MWE GOLD 850 - V2 (FULL MODULAR)
MPE-8501-AFAAG
FULL MODULAR 80 PLUS GOLD CERTIFIED ATX POWER SUPPLY
MWE Gold –V2 (Full Modular) is the next step in the evolution of Cooler Master’s entry level 80 PLUS Gold power offerings. The intention was not to create a new product but to improve a current one to be even more useful to consumers. The design changes implemented in this iteration of the MWE Gold were based on user feedback and demand. New things were added or changed to make the user experience better and simpler. Together, these design choices deliver a great entry level power supply option complete with high efficiency, reliability, simplicity, and a competitive price point.
FEATURES |
|
|
|
|
|
SPECIFICATIONS |
|
|
|
|
|
|
|
||
Highly Efficient Performance : The 80 PLUS Gold certification |
|
|
Product Name |
|
|
|
MWE Gold 850 - V2 (Full Modular) |
||||||||
guarantees a minimum efficiency of 90%. |
|
|
|
Item Code |
|
|
|
MPE-8501-AFAAG |
|
|
|||||
|
|
|
|
|
|
ATX Version |
|
|
|
ATX 12V |
|
|
|
|
|
2 EPS Connectors : 2 EPS connectors included with all models for |
|
|
PFC |
|
|
|
Active PFC |
|
|
||||||
|
|
Input Voltage |
|
|
|
90 - 264V |
|
|
|||||||
universal current generation motherboard compatibility. |
|
|
Input Current |
|
|
|
12 - 6A |
|
|
|
|
||||
|
|
|
|
|
|
Dimensions (L x W x H) |
|
140 x 150 x 86mm |
|
|
|||||
120mm HDB Fan : 120mm Hydro Dynamic Fan bearing for |
|
|
Fan Size |
|
|
|
120mm |
|
|
|
|
||||
|
|
Fan Bearing |
|
|
|
HDB |
|
|
|
|
|||||
improved cooling and noise reduction. |
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
Efficiency |
|
|
|
90% @ Typical Load |
|
|||||||
|
|
|
|
|
|
80 PLUS Rating |
|
|
|
80 PLUS Gold |
|
|
|||
High Operating Temperature : The MWE Gold - V2 can operate |
|
|
ErP 2014 Lot 3 |
|
|
|
Yes |
|
|
|
|
||||
|
|
Operating Temperature |
|
0~50°C |
|
|
|
|
|||||||
safely at up to 50 degrees. |
|
|
|
|
|
|
|
|
|||||||
|
|
|
Hold Up Time |
|
|
|
>16ms at 100% Load |
|
|||||||
|
|
|
|
|
|
|
|
|
|
||||||
Full Modular Cabling : MWE Gold - V2 comes with full modular flat, |
|
|
MTBF |
|
|
|
>100,000 hours |
|
|
||||||
|
|
Connectors |
ATX 24 Pin |
|
x1 |
|
|
|
|
||||||
black cables for increased airflow. |
|
|
|
|
EPS 4+4 Pin |
|
x1 |
|
|
|
|
||||
|
|
|
|
|
|
|
EPS 8 Pin |
|
x1 |
|
|
|
|
||
5 Year Warranty : All MWE Gold - V2 models come with a 5 year |
|
|
|
SATA |
|
x12 |
|
|
|
|
|||||
|
|
|
Peripheral 4 Pin |
x4 |
|
|
|
|
|||||||
factory warranty from purchase date. |
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
PCI-e 6+2 Pin |
|
x4 |
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
||||
PACKAGE INFORMATION |
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
AC INPUT |
|
|
90 - 264V~ 12 - 6A |
|
||||||||
|
|
|
DC OUTPUT |
|
+3.3V |
+5V |
|
+12V |
|
-12V |
+5Vstb |
||||
Cable Type |
EAN |
UPC |
|
|
|
|
|
||||||||
|
|
|
|
|
20A |
20A |
|
70.8A |
|
0.3A |
3A |
||||
|
|
|
|
|
|
|
|||||||||
US |
4719512106280 |
884102078590 |
|
|
|
|
|
|
|
||||||
|
|
TOTAL POWER |
|
120W |
|
850W |
|
|
|
||||||
U2 |
4719512106297 |
884102078606 |
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
850 |
|
|
|
||||
UK |
4719512106303 |
884102078613 |
|
|
|
|
|
|
|
|
|
|
|
||
EU |
4719512106310 |
884102078620 |
|
|
|
|
|
|
|
|
|
|
|
|
|
ST |
4719512106327 |
884102078637 |
|
|
|
|
|
|
|
|
|
|
|
|
|
AU |
4719512106334 |
884102078644 |
|
|
|
|
|
|
|
|
|
|
|
|
|
BR |
4719512106341 |
884102078651 |
|
|
|
|
|
|
|
|
|
|
|
|
|
KR |
4719512106358 |
884102078668 |
|
|
|
|
|
|
|
|
|
|
|
|
|
JP |
4719512106372 |
884102078682 |
|
|
|
|
|
|
|
|
|
|
|
|
|
IN |
4719512106389 |
884102078699 |
|
|
|
|
|
|
|
|
|
|
|
|
|
WO |
4719512106396 |
884102078705 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Nett Weight |
|
2.17 kg / 4.784 lb |
|
|
|
|
|
|
|
|
|
|
|
|
|
Gross Weight |
|
2.57 kg / 5.666 lb |
|
|
|
|
|
|
|
|
|
|
|
|
|
Package Dimensions |
|
310 x 194 x 120mm (12.2 x 7.64 x 4.72") |
|
|
|
|
|
|
|
|
|
|
|
|
|
Carton Dimensions |
|
620 x 325 x 220mm (24.41 x 12.8 x 8.66") |
|
|
|
|
|
|
|
|
|
|
|
|
|
Unit / Carton |
|
5 pcs |
|
|
|
|
|
|
|
|
|
|
|
|
|
Carton / Pallet |
|
16 pcs |
|
|
|
|
|
|
|
|
|
|
|
|
|
