005M
Product Features
Four USB ports, including 3.0
added buttons for LED strip and fan speed control
Front and top panels fit snugly
Optional padded front and top
panels (with added plate) balance noise and airflow
to six 140mm
with three in front and two on the top for top
Unique components panel for drive
Water bracket
mounted
Partition panel isolates power supply
Two pockets with four mounting
behind motherboard tray and on top of
The new wave of case technology pioneered by our
MasterCase series crests with the unique FreeForm™
Modular System, which allows unparalleled
upgrade your case via the addition of top panels or doors,
adjusting aesthetics, thermal performance and layout
The MasterCase Maker 5 advances beyond the concept
of a standard build by offering the option to completely
d readjust the case’s form and functionality with
multiple interior and exterior outlooks, ample space and
MasterCase Maker 5 (MCZ-
-KWN00)
flexibility.
swap an
customized accessories.
flexibility to
•
Upgraded I/O –
•
Magnetic paneling with a magnetic grip
•
Sound suppression -
•
Custom air cooling – Support for up
fans,
cooling
•
Clip-and-click cage adjustment
•
Diverse 280mm liquid cooling enables top cooling while shifting the bottom-
HDD cage allows for front installation
•
Dual chamber and cables for clean management
•
Slip-and-clip SSDs positions –
Type C,
-down
partition
Dimensions
(L x W x H)
Net Weight 12.3kg / 27.2lb
M/B Type ATX, microATX, Mini-ITX
5.25" Drive Bays 2
3.5" Drive Bays 5
2.5" Drive Bays 2+5
I/O Panel USB 3.0 x1, USB 3.0 (type C) x1, USB 2.0 x2, Audio In & Out (supports HD Audio).
Expansion Slots 7
Cooling Support
Radiator Support
528.6(L) x 235(W) x 548(H) mm / 20.8(L) x 9.3(W) x 21.6(H) in
Front:
140x25mm fan x2, 1200RPM (pre-Installed).
140 x 25mm fanx1 (optional).
Rear:
140x25mm fan x1, 1200RPM (pre-Installed).
120mm fan x1 (optional).
Top:
120/140mm fan x2 (optional)
Front:
120mm, 140mm, 240mm, 280mm (requires removal of ODD cage)
Rear:
120mm, 140mm.
Top:
120mm, 140mm, 240mm, 280mm (max. 297mm radiator length)
Lighting Support
Power Supply Bottom Mount, ATX PS2 (maximum length: 200mm)
Compatibility (Maximum)
Red LED strip x 1(pre-Installed)
4 LED connections available
VGA card length:
412mm/16.22 inch (without 3.5” HDD cage)
296mm/11.7 inch (with 3.5” HDD cage)
CPU cooler height: 190mm/7.48 inch
EAN Code 4719512050224
UPC Code 884102027666
Carton Size (L x W x H) 602 x 332 x 660 mm / 23.7 x 13.1 x 26.0 inch
Gross Weight 15.3kg/33.73lb
Container With Pallet Carton/Pallet W/O Pallet
20’ 180 18 225
40’ 378 18 465
40’ HQ 420 20 544
buttons
LED & Fan Controller Board
s
included)
on, off and breathe
Dual Chamber
Partition panel isolates power supply and cables
management.
Upgraded I/O
USB 3.0 Type C, fan speed and LED control
Connect up to six 3-pin fan
(12V) and Low( 7V)
Four 2-pin LED strips (one
Three LED modes -
with two-speed control - High
Magnetic LED Strip (Red)
Magnetically attaches to any part of the case
for clean
Sound suppression
Padded front and top panels (with added plate) balance noise
and airflow
Steel Accessory Box
Individually packed screws for easy access and use. Box
comes with magnetic grip which easily sticks to any steel
surface.
Magnetic paneling
Front and top panels fit snugly with a magnetic grip
