM card.
separately).
4. Insert the microSD card (sold
5
Home Screen
Icon
Status
Bluetooth active
Wi-Fi active
Vibrate
Network (full signal)
The Home screen displays important information about your phone.
Status Bar
The status bar appears at the top of your Home screen. From the status bar, you can view
both the phone status (on the right side) and the notification information (on the left side).
Icons indicating your phone’s status appear on the status bar.
6
4G LTE data service
Airplane mode
Alarm set
Battery (charging)
Battery (full charge)
Missed call
New message
Changing Home Screen Wallpaper
1. From the home screen, press OK key to access the apps screen.
2. Select Settings > General settings > Display > Wallpaper.
3. Choose wallpaper from Gallery or Wallpapers .
4. Select an image, and press Left soft key to access the Menu .
5. Select Set as Wallpaper to set it as the wallpaper.
7
Apps
Phone
Making a Call
On the Home screen, dial the desired number and press the Send key to place the
call. The number you entered can be saved to Contacts by accessing Menu > Create
new contact. If you make a mistake, you may press Clear key to delete the incorrect
digits.
Emergency call
To make an emergency call, dial emergency number and press the Send key . This
works even without a SIM card but requires network coverage.
Receiving a Call
The Incoming Call screen pops up when a call comes in, along with the caller ID and
other information you’ve entered in the Contacts.
There are various options available when a call comes in.
• To answer a call, press the Send key .
• To reject a call, press the End key .
To mute the ringtone volume of an incoming call, press the Volume key.
Using the Speaker
During a call, press OK key to select Audio > Speaker. You will see an icon
displayed on the status bar and you can hear the sound when the phone is away from the
ear. The speaker is automatically disabled when you end the call.
8
Note: Due to increased volume levels, do not place the phone near your ear while the
speaker is enabled.
Recent Calls
On the Home screen, press OK key to access the apps screen, and select Recent
Calls to enter the Recent calls screen. Or you can access the Recent calls screen by
directly pressing the Send key from the Home screen. Recent calls contain your
history of calls received, missed or made. It's an easy way to redial a number, return a call
or add a number to your contacts.
In the Recent calls screen, you'll see a list of your most recent incoming and outgoing
calls. Arrow icons beside a call indicate the type of call, and multiple arrows indicate
multiple calls:
• Missed call
• Incoming call
• Outgoing call
9
Select a call and press Left soft key to access the Menu . You’ll see the
following options:
1. Send a message
2. Block number
3. Edit number before call
4. Clear call log
5. Multi-select
Contacts
On the Home screen, press OK key to access the apps screen, and select Contacts
to enter the Contacts screen. This app easily saves all your important contact
information including contact names, numbers, and email addresses.
Searching for a Contact
To search for your contacts, enter keywords in the search box. The phone system will
automatically display the matched results.
Adding a New Contact
1. On the Contacts screen, press Left soft key to access the Menu .
10
2. Select New contact.
3. Enter the contact information.
4. Press Left soft key to access the Menu and select Save to save it.
Editing a Contact
1. Select the contact you want to edit and press OK key to access the contact
details.
2. Press Left soft key to access the Menu and select Edit.
3. Edit the contact information.
4. Press Left soft key to access the Menu and select Save to save it or select
Discard to discard changes.
Deleting a Contact
1. Select the contact you want to delete and press OK key to access the contact
details.
2. Press Left soft key to access the Menu and select Delete.
3. Press Navigation key right to select Delete.
4. Press OK key to confirm deleting.
11
Sharing a Contact
1. Select the contact you want to share and press OK key to access the contact
details.
2. Press Left soft key to access the Menu and select Share.
3. Follow the prompts to turn on Bluetooth and share the contact.
Messages
On the Home screen, press OK key to access the apps screen, and select
Messages to enter the Messages screen.
Creating a Message
1. On the Messages screen, press Left soft key to access the Menu .
2. Select New message.
3. Press OK key to select recipients.
4. Enter your message. Press Left soft key to access the Menu and select
Insert attachment such as picture, video, audio and slides.
5. Press OK key to send the message.
Note: An SMS will be sent as an MMS when attachments are added.
12
Replying to a Message
1. On the Messages screen, select the message you want to reply to.
2. Compose your message and press OK key to send it.
Deleting a Message
1. On the Messages screen, select the message conversation you want to delete.
2. Press Left soft key to access the Menu and select Delete thread to delete the
message conversation.
Entering Text
You can enter text using your phone’s 12-key keyboard. Your phone offers you a choice
of using normal or predictive text input.
1. When in a text entry field, you can press to switch among
“Abc/abc/ABC/KT9/123” modes. You can check the current text input mode from the
status bar.
2. Press to insert a space. Press to insert a punctuation mark or special
character.
3. If you want to delete the text entered, press the Clear key to delete the letters one
by one, or press and hold the key to delete all.
13
Note: KT9 is a predictive text input mode which predicts words as you type. In predictive
mode, the phone will suggest words for you at the bottom of the screen. Use the
Navigation key to select the desired word and OK key or space to select the
word. Other modes including Abc, abc and ABC are normal text input modes. You can
press the number keys 2-9 until the desired letter displays.
Calendar
On the Home screen, press OK key to access the apps screen, and select Calendar
to enter the Calendar screen.
• To create a new event, press Left soft key to access the Menu and select
New event, fill in new event information and press Left soft key to save.
• To modify the Calendar view, press Left soft key to access the Menu and
select View by to change between Month, Week or Agenda view.
14
Camera
On the Home screen, press OK key to access the apps screen, and select Camera
to enter the Camera screen. You can use the Camera app to take pictures and record
videos.
Taking a Photo
1. On the Camera screen, focus on your subject by looking at your phone screen.
2. Press OK key to take a photo.
3. Press OK key again to confirm saving the photo or press Left soft key to
retake a photo.
Creating a Video
1. On the Camera screen, press Navigation key right to activate the Video mode.
2. Press OK key to start recording a video.
3. Press OK key again to stop when you finish recording.
15
Gallery
On the Home screen, press OK key to access the apps screen, and select Gallery
to enter the Gallery screen. You can view and manage photos and videos stored in
your phone.
Deleting an Image or a Video
1. Select an image or a video you want to delete and press OK key to access the
image or video details.
2. Press Left soft key to access the Menu and select Delete.
3. Press OK key to confirm deleting.
Note: To delete multiple images and videos, enter the album and press Left soft key
to access the Menu and select Multi-select. Select the images or videos you want to
delete one by one. If you want to delete all images or videos, press Left soft key to
access the Menu and select Select all.
Sharing an Image or a Video
1. Select an image or a video you want to share and press OK key to access the
image or video details.
2. Press Left soft key to access the Menu and select Share.
3. From the pop-up screen, select your desired sharing method.
16
Clock
On the Home screen, press OK key to access the apps screen, and select Clock
to enter the Clock screen. You can set alarms, check the current time in many cities
around the world, set a specific duration, or time an event.
Operating the Alarm
1. On the Clock screen, press Navigation key left to enter the Alarm screen.
2. Press Left soft key to access the Menu and select New alarm.
3. Choose a time to set your alarm.
17
Loading...
