ENGLISH
FAN CF-2006
The fan is intended for artificial ventilation of rooms.
DESCRIPTION
1. Front safety grid
2. Photoreceiver window
3. Blade clamp
4. Blades
5. Rear grid fastening nut
6. Rear grid with carrying handle
7. Motor unit
8. Control panel
9. Motor unit clamp
10. Telescopic bar
11. Telescopic bar clamp
12. Lower bar
13. Crossed floor support
14. Lock
Control panel (8)
15. On/speed selection button «ON/SPEED»
16. Oscillation mode on/off button «SWING»
17. Timer on/off button «TIMER»
18. Switch-off button «OFF»
19. «MODE» air flow mode selection button
21. Speed indicators «HIGH-MID-LOW»
22. Timer operation time indicators «0,5H-1Н-2Н-4Н»
23. Ventilation mode indicator «NORMAL»
24. Natural airflow mode indicator «NATURAL»
25. Night mode indicator «SLEEP»
Remote control (20)
15. On/speed selection button «ON/SPEED»
16. Oscillation mode on/off button «SWING»
17. Timer on/off button «TIMER»
18. Switch-off button «OFF»
19. «MODE» air flow mode selection button
SAFETY MEASURES
Before using the fan, read this instruction manual carefully and
keep it for further reference.
Use the unit for its intended purpose only as specified in this manual.
Mishandling of the unit may lead to its breakage and cause harm
to the user or damage to property.
• Before switching the unit on for the first time make sure that
your home mains voltage corresponds to the unit operating
voltage.
• Before using the fan examine the power cord closely and
make sure that it is not damaged. If you find that the power
cord is damaged, do not use the unit.
• If the power cord is damaged, it should be replaced by the
manufacturer, a maintenance service or similar qualified
personnel to avoid danger.
• Do not use the fan outdoors.
• Place the unit on a flat, dry and steady surface away from
sources of heat or open flame.
• Do not use the unit near containers filled with water, next to a
kitchen sink, in wet basements or near a swimming pool.
• Do not immerse the fan, power cord and power plug into
water or any other liquids.
• Do not touch the unit body and the power plug with wet hands.
• If the fan falls into water, unplug it before touching it and only
then you may take the fan out of water. Apply to the nearest
authorized service center for testing or repairing the unit at
the contact addresses given in the warranty certificate and
on the website www.coolfort.ru.
• Make sure that the power cord does not contact with hot
surfaces and sharp furniture edges.
• Do not switch the unassembled fan on.
• Do not insert any foreign objects into the openings of the fan
protective grids to avoid injuries or unit damage.
• Do not touch the rotating blades during the fan operation.
• Do not place the fan near curtains or house plants.
• It is not recommended to stay under the air flow coming from
the fan for a long time (especially for children and elderly
people).
4
• Never leave the operating unit unattended.
• Unplug the fan before cleaning and when you do not use the
unit or before moving it to a new place.
• When unplugging the fan pull the plug but not the cord.
• Clean the unit regularly.
• Do not leave children unattended to avoid them using the unit
as a toy.
• For children safety reasons do not leave polyethylene bags
used as packaging unattended.
Attention! Do not let children play with polyethylene bags or
packaging film. Danger of suffocation!
• Do not allow children to touch the unit and the power cord
during the unit operation.
• The unit is not intended to be used by people with physical,
sensory or mental disabilities (including children) or by persons lacking experience or knowledge if they are not under
supervision of a person who is responsible for their safety
or if they are not instructed by this person on the usage of
the unit.
• Do not use the fan if the blades, the power cord or the power
plug are damaged, if the fan works improperly, after it was
dropped or was damaged in some other way.
• If the power cord is damaged, it should be replaced by the
manufacturer, a maintenance service or similar qualified
personnel to avoid danger.
• Do not repair the unit by yourself. Do not disassemble the
unit by yourself, if any malfunction is detected or after it was
dropped, unplug the unit and apply to any authorized service
center at the contact addresses given in the warranty certificate and on the website www.coolfort.ru.
• Transport the unit in the original package.
• Keep the unit in a dry cool place unreachable for children and
people with disabilities.
THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY. ITS
COMMERCIAL USAGE AND USAGE IN PRODUCTION AREAS
AND WORK SPACES ARE PROHIBITED.
BEFORE THE FIRST USE
After the unit transportation or storage at low temperature
keep it for at least three hours at room temperature before
switching on.
Fan Assembly
• Unpack the fan and remove any advertising stickers that
can prevent its operation.
• Check the unit for damages, do not use it in case of any.
• Set the crossed support (13) on a flat dry surface.
• Insert the lower part of the bar (12) into the floor support
(13) and fix it with the clamp (14) by threading it clockwise.
Make sure that the support (13) is fixed firmly.
• Unscrew the clamp (11) and extend the bar (10) to the
desired height and fix it by tightening the clamp (11) with
a slight effort as you turn it clockwise.
• Install the motor unit (7) on the telescopic bar (10)
until bumping and fix it by the clamp (9), do not apply
excessive effort when screwing the clamp of the motor
unit (9).
• Unscrew and remove the rear grid (6) fastening nut (5).
• Install the rear grid (6) on the motor unit (7). The carrying
handle on the rear grid (6) should be turned upwards.
• Fix the rear grid (6) on the motor unit (7) with the nut (5)
by screwing it clockwise until bumping.
• Install the blades (4) on the motor axis and fix them with
the clamp (3), rotating it counterclockwise, holding the
blades (4) with a free hand.
• Open the clamps on the rear grid (6).
• Install the front grid (1) on the rear grid (6) and close the
clamps.
• The fan is ready for operation.
USAGE
• Before using the unit for the first time, make sure that the
mains voltage corresponds to the unit operating voltage.
• Plug the unit in, the speed indicators (21) and the natural
airflow mode indicator «NORMAL» (23) will light up.
ENGLISH
• Press the «ON/SPEED» button (15) to select the blades rotation speed:
– «LOW» – low air flow speed;
– «MID» – medium air flow speed;
– «HIGH» – high air flow speed.
• Press the button (16) «SWING» to switch the 90° oscillation
operating mode of the fan on.
• To stop the oscillation, press the button (16) «SWING» again.
• To select the airflow mode, consequently press the button
(19) «MODE» on the remote control or the control panel
(8). You may choose three operation modes, the operation
modes are shown (23, 24, 25):
– «NORMAL» – simple ventilation, the indicator (23) is glow-
ing; the blades rotation speed depends on the selected
mode and is shown with the indicators (21) «HIGH-MIDLOW».
– «NATURAL» – natural wind, the indicator (24) is glow-
ing; natural wind imitation mode, the air flow speed is
chaotically changing: from soft breeze to strong gusts
of wind.
– «SLEEP» –night mode, the indicator (25) is glowing; the
air flow speed is changing in cycles, constantly increasing
and decreasing.
• You can set the operation time of the fan sleep timer with
the button (17) «TIMER», one of four indicators (22) will be
glowing.
• You can set the fan operation time from 0.5 «0,5Н» hour to
7.5 «0,5Н-1Н-2Н-4Н» hours (with 0.5 hour setting step).
• One of four indicators (22) will show the selected operation
time of the timer.
• To switch the timer off press the button (17) «TIMER» repeatedly until all the indicators (22) go out.
• To switch the fan off press the button (18) «OFF».
• You may change the position of the motor unit (7) of the fan
in accordance with the required air flow angle in the vertical
position, the fan slope angle is set manually. To change the
fan slope angle press with a slight effort on the motor unit (7)
upwards or downwards. Clicking while the fan is being tilted
is normal.
USING THE REMOTE CONTROL (20)
ATTENTION!
Batteries leakage can cause injuries or damage the unit. To
avoid the unit damage, follow the instructions given below:
– use only the «AAA» batteries;
– do not use old and new batteries at the same time or differ-
ent types of batteries;
– do not recharge the batteries;
– insert the batteries strictly following the polarity;
– remove the batteries if you are not planning to use the unit
for a long time;
– replace the batteries in time.
– apply to specialized centers for further recycling of the bat-
teries;
– avoid the power nippers circuit.
To use the remote control (RC) (20) open the battery compartment lid and insert 2 «AAA» batteries (not supplied with the unit)
into the battery compartment strictly following the polarity, close
the battery compartment lid. If you do not use the unit for a long
time, remove the batteries from the battery compartment of the
remote control (20).
Note: – the buttons on the remote control (20) fully correspond
with the buttons on the control panel (8).
MAINTENANCE AND CARE
• Before cleaning the fan switch it off by pressing the button
(18) «OFF» or the button (18) «OFF» on the remote control
(20) and unplug it.
• Do not use abrasive cleaners and solvents to clean the unit.
• Clean the motor unit (7) with a slightly damp cloth, and then
wipe it dry.
• If you need to clean the blades (4), open the clamps of the
rear grid (6), remove the front grid (1) and then wipe the
blades (4) with a slightly damp cloth.
• Install the front grid (1) back to its place and close the
clamps.
• You may clean the fan blades with a vacuum cleaner using a
proper attachment.
• Do not immerse the motor unit (7) of the fan into water or any
other liquids. Make sure that no liquids get into the motor unit
(7) of the fan to avoid its damage and prevent risk of electric
shock.
STORAGE
– Unplug the fan and clean it.
– If necessary, dismantle the fan.
– Open the clamps on the rear grid (6), remove the front grid
(1), unscrew the blade clamp (3) by turning it clockwise,
remove the blades (4), unscrew the fixing nut of the rear grid
(6) and remove the grid (6).
– Unscrew the clamp (9) and remove the motor unit (7) from
the telescopic bar (10).
– Unscrew the clamp (14) and remove the bar (12) from the
crossed floor support (13).
– Pack the fan into the original package and put it away for
storage in a dry cool place away from children and disabled
persons.
DELIVERY SET
Motor unit – 1 pc.
Front grid – 1 pc.
Blade clamp – 1 pc.
Blades – 1 pc.
Rear grid – 1 pc.
Telescopic bar with the clamp – 1 pc.
Crossed floor support – 1 pc.
Remote control – 1 pc.
Warranty certificate – 1 pc.
Instruction manual – 1 pc.
TECHNICAL SPECIFICATIONS
Power supply: 220-240 V ~ 50 Hz
Rated input power: 40 W
Diameter: 40 cm (16”)
Remote control: 3 V 2 «AAA» batteries 1.5 V (not supplied)
RECYCLING
For environment protection do not throw out the unit and the batteries (if included), do not discard the unit and the batteries with
usual household waste after the service life expiration; apply to
specialized centers for further recycling.
The waste generated during the disposal of the unit is subject to
mandatory collection and consequent disposal in the prescribed
manner.
For further information about recycling of this product apply to a
local municipal administration, a disposal service or to the shop
where you purchased this product.
The manufacturer preserves the right to change design, structure and specifications not affecting general principles of the
unit operation without a preliminary notification due to which
insignificant differences between the manual and product may
be observed. If the user reveals such dif ferences, please report
them via e-mail info@coolfort.ru for receipt of an updated
manual.
Unit operating life is not less than 3 years
Guarantee
Details regarding guarantee conditions can be obtained from the
dealer from whom the appliance was purchased. The bill of sale
or receipt must be produced when making any claim under the
terms of this guarantee.
This product conforms to the EMC Directive 2014/30/
EU and to the Low Voltage Directive 2014/35/EU.
5
Loading...
