Coolpad 5860E, Quattro 4G User Manual
5860E
User Manual
Coolpad 5860E
Copyright ©2012 Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd. All rights
reserved. Coolpad logo are registered trademarks of Yulong Computer Telecommunication
Scientific (Shenzhen) Co., Ltd. All other trademarks are the property of their respective owners.
No part of this user manual may be reproduced, distributed, translated, or transmitted in any
form or by any means, electronic or mechanical, including photocopying, recording, or storing
in any information storage and retrieval system, without the prior written permission of Yulong
Computer Telecommunication Scientific (Shenzhen) Co., Ltd.
Coolpad 5860E
Table of Contents
PHONE OVERVIEW .................... 1
BACK COVER AND BATTERY: 2
BASIC OPERATIONS .............................. 6
POWERING ON/OFF ................................ 6
HOME SCREEN ........................................ 7
APPLICATIONS INTERFACE ................ 7
CONTACTS .................................... 7
VIEW AND EDIT CONTACT ...... 8
MESSAGING.................................. 9
COMPOSING SMS/MMS ......................... 9
DIALING ....................................... 11
CALL LOG ................................... 14
BROWSER .................................... 15
CLOCK .......................................... 15
CALENDAR .................................. 15
SENDING E-MAIL ...................... 16
MUSIC ........................................... 18
SOUND RECORDER ................... 19
GALLERY ..................................... 19
CAMERA ...................................... 19
Coolpad 5860E
VIDEO ........................................... 20
INTRODUCTION TO METRO
APPLICATIONS .......................... 20
IM AND SOCIAL™ ................................20
METRO411 ..............................................21
APPSTORE ..............................................21
TOTAL PROTECTION ...........................21
METROPCS EASY WI-FI .......................22
MSTUDIO ................................................22
MYEXTRAS ............................................22
MYMETRO .............................................23
POCKET EXPRESS ................................23
RHAPSODY ............................................23
TALK ....................................................... 23
SETTINGS .................................... 24
WIRELESS AND NETWORK ............... 24
CALL SETTINGS ................................... 25
SOUND .................................................... 25
DISPLAY................................................. 25
LOCATION AND SECURITY ............... 25
APPLICATIONS ..................................... 26
ACCOUNT AND SYNC ......................... 26
PRIVACY ................................................ 26
STORAGE ............................................... 26
LANGUAGE AND KEYBOARD .......... 27
VOICE INPUT AND OUTPUT .............. 27
DATE AND TIME ................................... 27
Coolpad 5860E
ABOUT PHONE ......................................27
CALCULATOR ............................ 27
VOICE DIALER .......................... 27
GOOGLE SEARCH ..................... 28
MAPS ............................................ 28
NAVIGATION .............................. 28
PLACES ........................................ 28
VOICE SEARCH ......................... 28
TECHNOLOGICAL DATA ........ 29
ACCESSORY LIST ..................... 31
Coolpad 5860E
Using this manual
Thank you for purchasing this
Coolpad mobile device. Before proceeding
further, Coolpad requests that you comply
with the following:
1. Please read this manual and the safety
precautions therein carefully before using
your new device.
2. The content identified in this user
manual may differ from the product, or
from software provided by service
providers or carriers, and is subject to
change without prior notice.
3. Applications, their features and their
functions may vary by country, region, or
hardware specifications. Coolpad is not
liable for performance issues caused by
third-party applications.
4. Coolpad is not liable for performance
issues or incompatibilities caused by user
editing of registry settings.
Coolpad 5860E
PHONE OVERVIEW
Note: All the keys on the touch screen interface are all touch keys.
Coolpad 5860E
Key Functionality
Power Key When the backlight is on, press the button shortly to turn off the backlight.
Press and hold the key to select from: Power Off; Restart; Airplane Mode or
Slient Mode. While the device is asleep, press the Power Key to wake it up.
Menu Key Tap for the menu to pop up at the functionality interface
Home Key Tap to go back to the functionality interface from the application interface
Back Key Tap to go back to the previous interface
Search Key Tap to perform a search
Volume Key Adjust call, ringtone, music and video volumes
Camera Key
Press and hold the camera key to activate the camera application. Once the
application is running, press the camera key to take photos or record videos.
Coolpad 5860E
BACK COVER AND BATTERY:
Uninstalling the back cover:
1. With one hand, tightly hold the
device face down.
2. With the other hand, slide the back
cover downwards and lift to remove
the cover.
Coolpad 5860E
Taking out the battery:
1. With one hand, tightly hold the
device face down.
2. With the other hand, lift the battery
to remove it.
Note: Your device must be powered
off before exchanging or
uninstalling the battery!
Charging the battery:
1. Insert the end of the USB cable
corresponding to your device into the
I/O port.
2. Connect the other end of the USB
cable to the power plug, and insert the
Coolpad 5860E
power plug into the outlet. When
these steps are completed, your
device can be charged.
3. If your battery has been not used for a
long time, it will gradually discharge.
If this happens and you want to use
your device, you must first recharge
the battery.
Notes:
1) You can view battery information by
use of the battery icon located in the
tray.
2) When your device is powered on and
charging is in progress, the battery
icon in the tray will display a
charging status. While your device is
powered off and charging is in
progress, the charging icon will be
displayed on the screen.
3) When the battery is at low levels,
your device will automatically power
off. Please recharge the battery to
continue using your device.
PHONE CARD AND SD CARD
Coolpad 5860E
You can use your device to perform
certain operations without a phone card,
but functionalities related to network and
telecommunications are not available
without a phone card. Your device is a
LTE 4G Network mobile phone and will
only operate properly with a corresponding
phone card.
Note: To use a Micro SD card, insert and
push it into the card slot, the card slot is
located at the left of phone card slot; pull
down on the card to remove it from the
slot. Please take good care of your phone
card and SD card. Do not bend, scratch, or
expose your phone or SD card to static
electricity or water.
BASIC OPERATIONS
POWERING ON/OFF
1. When your device is powered off,
press and hold the Power key to
power on and boot up the main
interface.
2. When your device is powered on,
press and hold the Power key for
Coolpad 5860E
“Phone options” to select from:
Airplane Mode; Silent Mode; Restart
or Power Off based on your needs.
HOME SCREEN
You can easily and conveniently view
applications on the Home screen. Slide
your finger to the left or right to scroll
through the Home screen pages. Tap the
Menu Key to Add and Manage
applications, Change the wallpaper, Edit,
and access phone settings.
APPLICATIONS INTERFACE
At the applications interface, press,
hold, and drag the selected application to
adjust its location.
CONTACTS
In “Contacts”, you can store and
manage contact information. Select your
contact to edit your contact’s name, phone
number, e-mail address, and other
information. Also, you can execute various
communication options (e.g. send a SMS)
from the Contact’s interface. Morover, you
Coolpad 5860E
can view, add, manage, and sync your
Contacts information to and from your PC.
Create New Contact
1. Tap the Contact icon on the home
interface
2. Tap the Menu key and select “New
Contact” to enter the interface for
creating a new contact.
3. Input the contact information and tap
“Done” to finish creating the new
contact.
View and edit contact
Select the contact to view details for
that contact:
Coolpad 5860E
1. You can view and/or edit the
contact’s stored information.
2. Tap the Menu key and select “Edit
Contact” to edit information
pertaining to the contact. When
finished editing, tap “Done” to save
the changes and exit the interface.
Search for contact(s)
Your device features a search
functionality for Contacts. Tap the Menu
key and select “Search”, then input key
words to quickly search for your desired
contact.
MESSAGING
COMPOSING SMS/MMS
1. Tap the Messaging icon to enter the
messaging main interface, and then
tap “Compose new message” to
create a new message. Directly input
the message recipient's phone number
into the “To:” box or tap the
Recipient icon to select the desired
Coolpad 5860E
recipient(s) from your Contacts list.
2. Type your desired message into the
message box.
3. Tap “Send” to send your message and
a copy of it will be saved in the Sent
mailbox. If you tap the “Back” button
prior to sending the message, the
message will be automatically saved
in the Drafts mailbox.
4. You can tap the Menu key to attach
photos, audio files, videos, and other
types of files based on your needs.
5. Tap “Send” to send the message as a
MMS. If you tap “Back” prior to
sending the message, the message
will be automatically saved in Drafts.
Searching messages
At the main messaging interface, tap
the Menu key to select “Search” from the
Coolpad 5860E
pop-up menu and input key words(it can
search messages by receiver’s names) to
search for your desired message(s).
Settings
1. At the main messaging interface, tap
the Menu key to select “Settings”
from the pop-up menu.
2. You can access various settings for
message storage, SMS, MMS,
notifications, signature, sending
options, and message statistics.
DIALING
You can dial a phone number through
the Dialpad, Contacts, or Call log
Coolpad 5860E
interfaces. From the main interface, select
“Phone” to access the Dialpad and input
the phone number with the on-screen
keyboard. Tap the green Call icon to place
the call. For other dialing methods, please
refer to the relevant sections.
Answering a call
When you receive an incoming call,
slide your finger across the screen to
answer it.
Answering/Placing a call via earphone
During incoming calls: When there is an
incoming call, the backlight is on
automatically. Short press to answer and
long press to hand up.
During active calls:
Backlight on Backlight off
Short
press
Long
press
Functionalities during active calls
Mute Mute
Hand up in
one second
Release to
hand up
Coolpad 5860E
On the active call interface, tap
“Mute” to mute your voice but continue
hearing the receiver’s; tap “Speaker” to
activate the Speaker function; tap【+】to
access Dial pad to add a new caller; tap
“Dialpad” to access the input keyboard of
the active call interface. If a Bluetooth
accessory is connected, tap “BT” to switch
to Bluetooth mode. Tap “End” to end the
call.
Coolpad 5860E
CALL LOG
The call log stores your dialed, received
and missed calls.
Basic operations
1. Select a specific list/history to view
its details.
2. Click the number listed to access
Call Log options: tap “Call Back” to
call the selected phone number; tap
“Send Text Message” to send a
message to the selected phone
number;and tap “Add to Contacts”
to add and store the selected phone
number.
Deleting the call log
At the main call log interface, tap
the Menu key and select “Clear Call Log”.
Coolpad 5860E
This command will clear all the call
histories within the call log.
BROWSER
With the device’s web browser, you
can easily and rapidly connect to a
network and/or webpage(s). While
accessing a website, you can perform basic
web browsing operations, such as opening
a new window, adding bookmarks, and
refreshing the website, by tapping the
Menu key and selecting the desired
command.
Note: Access to the network depends on if
the network service provider offers the
requested service and whether you have
subscribed to it. Please contact the network
service provider for specific details.
CLOCK
With the clock function, you can set
alarm time(s), alarm ringtone(s), and day(s)
to repeat the alarm.
CALENDAR
The Calendar application includes
numerous functions such as a Calendar and
Coolpad 5860E
Agenda. To switch between different
views of the calendar, tap either “List”,
“Day”, “Week”, or “Month”. To add
events to the Calendar/Agenda, at the
screen of Month, long press the day you
want to add events to pop up context menu
and click Add to build new events, and tap
on “Done” to save the event on the
Calendar.
SENDING E-MAIL
With your device, you can send,
receive, and manage e-mails.
Creating a new account
Coolpad 5860E
Before using the e-mail function,
you must first set up your own e-mail
address/mailbox. You can apply for an
e-mail address and/or mailbox from
third-party websites, or use your own
pre-existing e-mail address/mailbox.
Account management
At the e-mail inbox interface, tap the
Menu key to select your account. Press and
hold the selected e-mail account to access
a pop-up menu with account settings and
Coolpad 5860E
operations. At the account interface, tap
the Menu key to add e-mail accounts.
Note: If you do not specify which account
to use to send your e-mail, the system will
use the default account to send your
e-mail.
Composing new e-mail
At the e-mail inbox interface, tap
the Menu key and select “Compose” to
compose a new e-mail message. Manually
input the receiver’s e-mail address into the
“To:” box, write the Subject and Content
of the message, and tap “Send” to deliver
the e-mail to the specified receiver.
MUSIC
Select the Music application to enter
the Music interface, where you can view
and select to play audio files organized by
song titles, playlists, albums, or artists.
While a song is playing, you can perform
operations such as Stop, Pause/Play,
Previous, Next, and Set loop mode.
Coolpad 5860E
SOUND RECORDER
Your device has a recording
function to record audio file(s).
GALLERY
Select the “Gallery” application from
the Applications menu. From the Gallery
interface, you can perform operations such
as managing and viewing photos and
videos.
CAMERA
Your device has a camera for taking
photos and videos.
Taking pictures
Select the “Camera” application from
the Applications menu. While in the
camera interface, tap the icons shown on
the screen to adjust the white balance,
picture size, picture quality, color effect(s),
etc. for your photo. After adjusting your
camera settings, aim your camera lens and
tap “Shoot” to capture the image. Tap the
picture to delete, share, set the picture as
wallpaper, or perform other operations.
Note: please remove the camera lens
cover before using the camera.
Coolpad 5860E
VIDEO
Select the “Camcorder” application
from the applications menu. While in the
camcorder interface, tap the icons shown
on the interface to adjust the color effect(s),
white balance, video quality, etc. for your
video. After adjusting your settings, aim
your camera lens and tap “Shoot” to start
recording a video. While the video is
shooting, the amount of time available for
recording and the amount of time that has
been recorded is displayed at the bottom of
the screen. Tap the button to stop
recording the video. Tap the video to
delete, share, and play your short video(s).
INTRODUCTION TO METRO
APPLICATIONS
IM AND SOCIAL™
With your MetroPCS cell phone,
you can stay connected to your friends
through Facebook, Twitter, and instant
messaging (IM) all through one
easy-to-use application, IM and Social.
Coolpad 5860E
Open up the application and log in to your
accounts to get started.
MAIL@METRO
With Mail@metro, you can send
and receive email wherever you go. You
can directly access your existing e-mail
account from your MetroPCS phone as
well as set up alerts for when new emails
are received.
METRO411
With Metro411, you have quick and
easy access to directory assistance
information through one of the MetroPCS
Directory Assistance Services.
APPSTORE
Download the most popular games
and applications from the Metro App Store
to customize your phone.
TOTAL PROTECTION
To give the user the best protection
against viruses and spyware, we've
combined all the great features of
MetroGUARD and MetroBACKUP into a
single application. You can adjust your
Coolpad 5860E
cell phone’s security and backup settings
for your desired level of protection.
METROPCS EASY WI-FI
With MetroPCS Wi-Fi, your
MetroPCS cell phone can find and connect
to hundreds of thousands of free Wi-Fi
hotspots around the world. Add to and
save personalized lists of your own hotspot
accounts, such as the Wi-Fi bundled with
your home service or with other network.
MSTUDIO
MetroSTUDIO offers full song
tracks, ringtones and ringback tones from
today’s hottest artists. Watch TV shows,
news, sports, and other entertainment on
your cell phone with Video On Demand.
MYEXTRAS
MyExtrasSM provides you with
informational content such as weather
forecasts, sports scores, entertainment
highlights, information about local events,
promotional offers, and exclusive
discounts.
Coolpad 5860E
MYMETRO
MyMetro can help you manage your
MetroPCS account from anywhere and at
anytime. View your account information,
pay your bill, add features, and more
directly from your mobile phone screen.
POCKET EXPRESS
Pocket Express streamlines your
customized news sources for quicker and
easier perusal at your fingertips. View
news, sports, weather, maps, and more
without the browse-and-wait of mobile
Internet.
RHAPSODY
Rhapsody is one of the leading
online music subscription services in the
United States. A subscription allows
members access to numerous full-length
songs from almost anywhere, such as web
browsers, mobile applications, MP3
players, and hi-fi systems.
TALK
Log in with your Gmail account to
chat, text, and call your friends all in one
easy-to-use application.
Coolpad 5860E
SETTINGS
WIRELESS AND NETWORK
You can adjust your cell phone’s
wireless and network settings such as
putting your phone in airplane mode and
modifying your Bluetooth connections.
Airplane mode: Select this option to stop
all wireless connections.
Wi-Fi：Tap to turn on/off Wi-Fi.
Wi-Fi settings: You can adjust the settings
for Wi-Fi and other networks.
Bluetooth：Tap to turn on/off Bluetooth.
Bluetooth settings
Your device supports Bluetooth. Your
Bluetooth device can connect with your
device from up to 10 meters. If there is any
obstacle between the transmitting and
receiving devices, the Bluetooth signal
may be disrupted and/or weakened. At the
Settings interface, select “Bluetooth
Settings” to enter the interface. Tap
“Bluetooth” to turn it on, tap “Device
Name” to change the Bluetooth device’s
name, tap “Discoverable” to let your
device be viewed by other Bluetooth
Loading...
